The Rice Lake 1280 scale allows you to adjust the tare function through the Scale Setup menu. To make the tare function less sensitive, follow these steps:

1. Enter the Scale Setup menu by pressing the Scales icon.
2. Select Setup from the Scales menu.
3. Locate the Tare Function parameter.
4. Adjust the settings to disable push-button or keyed tares if needed.

Additionally, you may need to adjust the Motion Band parameter to ensure the scale does not detect small fluctuations as motion, which can affect tare sensitivity.

This answer is automatically generated

Summary of Contents for Rice Lake 1280

Page 1 1280 Enterprise Series ™ Color Touchscreen Indicator Version 1.07 Technical Manual PN 167659 Rev G...
Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
Page 3: Table Of Contents
CPU Digital I/O Wiring ............... . 36 Technical training seminars are available through Rice Lake Weighing Systems.
Page 4 Softkeys ..................79 Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost.
Page 5 Importing Revolution Files from a Flash Drive or Micro SD Card........120 Technical training seminars are available through Rice Lake Weighing Systems.
Page 6 Saving Databases from the 1280 to a PC ....... . .
Page 7: Introduction
SD card). Configuration can be performed using the front panel, serial commands or Revolution scale software. For applications using the 1280 indicator as a host device, Version 1.03 or later of the 1280 indicator software must be installed. ®...
Page 8: Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals. WARNING Failure to heed may result in serious injury or death.
Page 9: Weigh Mode
When a system reset is performed (Version 1.05 and later) the Weigh Mode display is populated with a scale widget and Note a softkey widget. This gives end users access to softkey setup without having to use EDP commands or revolution. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 10: Numeric/Alpha Entry
1280 Series Color Touchscreen Indicator Numeric/Alpha Entry When data entry is required, a keyboard or a numeric keypad will display on the screen. Additionally, the indicator’s front panel is equipped with a numeric keypad. 1280 Figure 1-2. On-screen Full Keyboard for Alphanumeric Entry 1280 Figure 1-3.
Page 11: Main Menu User Interface
13. The re-zero function is used to remove a calibration offset when hooks or chains are used to hang the test weights during both zero and span calibration. If hooks or chains were used during calibration, remove these and the test weights from the scale. 14. With all weight removed, press Re-Zero © Rice Lake Weighing Systems ● All Rights Reserved...
Page 12: Setpoints
1280 Series Color Touchscreen Indicator 1.4.2 Setpoints Targets are a set of values that when met, cause the setpoint to trip. Parameter Default Description Setpoint Value: Weight-based – specifies the target weight value, 0–9999999 Value Time-based – specifies time in 0.1 second intervals, range 0–65535 Counter –...
Page 13: Language
Introduction 1.4.4 Language The 1280 has 16 language choices, setting the language is only available in weigh mode. Configuration mode remains in English. Figure 1-5. Language Selections 1. Press to display the list of available languages. 2. Select the desired language.
Page 14: Toggle Units
1280 Series Color Touchscreen Indicator 1.5.1 Toggle Units Pressing toggles between primary, secondary and tertiary units. 1.5.2 Zero Scale Use the following steps to zero the scale (if it is within the acceptable zero range). 1. In gross mode, remove all weight from the scale nd wait for to display.
Page 15: Accumulator Functions
The standard 7 inch panel mount has front panel keys, navigation softkeys and a virtual keypad. The 7 inch and 12 inch keyless panel mounts only support a virtual keypad (Figure 1-7). 1. To enter navigation softkey designations for the 7 inch panel mount, navigate from the 1280 main menu to Configuration Features Softkeys 2.
Page 16: Indicator Keypad Operations
1280 Series Color Touchscreen Indicator Indicator Keypad Operations Display/Virtual keypad Numeric Keypad Navigation Keys 1280 Figure 1-9. Front Panel 1.6.1 Navigation Keys Navigation keys are primarily linked to iRite handlers. If no iRite handlers exist, the navigation keys toggle through a selection of displayed scales.
Page 17: Tare
Display or Clear the Accumulator • A softkey can be programmed for each function • A Display or Clear Accumulator Digital Input can be activated • A serial command can be sent © Rice Lake Weighing Systems ● All Rights Reserved...
