Installation, operation and
maintenance instructions
These instructions are
to be passed on by the
fitter to the use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the multitronic 881 and is the answer not in the manual?

Questions and answers

Related Manuals for FUHR multitronic 881

Summary of Contents for FUHR multitronic 881

  • Page 1 WWW.FUHR.DE www.fuhr.de www.fuhr.de Installation, operation and maintenance instructions These instructions are to be passed on by the fitter to the use...

  • Page 2: Table Of Contents

    8 Troubleshooting Adjustment of strike plates/one-piece strike plates and latch changing 9 Technical data FUHR multitronic radio key (remote control) FUHR multitronic control unit with radio receiver FUHR multitronic drive unit FUHR multitronic switching power supply unit 10 Optional accessories 11 Wiring diagram Instructions in further languages, refer to www.fuhr.de...

  • Page 3: Introduction

    Introduction The FUHR multipoint locking system multitronic 881 locks doors electromotively – at all times and fully automated. • Particularly reliable – strong and fast – due to two parallel high performance drives. • This conserves energy as the door always closes imperviously.

  • Page 4: Important Information/Safety Instructions

    Material damage or personal injury resulting from non-compliance with the installation, operation and maintenance instructions or inappropriate operation invalidates the warranty. We assume no liability for any consequential damage. The FUHR multipoint locking system multitronic 881 must be protected from humidity. It is not suitable for areas with high humidity and chemical substances.

  • Page 5: Delivery Scope

    Delivery scope One-piece keep or individual keeps Multipoint locking system multitronic 881 Profile related version, incl. electromotive drive unit incl. magnetic contact Control unit with radio receiver and visual locking Switching power supply unit (transformer) indicator Profile related version, Preassembled cable connectors (length 200 and 300 mm)
  • Page 6 3-channel radio key as remote control, 2 m. cover plate 1 pc. with red buttons = master key 6 pcs. double cable guides 2 pcs. with turquoise buttons 2 pcs. end caps Profile-related routing drawing Cable protection sleeves 3 pcs. WWW.FUHR.DE...

  • Page 7: Installation Instructions

    Installation instructions Routing and drilling operations The routings for the FUHR multipoint locking system multitronic 881 are carried out in accordance with the routing drawing provided. In addition to the conventional routings FUHR multipoint locking sys- tems, for example on multisafe 855, only 2 additional routings in the door leaf and the door frame are required.

  • Page 8: Cable-Laying Depending On The Door Design

    The cable-laying for version A is described in the following installation steps. 4.1.2 Routing for the electronic drive unit in the door leaf Routing in compliance with the separate routing drawing between the main lock and the bottom additional locking point WWW.FUHR.DE...

  • Page 9: Routing For The Tappet Contacts In The Door Leaf

    4.1.3 Routing for the tappet contacts in the door leaf Routing in compliance with the separate routing drawing on the hinge side of the door leaf Make sure that the surface-contact device and the tappet contact device are aligned accurately horizontally. Refer to chapter 4.1.6.

  • Page 10: Routing For The Switching Power Supply Unit In The Door Frame

    Drilling in compliance with the separate routing drawing in the frame profile, laterally at the same height as the tappet contact device Make sure that the surface-contact device and the tappet contact device are aligned accurately horizontally. Refer to chapter 4.1.3. WWW.FUHR.DE...

  • Page 11: Drilling For The 230 V Power Supply Cable

    4.1.7 Drilling for the 230 v power supply cable Drilling in compliance with the separate routing drawing on the reverse side of the profile within the routing to accommo- date the switching power supply unit This drill hole must deburred carefully at both ends! Insert the cable protection sleeve provided in the drill hole to protect the 230 V cable.

  • Page 12: Installation

    The installation requires exceptional care. This applies particularly to the electronic compo- nents, as routing and drilling swarf, abrasion points and defective cables can lead to the device malfunctioning. Avoid positioning fixing materials (e.g. frame-fixing screws) in areas where electronic components are located! WWW.FUHR.DE...

  • Page 13: Installation Of The Tappet Contacts In The Door Leaf

    4.2.1 Installation of the tappet contacts in the door leaf The electricity and data transfer control unit for FUHR multitronic may be used on left or right handed doors. On DIN left-handed doors the tappet contact is installed as provided.

  • Page 14: Installation Of The Multipoint Locking System In The Door Leaf

    3. Insert the cable and FUHR multipoint locking system multitronic into the routed recess. In doing so, ensure that the cables are neither kinked, trapped nor damaged.

  • Page 15: Installation Of The Cable Guides, End Caps And Cover Plates In The Door Leaf

    4.2.3 Installation of the cable guides, end caps, and cover plates in the door leaf 1. Fold the provided PVC cable guides for the profile corners in half and snap them apart for the centre profile area. 2. Clip in each of the cable guides into the top door leaf cor- ners, and depending on the door width and height, also in the Euro groove channel.

  • Page 16: Installation Of The Magnetic Contact In The Door Frame

    4. Replace the covers. In order to ensure proper contact and durable operation, the contact surface has been pre-treated with contact lubricant. Please do not remove this lubricant film! Please adhere to the regular maintenance instructions compliance with chapter 7.1. WWW.FUHR.DE...

  • Page 17: Installation Of The Control Unit Casing In The Door Frame

    4.2.6 Installation of the control unit casing in the door frame 1. Remove the silver cover before installing the control unit casing. To do so, carefully insert a small screwdriver into the cover cap’s recess and pry it out. 2. Connect up the surface-contact device’s 3-core cable plug (red, black, white) with the control unit casing’s 3-core cable plug.

