H-2083, H-2084, H-2085
π
H-2656, H-2657, H-2658
SECURITY CARTS
TOOLS NEEDED
Rubber Mallet
7/16" Wrench
In addition to the 4 posts, 4 shelves, 4 inserts, 4 bolts and
shelf supports from the Chrome Wire Shelving, this kit
includes the following:
Caster x 4
Front Left Door x 1
Front Right Door with Latch x 1
PAGE 1 OF 4
Back Panel
Large Nut x 8
Bracket x 4
1-800-295-5510
uline.com
3/8" Wrench
Phillips Head
Screwdriver
PARTS LIST
NOTE: Back panels, side panels, large nuts
and back panel brackets are included in
the panel box.
Bracket x 8
Side Panel x 2
Bolt x 4
Back Left Panel x 1
Nut x 4
Back Right Panel x 1
0715 IH-2083
Advertisement
Related Manuals for U-Line H-2083
Summary of Contents for U-Line H-2083
- Page 1 H-2083, H-2084, H-2085 π 1-800-295-5510 H-2656, H-2657, H-2658 uline.com SECURITY CARTS TOOLS NEEDED Rubber Mallet 3/8" Wrench 7/16" Wrench Phillips Head Screwdriver PARTS LIST In addition to the 4 posts, 4 shelves, 4 inserts, 4 bolts and NOTE: Back panels, side panels, large nuts...
- Page 2 ASSEMBLY INSTRUCTIONS INSTALL CASTERS 3. Slide posts through underside of shelf until shelf slides firmly over shelf supports. (See Figure 3) 1. Make sure post is positioned as shown. 4. Stand unit upright. Gently tap shelf down to secure. (See Figure 1) (See Figure 4) 2.
- Page 3 ASSEMBLY INSTRUCTIONS CONTINUED 4. Assemble the side panels with the loops on the top 3. After all the loops are lined up on top of the metal facing inward. Tilt the panel so it locks around the inserts on the top of the posts, screw in the bolt on all posts on both ends and then slide down so the loops four posts and tighten using wrench.
- Page 4 ASSEMBLY INSTRUCTIONS CONTINUED ATTACH FRONT DOORS 4. Raise the latch and close the Right Front Door. Lower the latch into place to secure door. 1. Align Left Front Door hinges with Side Panel hinges (See Figure 13) and lower door into place. (See Figure 11) 5.