Page 18: Alibi Storage
1280 Series Color Touchscreen Indicator Print the Accumulated Value To print the accumulated value, press while displaying the accumulator. Alibi Storage Alibi storage is a database of past transactions listed by date. This allows previous print transactions to be recalled and reprinted.
Page 19: Softkey Operations
Table 1-6. Configurable Softkeys Applications The 1280 can be used in a variety of applications, including checkweighing, counting, recipe batching and truck in/out. For these frequently used applications, the 1280 includes built-in programs that can be used as-is or customized for specific needs.
Page 20 1280 Series Color Touchscreen Indicator 2. System prompts Enter ID to Checkweigh. Enter a stored ID with associated low and high weights. 3. The ID, low and high weights are displayed and the system waits for the threshold to be triggered.
Page 21: Counting Application
Table 1-8. Checkweigher Application Setup and Configuration (Continued) 1.11.2 Counting Application The 1280 counting application is included with the 1280 standard firmware. This application has two scales, one for sampling and one for counting. Upon startup, the softkeys are available.
Page 22: Recipe Batching Application
1280 Series Color Touchscreen Indicator 1.11.3 Recipe Batching Application The 1280 recipe batching application is included with the 1280 standard firmware. Upon startup, the softkeys Recipe are available. Setup Menu Recall a Recipe 1. Press the softkey. The system prompts Enter Recipe ID.
Page 23: Truck In/Out Application
Table 1-10. Recipe Batching Application Setup and Configuration 1.11.4 Truck In/Out Application The 1280 truck in/out software application is included with the 1280 standard firmware. See the 1280 Truck In/Out Addendum (PN 187311) for complete information on setup and functions.
Page 24 1280 Series Color Touchscreen Indicator 2. Enter the truck ID and press . System queries the Inbound database table: Enter If the ID is not found and there is not a keyed tare, the indicator • Momentarily displays Truck Not Found •...
Page 25 USB flash drive using .DB file type; also allows the Import/Export Data Import/Export user to save transactions to the USB flash drive. Reference the 1280 Technical Manual import/Export section for more details. Add/Edit Products Add//Edit Product Add/Edit products in the Product database table.
Page 26: Installation
• Procedures requiring work inside the indicator must be performed by qualified service personnel only. • In the 1280 wall and universal mounts, the supply cord serves as the power disconnect. The power receptacle to the indicator must be easily accessible for these models.
Page 27 Reverse this procedure for reassembly. Upon reassembly, ensure display and keyboard wires are properly connected. To close the door to the universal enclosure, push the bail in and down so that it does not get caught on the Note controller assembly. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 28 1280 Series Color Touchscreen Indicator Controller Assembly Locking Tab Bail Retaining Wire Clip Figure 2-4. Remove CPU Assembly– Universal 10.86 9.24 6.00 5.25 4.25 BASE AND HOLE PATTERN Dimensions are in inches IS SYMMETRICAL ABOUT C L 1.50 .344 Figure 2-5. Universal Surface Mount Stand Dimensions This illustration is not to scale.
Page 29 Alternatively, the A/D scale card includes fillister screws and a bracket that prevent the load cell cable from being disconnected. Large Screw Small Fillister Screws Figure 2-7. Seal the Front Door (Universal Mount) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 30: Wall Mount Enclosure
1. Using the wall mount as a template, mark the screw locations. See Figure 2-14 on page 26 for dimensions. The 1280 wall enclosure can mount to the same location where a 920i was mounted; the screw locations are the Note same.
Page 31 Enclosure hidden for illustration purposes only. Controller Assembly does not need to be removed from the enclosure to seal the setup switch. Large Fillister Screw DIN Rail Clip Figure 2-12. Seal the Setup Switch (Wall Mount) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 32 1280 Series Color Touchscreen Indicator Sealing the Front Door In certain Legal for Trade applications, it may be necessary to seal the indicator to restrict access from the internal hardware of the indicator. To seal the wall mount enclosure front door, wrap the lead wire seal through the large screw securing the front door and the hole in the edge of the door enclosure.
Page 33: Panel Mount Enclosure
Installation 2.2.3 Panel Mount Enclosure The 1280 panel mount will ship partially assembled. The display assembly must be removed from the backing plate to allow installation on the existing panel. 1. Tape the panel mount template to the outside of the panel.
