5.2

Replacing the safety cartridge

WARNING
Risk of injury from needles
Injuries caused by contaminated
needles from the safety cartridges can
lead to the transmission of disease.
Always use genuine
safety cartridges for the HAWK PEN.
The installed safety membrane on
these safety cartridges prevents the
ingress of ink into the drive, and also
prevents pathogens from entering
the appliance.
Never hold the safety cartridge by
its tip.
Switch off the HAWK PEN before
changing the safety cartridge.
Ensure that when removing a used
safety cartridge, no ink remnants can
run into the handle.
Never push the needles out of
the safety cartridge.
Check during the removal of a used
safety cartridge that the needles are
completely retracted into the safety
cartridge.
Cheyenne HAWK PEN
Dispose of used safety cartridges that
are no longer required for the current
application (see chapter "Disposal of
equipment" on page 32).
The safety cartridges are supplied
in sterile packaging. Do not remove
them from their packaging until
Cheyenne immediately before you intend to use
them.
Always place the HAWK PEN on the
HAWK PEN TRAY so that the safety
cartridge does not come into contact
with other surfaces.
Seek medical attention if injured by
a contaminated needle.
Switch off the power supply to
the HAWK PEN.
Insert the safety cartridge
the opening in the handle, as illustrated
below.
Due to its locating points on the top and
bottom, each safety cartridge can only
fit in the oval opening in two ways.
Rotate the safety cartridge clockwise
through approx. 45°.
approx. 45°
As you rotate it, the four locating points
will engage audibly until the safety
cartridge is firmly locked into position.