  • Page 18: Installation Of The Switching Power Supply Unit (Transformer) In The Door Frame

    4.2.7 Installation of the switching power supply unit (transformer) in the door frame The FUHR multitronic switching power supply unit can be used for left handed as well as right handed doors. On DIN right-handed doors the switching power supply unit is installed as provided.

  • Page 19: Commissioning

    In the event of any problems arising, please refer to chapter 8. 6. If the FUHR multitronic lock is fully operational, the two- pin earthed/grounded plug can be removed and the door can be despatched.

  • Page 20: The Radio Keys (Radio-Controlled Remote Control)

    The radio keys (radio­controlled remote control) The FUHR multitronic is supplied with 3 radio keys (radio- controlled remote controls). All radio keys are copy protected by means of a ‘rolling code system’. The radio key with the red buttons is defined as the master key and is needed to tune in the other radio keys.

  • Page 21: Tuning In And Deleting Radio Keys

    Tuning in and deleting the radio keys 5.5.1 Tuning in individual radio keys (max. 25) 1. During the initial commissioning, all radio keys should, for security reasons be deleted as described in chapter 5.5.3. Subsequently proceed from step 2. 2. Close the door and press the 3.

  • Page 22: Deleting Individual Radio Keys (Except The Master Key)

    2 seconds and then lights up for 1 second and then goes continues to flash slowly. aborted if the 20 second time limit out. is exceeded. 7. Repeat from step 1, should you wish to delete another radio key. WWW.FUHR.DE...

  • Page 23: Deleting All Radio Keys (Except The Master Key)

    5.5.3 Deleting all radio keys (except the master key) 1. Close the door and press the 2. Release the programming button 3. Now press the master key’s middle programming button for longer transmitter button within 20 sec. as soon as the green LED flashes than 3 sec.

  • Page 24: External Connection Options

    External connection options The FUHR multitronic control unit is equipped with a multitude of input and output sockets to connect additional compo- nents (such as e.g. transponder, eye scan, finger print, code locks, electrical swing door opener, alarm systems, facility management systems etc.).
  • Page 25 Opening with day latch function If a continuous signal is applied to this input (e.g. activated via a time switch) the FUHR multitronic lock will open. Upon opening the door leaf or after 5 seconds, only the lock’s latch protrudes. All bolts remain withdrawn as long as the continuous signal is applied.

  • Page 26: Application Examples For Circuit Board Assignment

    Connect the time switch with potential-free continuous signal to terminals 11 + 12 for function 2. Connect the access control system with potential-free impulse (≤ 1 sec.) to terminals 9 + 10 for function 1. Connect the swing door opener to terminals 3 + 4. WWW.FUHR.DE...

  • Page 27: The Drive Unit's Multi-Functional Jack

     By means of either the access control system’s control unit or by pressing a switch, a brief potential-free contact trig- gers opening the FUHR multitronic lock. 5 + 6 Output – ideally used for the power supply of illuminated fixed pad handles or illumina- ted glazed panels.

  • Page 28: Maintenance And Care

    The points raised below are intended as an addition to the FUHR product information M3/3. The importance of their compliance must be pointed out to builders and users alike. In the event of non- compliance with these necessary instructions, faultless operation of the locks cannot be guaranteed.

  • Page 29: Contact Device

    All safety-relevant hardware must be checked at least annually for wear and tear and if mechanically secured. Depending on the requirements, fixing screws must be tightened or the damaged or worn parts exchanged for original parts by a specialised company. Additionally all movable parts and locking points must be lubricated and their function must be checked.

  • Page 30: Troubleshooting

    Troubleshooting In the event that your FUHR multitronic lock should fail to function properly, please refer to the table below to find and rectify the fault. IMPORTANT! The entire FUHR multitronic lock has been subject to extensive inspections by the manufacturer.

  • Page 31: Adjustment Of Strike Plates/One-Piece Strike Plates And Latch Changing

    Type of fault Signal Possible cause of fault Fault repair The door cannot be Red LED lights up. The radio key is not tuned in. Tune in the radio key. opened by the radio key or by an external opening impulse. The distance to the receiver is too Hold the radio key closer to the door.

  • Page 32: Technical Data

    1 master radio key with red buttons and 2 radio keys with turquoise buttons (all supplied with battery) Note: Please refer to our web site www.fuhr.de for a list of countries, in which our radio frequency is approved. FUHR multitronic control unit with radio receiver...

  • Page 33: Fuhr Multitronic Switching Power Supply Unit

    FUHR multitronic switching power supply unit Model: Primary switching controller (single phase, primary clocked built-in power supply) Impulse load capacity, short circuit protected, open-circuit proof, high efficiency, thermal overload protection Tested in accordance with: EN 60950 EMV: EN 50081-2 (emitted interference)

  • Page 34: Optional Accessories

    10.1 Radio fingerprint Pluggable onto the motor scanner drive, compatible with all Biometric system for con- FUHR radio control moduls. venient, keyless access con- A separate control is not trol. With 2 channel techno- necessary. Connects directly logy, opening impulse via to the motor drive socket.
  • Page 35 10.7 Power socket radio 10.11 User transponder receiver Additional user transponder Designed for use with two- (3 user transponders are pin earthed/grounded plug- included in delivery of trans- sockets. For triggering exis- ponder reader). ting electrical drive units via radio key, e.g. garage doors. Item no.

  • Page 36: Wiring Diagram

    Note: In order to activate the alarm system function via terminal 16 and 17, both the motor's circuit board as well as the control unit's circuit board require software release 4.3 or higher. CARL FUHR GmbH & Co. KG Schlösser und Beschläge Carl­Fuhr­straße 12 D­42579 Heiligenhaus Tel.: +49 2056 592­0 Fax: +49 2056 592­384...
