CABINET DOLLY
TOOL NEEDED
14 mm Wrench
Caster with Brake x 4
1. Align caster plate with bolt holes on dolly tray. Insert
four bolts through dolly tray into caster plate. Attach
bolts with lock washers and nuts. (See Figure 1)
2. Tighten nuts with a 14 mm wrench.
3. Repeat for remaining casters.
Figure 1
π
PAGE 1 OF 3
CHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
Bolt x 16
Lock Washer x 16
ASSEMBLY
PARTS
Nut x 16
NOTE: Before setting storage cabinet on dolly
please make sure all contents are removed
from cabinet.
Para Español, vea página 2.
Pour le français, consulter la page 3.
NOTE: Weight capacity of the dolly
is 1,000 lbs. This includes weight of
storage cabinet.
Dolly Tray x 1
0219 IH-2461