Page 34 1280 Series Color Touchscreen Indicator Panel Mount Dimensions Dimensions are in inches 9.000 FOOT PRINT OF PANEL 7.440 AND BRACKET HOLE PATTERN Ă .250 DRILL 4.75 7.440 HOLE PATTERN 9.000 FOOT PRINT OF PANEL AND BRACKET Ă 1.00 CUT OUT ALONG...
Page 35 These illustrations are not to scale. It is for illustration purposes only. Use the dimensions to mark the holes for IMPORTANT the panel mount, or use the template provided with the indicator. Do NOT use Figure 2-17, Figure 2-18 Figure 2-19 as a template. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 36 1280 Series Color Touchscreen Indicator Installing Grounding Bus Bar The grounding bus bar is installed on the controller assembly for grounding purposes on the 1280 panel mount enclosure. 1. Remove the four corner screws from the controller assembly. 2. Secure grounding bus bar onto controller assembly using screws from step 1.
Page 37 Similarly, the grounding bus bar may remain attached if previously installed. DIN Rail Clip Large Fillister Screw Figure 2-23. Seal the Setup Switch (Panel Mount Enclosure) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 38: Option Card Installation
Option Card Installation Use the following instructions to install option cards in the 1280. There are two SPI communication buses for the six option card slots: one for slots 1, 2 and 3 and a second for slots 4, 5 and 6. Communication is faster with less traffic on an SPI bus. For optimal performance, populate slots 1 and 4 first in order to keep cards on their own SPI bus.
Page 39: Cable Connections
Figure 2-27 Cable Connections The 1280 universal and wall enclosures provide cord grips for cabling into the indicator; one is for the power cord and the rest are to accommodate interface cables. Install plugs in all unused cord grips to prevent moisture from entering the enclosure. Secure wires after cabling is complete to avoid low voltage circuits contacting high voltage circuits.
Page 40: Panel Enclosure Grounding
1280 Series Color Touchscreen Indicator 2.4.2 Panel Enclosure Grounding To ground cables to the panel enclosure, place the shield wire on the grounding clip on the controller assembly. Place the shield wire on the grounding clip on the Controller Assembly.
Page 41: Serial Communications
The hardware of J2 will not be populated on a single A/D scale card. Note 2.4.4 Serial Communications The two communication ports on the 1280 CPU board support full duplex RS-232, RS-422 or RS-485 communications at up to 115200 bps. LVDS DISPLAY KEYBOARD...
Page 42: Cpu Digital I/O Wiring
1280 Series Color Touchscreen Indicator Table 2-2 shows the pin assignments for communication ports. Connector Signal Port RS-232 RX/RS-485 B RS-232 TX/RS-485 A RS-232 CTS/RS-485 Z RS-232 RTS/RS-485 Y RS-232 RX/RS-485 B RS-232 TX/RS-485 A RS-232 CTS/RS-485 Z RS-232 RTS/RS-485 Y Table 2-2.
Page 43: Wiring Schematics
INSERT SIDE UP WD_RST RESET iMX6 JTAG MFGR MFGR PN# VER. x.xxx CGND CGND ETHERNET Micro DUAL SERIAL uUSB-AB PORT#1 PORT#2 SD Card USB-A ANTENNA CPU Board Figure 2-32. Wiring Diagram © Rice Lake Weighing Systems ● All Rights Reserved...
Page 44: Configuration Methods
USB-A ANTENNA Figure 2-33. 7 and 12 Inch Panel Mounts - Touch Only Configuration Methods The 1280 indicator can be configured using: • Front panel keys to navigate through a series of configuration menus (see Section 3.0 on page ®...
Page 45: Cpu Board Replacement
4. Remove the nut for the antenna and the two screws securing the CPU board to the face plate. 5. Remove the CPU board. Reverse procedure for reassembly. Figure 2-35. Remove CPU Board from the Face Plate © Rice Lake Weighing Systems ● All Rights Reserved...
Page 46: Power Supply Replacement
1280 Series Color Touchscreen Indicator Power Supply Replacement WARNING • Use a wrist strap for grounding to protect components from electrostatic discharge (ESD) when working inside the indicator enclosure. • Procedures requiring work inside the indicator must be performed by qualified service personnel only.
