1. RS-232 Port
2. USB Port
3. Stecker für Not-Aus-Schalter (Emergency power off - EPO).
4. Share current port (only available for parallel model)
5. Parallel port (only available for parallel model)
IT
6. Intelligent slot
7. Power stage fan
8. Externer Akkuanschluss
9. Bypass Input Circuit Breaker(Only available for dual input unit)
10. Eingang/Ausgang terminal ( Diagramm 2)
11. Eingangsicherung
12. Maintenance bypass switch
13. Output Grounding terminal
14. Output terminal: connect to mission-critical loads
15. Line input terminal
16. Bypass input terminal(Only available for dual input)
17. Input Grounding terminal
2-3. Single UPS Installation
Installation and wiring must be performed in accordance with the local electric laws/regulations and execute
the following instructions by professional personnel.
1)
Make sure the mains wire and breakers in the building are enough for the rated capacity of UPS to
avoid the hazards of electric shock or fire.
NOTE: Do not use the wall receptacle as the input power source for the UPS, as its rated current is less than
the UPS's maximum input current. Otherwise the receptacle may be burned and destroyed.
2) Switch off the mains switch in the building before installation.
3) Turn off all the connected devices before connecting to the UPS.
4) Prepare wires based on the following table:
Model
10000
10000L
15000
15000L
20000
20000L
30000
30000L
Wiring spec (AWG)
Input(Ph)
Output(Ph)
10
10
10
10
8
8
8
8
8
8
8
8
8
8
8
8
Neutral
Battery
8
8
8
6
6
6
6
6
6
4
4
4
Ground
8
8
6
6
6
6
4
4
