FUHR autotronic 834 Installation Instructions Manual
Radio transponder reader nb693n
Hide thumbs
Also See for autotronic 834:
- Quick start manual (12 pages) ,
- Installation, operation and maintenance instructions (55 pages)
Subscribe to Our Youtube Channel
Related Manuals for FUHR autotronic 834
Summary of Contents for FUHR autotronic 834
- Page 1 WWW.FUHR.DE autotronic multitronic 881TPIG01 Radio transponder reader NB693N Installation instructions These instructions are to be passed on by the fitter to the user. www.fuhr.de...
- Page 2 LEDs do not light up. Important information; please note. Green LED flashes. Red LED flashes. For this manual in other languages see www.fuhr.de Green LED lights up, www.fuhr.de Red LED flashes. 2 sec. Green LED lights up for 2 sec.
- Page 3 Applications The radio transponder reader NB693N is a convenient, modern and secure access control system for contact-free switching of FUHR motorised locks. For further connection options, an additional mains-operated power-socket radio-receiver (item no. NZ80088) or a universal radio-receiver (item no. NZ80023) can be integrated in the multitronic/autotronic system, controlled via the radio transponder reader.
- Page 4 Delivery scope FUHR radio transponder reader as set NB693N 1 piece Radio transponder reader with flat stainless steel cover, LED display + connection cable 1 piece Master transponder card for radio channel 1 (no batteries needed) 1 piece...
- Page 5 Radio transponder reader NB693N on the outside of the door 36.4 min. 21.5 Note the plug assignment! 1 2 3 PLEASE NOTE : Please observe the +/- Cable 1, 2, 3 of cable’s correct polarity! the doors’ tappet contacts 1234567 www.fuhr.de...
- Page 6 Item no. NB28052N M3x8 for ALU/PVCu profiles 3x20 for timber profiles Fit the recess in the cover pointing downwards. Before installation, remove the protective film of adhesive films. Press the cover down firmly. Clean the adhesive surfaces with attached cleaning cloth. www.fuhr.de...
- Page 7 For the multitronic/autotronic main door Channel 2 For another multitronic/autotronic door or, in conjunction with the FUHR radio receiver NZ80023/NZ80088, for a motorised garage door drive unit or an electrical yard gate. A user transponder can always only be tuned in to one of the two channels; never for both channels simultaneously. If you would like to control two different doors with one transponder reader, you must use two different user transponders.
- Page 8 CARL FUHR GmbH & Co. KG Carl-Fuhr-Straße 12 D-42579 Heiligenhaus Tel.: +49 2056 592-0 Fax: +49 2056 592-384 www.fuhr.de · info@fuhr.de...