Page 47: Replace Fan Plate And Back Plane
The power receptacle to the indicator must be easily accessible for these models. IMPORTANT If replacing CPU boards in the 1280, a new fan plate is also required. Use the follow ing instructions to replace the fan plate and back plane.
Page 48: Replacement Parts
1280 Series Color Touchscreen Indicator procedure for reassembly. Reverse this 2.10 Replacement Parts Inside Bottom of Enclosure (some items are hidden for clairity) Figure 2-40. Replacement Parts Drawing - Universal Enclosure Visit our website www.RiceLake.com...
Page 49 183663 Tall Flanged Drilled Hex Head Screw 169452 Enclosure Shell Assembly, Universal 169875 Cord Grip, PG 9 With Nut 169876 Cord Grip, PG 13.5 With Nut Table 2-4. Universal Parts List © Rice Lake Weighing Systems ● All Rights Reserved...
Page 50 1280 Series Color Touchscreen Indicator Figure 2-41. Replacement Parts Drawing - Panel Enclosure Visit our website www.RiceLake.com...
Page 51 Cable, CPU to Display (1000 Nit) 162309 Backer Bracket 166838 Bracket Assembly, DIN Rail Table 2-5. Replacement Parts – Panel Enclosure Note If controller is not connected to the panel, ground per NEC. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 52 1280 Series Color Touchscreen Indicator Cover exploded for clarity Inside Bottom of Enclosure (some items hidden for clarity) Figure 2-42. Replacement Parts Drawing - Wall Enclosure Visit our website www.RiceLake.com...
Page 53 Cord, European Power 169876 Cord Grip, PG13.5 With Nut 68600 Cord Grip, PG11 68599 Seal Ring, Nylon PG 11 68601 Nut, PG 11, Power Cord Cable Table 2-6. Replacement Parts - Wall Enclosure © Rice Lake Weighing Systems ● All Rights Reserved...
Page 54 1280 Series Color Touchscreen Indicator Figure 2-43. Replacement Parts Drawing - Controller Assembly Item No. Part No. Description Fan Mount Plate Assembly Note: CPU, Rev A, Requires Rev A Fan Plate CPU, Rev B, Requires Rev A Fan Plate 169350...
Page 55 Screw, Mach 6-32NC x 3/8'' 94422 Label, Capacity 163408 Blank Plate, Option Card Slot Cover 165927 Clip, Locking Load Cell (Kit PN 166957) Table 2-7. Replacement Parts - Controller Assembly (Continued) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 56 1280 Series Color Touchscreen Indicator Figure 2-44. Replacement Parts Drawing - 7 Inch Touch Only Panel Enclosure Item No. Part No. Description 182145 Mounting Plate Assembly, 7-inch Panel Mount 176168 Display, Assembly, 7-inch Panel Mount 166725 Display Board (500 Nit)
Page 57 Label, 1280 Serial Tag 166838 Din Rail Mount 180002 Cable, CPU to Touchscreen 182992 Display, 12-inch 180001 Cable, CPU to Display Table 2-9. Replacement Parts – 12 Inch Touch Only Panel Enclosure © Rice Lake Weighing Systems ● All Rights Reserved...
Page 58: Label Legend
1280 Series Color Touchscreen Indicator 2.11 Label Legend Slot 6 Slot 5 Slot 4 Slot 3 Slot 2 Slot 1 ETHERNET CHANNEL 2 CHANNEL 1 DIGITAL I/O DEVICE HOST SD CARD 10/100 RTS CTS TX RX GND RTS CTS TX RX GND...
Page 59: Configuration Menu
Non-conductive Tool Figure 3-1. Setup Switch Location (Universal Enclosure) Panel Mount Enclosure Wall Mount Enclosure Setup Switch Configuration Screw Setup Switch Configuration Screw Figure 3-2. Setup Switch Locations (Panel/Wall Mount Enclosures) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 60 1280 Series Color Touchscreen Indicator 4. Access to the configuration menu may be restricted with a password. If prompted, enter the password, then press . The configuration menu will display, see Section 3.3 on page KEYBOARD LVDS DISPLAY POWER Light pipes and mounting plate removed for clarity.
