Rice Lake 1280 Enterprise Series Installation

1280 Enterprise Series
Dual A/D Scale Card Installation
The Dual A/D Scale Card (PN 164683) provides two additional scale channels. The 1280 can support up to eight scales. The
configuration of each scale is stored both on the card and in the indicators memory. The CPU board will rewrite the calibration
to the A/D scale card if replacing or swapping installed cards.
Manuals can be viewed and downloaded from the Rice Lake Weighing Systems website at
Warranty information can be found on the website at
The included parts kit contains items used for installation of the card. Items listed for stud grounding of the shields pertain to the
panel mount enclosure. See the 1280 technical manual for more information on grounding the shield with the cord grip.
Part No.
14621
14822
15130
153883
15631
53075
94422
166957
171801
January 19, 2018
4
2
Figure 1. Dual A/D Scale Card Kit
Item No. Part No.
160760 Board Assy, Dual A/D
1
14822 Screw, Mach 4-40 NCx1/4
2
3 164676 Face Plate, Option Card
167194 Label, Dual Scale A/D
4
Table 1 Dual A/D Scale Card Kit Parts List
Nut, Kep 6-32NC HEX (used for stud grounding)
Screw, Mach 4-40 NCx1/4 (secures card to controller assembly)
Washer, Lock NO 6 Type A (used for stud grounding)
Connector,5 Pos Screw Terminal (interface connector)
Cable Tie, 3 inch Nylon (secures cable in panel mount installation)
Clamp, Ground Cable Shield (used for stud grounding)
Label, Capacity .40 X 5.00 (used with Dual Scale A/D scales)
NTEP seal for the A/D card to prevent removal.
158208 - Screw, Mach 4-40 x 3/8 (2)
165927 - Clip, Load Cell Locking (1).
Ferrite Core, Snap on (clips onto the load cell cable.)
Table 2 Parts Kit (PN 163784)
www.ricelake.com/warranties
1
3
Description
Description
www.ricelake.com
Qty
1
1
1
1
Qty
2
1
2
2
4
2
2
1
2
PN 164653 Rev D
