U-Line H-1096 Manual

U-Line H-1096 Manual

Deluxe counting scale
Hide thumbs Also See for H-1096:
1
2
3
4
5

Advertisement

Table of Contents

H-1096, H-1097
π
H-1098, H-1099
DELUXE
COUNTING SCALE
UNPACKING
1.
Unpack and verify the following components have
been included:
• Scale unit
• Instruction manual
• Weighing pan
• Power adapter
• Allen wrench
• Four head cap screws
2. Save the packaging material. This packaging ensures
the ideal protection for the storage or transport of the
product.
LEVELING
3. Retract the right rear foot (A) completely into the
scale. (See Figure 1)
B
PAGE 1 OF 5
1-800-295-5510
1-800-295-5510
uline.com
uline.com
INSTALLATION
Figure 1
A
4. Adjust the two front feet (A) until the leveling bubble (B)
is centered in the circle. (See Figure 1)
5. Extend the right rear foot until it contacts the mounting
surface. Make certain that all four feet are contacting
the mounting surface.
6. Make certain the scale is stable by placing both
hands on the scale platform and attempt to rock
the scale. If it moves, adjust the leveling feet until the
scale stands firmly on the mounting surface.
ASSEMBLY
1.
Using the Allen wrench and head cap screws
provided, secure the pan support (C) to the four posts
(D) over the sensor (E). Next, place the weighing pan
(F) over the pan support. (See Figure 2)
C
F
E
D
Figure 2
0412 IH-1096

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-1096 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U-Line H-1096

Summary of Contents for U-Line H-1096

  • Page 1 H-1096, H-1097 π 1-800-295-5510 1-800-295-5510 H-1098, H-1099 uline.com uline.com DELUXE COUNTING SCALE INSTALLATION UNPACKING 4. Adjust the two front feet (A) until the leveling bubble (B) is centered in the circle. (See Figure 1) Unpack and verify the following components have 5.

  • Page 2: Connecting To Power

    INSTALLATION CONTINUED CONNECTING TO POWER Figure 3 NOTE: When your scale is first powered on, it automatically runs through a 6-second display test. The scale next displays “C nnn g” (where nnn equals the full scale capacity in grams), performs self-diagnostics to ensure proper operation and then sets itself to zero.

  • Page 3: Basic Weighing

    KEYBOARD FUNCTIONS CONTINUED • Instructs scale to enter a decimal point during numeric entry. Instructs scale to change the sign of a number. Interpreted as a hyphen when entered as part of an ID number. When preceding any register that stores a value, instructs the scale to clear the stored value from that specific register.

  • Page 4: Basic Counting

    OPERATION CONTINUED DISPLAYING THE GROSS WEIGHT 2. To toggle between the gross weight and the net weight, press the gross key repeatedly. The gross Press display followed by the gross key. weight will equal the net weight unless a container weight has been entered using the tare key (see section, “Weighing with a Container”).

  • Page 5: Counting With A Known Average Piece-Weight

    OPERATION CONTINUED USING THE FULL COUNTING FUNCTION 6. When you reach the desired sample size, place the requested number of pieces in the container. Press the zero key. Press the count key. 2. Place a known number of pieces on the pan. 8.