Page 61: Configuration Menu
Press to restore all settings to factory defaults. Partially Reset to Factory Press to partially restore settings to factory defaults, this preserves Ethernet and scale settings. Defaults Table 3-1. Configuration Main Menus © Rice Lake Weighing Systems ● All Rights Reserved...
Page 62: Configuration Menu Map
1280 Series Color Touchscreen Indicator 3.3.1 Configuration Menu Map Figure 3-5 illustrates the menu structure in the configuration menu selections. Scales Scale 1-8 Format Calibration Filtering Setup Maintenance See Section 4.0 Communications Serial Ethernet Fieldbus See Section 5.0 Features Softkeys...
Page 63: Scale Configuration
A scale receiving a stream of weight data over a serial or Ethernet connection. Parameter values are Industrial Serial Scale configurable. Scale functions zero and tare can be used. iQube2 Scale Scale is connected to 1280 via an iQube2 Junction Box, see Section 5.4 on page 77 Program Scale iRite program provides the scale data.
Page 64: Scale Alias
1280 Series Color Touchscreen Indicator Setup a Scale 1. Select the scale (1-8) to be configured from the drop-down menu in Figure 4-1. 2. Press to select the scale kind. 3. If applicable, a screen will open showing available hardware to associate with the selected scale kind (for example, an analog load cell scale will have hardware identified as slot and channel).
Page 65: Scale Format
Available to enter a name for custom units. Maximum length is 8. Custom Units Two — Custom Units Three — Split Mode Multi-Range, Multi-Interval Settings; see Section 4.1.3 for more information. Table 4-2. Scale Format Defaults are shown for NTEP mode. Note © Rice Lake Weighing Systems ● All Rights Reserved...
Page 66: Split Mode
1280 Series Color Touchscreen Indicator 4.1.3 Split Mode The 1280 supports multi-range and multi-interval scales of either two or three ranges or intervals. To set up Multi-Range or Multi-Interval, select from the Scales Format menu. Select from the Split Mode...
Page 67: Scale Calibration
Linear calibration points provide increased scale accuracy by calibrating the indicator at up to four additional points Note between the zero and span calibrations. button begins a step-by step procedure for calibration. See Section 4.2.1. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 68: Standard Calibration
1280 Series Color Touchscreen Indicator 4.2.1 Standard Calibration Use the following steps to perform a standard calibration on a scale. 1. Select the scale to be calibrated and enter the calibration menu. 2. Press 3. Select the method of calibration. Press For other methods calibration see: •Section 4.2.2...
Page 69: Multi-Point Calibration
This calibration cannot be performed when calibrating a scale for the first time. A last zero calibration is typically used on truck scales to allow a scale verification to become a calibration without having to remove the test weights. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 70: Temporary Zero Calibration
Scale Filtering Digital filtering can be used to create a stable scale reading by removing environmental influences. The 1280 has two filtering methods that can be selected; Adaptive Digital and Three Stage Filtering. Three Stage Filtering is selected by default. In addition, the A/D sample rate and damping time constant can be set in this menu.
Page 71: Adaptive Digital Filter
4. Further tweak this value, along with the sensitivity, to achieve the desired results. Set sensitivity for the desired response for weight changes; light for less stable but quicker responses, heavy for more stable but slower responses. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 72: Three Stage Filter
1280 Series Color Touchscreen Indicator 4.3.2 Three Stage Filter The Three Stage Digital filter is a simple rolling average filter with three successive stages. The values assigned to each of the three stages determines the number of A/D readings averaged by that stage. The output value of each stage is passed on to the next stage at each A/D update.
Page 73: Scales Setup
• If motion is detected, the delay timer is reset and the warm up period is repeated. Visible Specifies whether scale data is displayed. * Maximum legal value of these parameters varies depending on local regulations. Table 4-11. Scales General Descriptions © Rice Lake Weighing Systems ● All Rights Reserved...
Page 74: Maintenance
For industrial scales, the only data needed is the gross weight. The data can (but does not need to) include the unit of measure, mode or status. If the unit of measure is included, it can be used to change the capacity label on the 1280 display. If not, the 1280 will always assume it is primary units.
Page 75 No matter the type, if the data received does not match exactly that which is expected (as defined by the stream format configuration), the data is thrown out and the scale will show an error. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 76: Communications
1280 Series Color Touchscreen Indicator Communications The Communications menu is used for the setup of communication parameters for the 1280. From the Configuration menu, select the Communications icon (circled in Figure 5-1) to enter the Communications menu. Once all parameters have been set, press to return to weigh mode.
Page 77: Serial Menu
RS-485 Network Address. Alias — Allows the serial port to be renamed. Specifies whether characters received by the port are echoed back to the sending Echo unit. Table 5-3. Serial Port Parameters © Rice Lake Weighing Systems ● All Rights Reserved...
Page 78: Ethernet Menu
The Ethernet menu is used for the setup of wired and Wi-Fi Ethernet connections, including Wi-Fi Direct. These are used to connect the 1280 to local area networks (WLAN and LAN). Network information can be found in weigh mode by pressing the Wi-Fi symbol or in the menu in Configuration Mode.
Page 79: Using An Internet Browser As A Remote Display
To use this feature, the 1280 and computer/mobile device must be connected to the same network. In the browser’s address bar (URL), type the 1280’s IP address using TCP port 3000.
Page 80: Wi-Fi® Direct
1280 Series Color Touchscreen Indicator 5.2.4 Wi-Fi Adapter When Wi-Fi Adapter is selected, the parameters in Table 5-6 will display. Parameter Default Description Enable Wi-Fi Ethernet Communications – Off speeds up the booting process and configura- Enable tion mode to weigh mode transitions.
Page 81 10. Press . The weigh screen is displayed. 11. Using the PC, mobile phone or iPad/tablet, enter settings, then Wi-Fi selections. The name of the 1280 SSID should be displayed as an option in the Wi-Fi selections. 12. Select the 1280 SSID from the list, a screen will display asking for the Password.
Page 82: Tcp Command Server
The amount of time an active connection is held before it is dropped. 30 Hz Sets the rate at which the 1280 polls the iQube2 for weight data. It is only visi- iQube2 Sample Rate ble when the Input Type is set to iQube2.
Page 83: Data Swap
It is best to change the data order in the device being used, but if that is not possible, Data Swap is the best alternative. iQube2 Scale This system has a scale connected to the 1280 using an iQube2 junction box. The setup for this system can be found in the iQube2 technical manual (PN 67888).
Page 84: Features
1280 Series Color Touchscreen Indicator Features The Features menu allows the setup of parameters for the menu items listed inTable 6-1. From the Configuration menu, select the icon (circled in Figure 6-1) to enter the Features menu. Features Once all parameters have been set, press to return to weigh mode.
Page 85: Softkeys
Enter the scale number (using the numeric keypad) to be displayed for multi-scale applications, followed by the select scale Select Scale softkey. Diagnostics Opens the iQube2 diagnostics screen Alibi Allows previous print transactions to be recalled and reprinted. Contrast Adjusts the screen backlight intensity. Table 6-2. Configurable Softkeys © Rice Lake Weighing Systems ● All Rights Reserved...
Page 86: Database Softkey
Section 13.5 on page 123 to complete the database import/export. 6.1.4 LaserLight Softkey User must configure 1280 softkeys to use Stop/Go. See Table 6-3 to view the pre-populated commands in the print formats. Figure 6-3. Database Screen in Weigh Mode Figure 6-4.
Page 87: General Parameters
• The remote indicator can only display the local’s display and return key/virtual keypad presses. Weight data is not available at the remote indicator for functions such as printing, serial data streaming or setpoints. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 88: Regulatory
To use this feature, the 1280 and computer/mobile device must be connected to the same network. In the browser’s address bar (URL), type the 1280’s IP address, using TCP port 3000.
Page 89: Parameters Available In All Regulatory Modes
No action if weight is outside of ZRANGE no action zero or negative Clear Tare Measurement Canada Zero Tare positive no action Industrial Mode See Table 6-8 Table 6-7. Tare/Zero Key Functions for Regulatory Parameter Settings © Rice Lake Weighing Systems ● All Rights Reserved...
Page 90 1280 Series Color Touchscreen Indicator Front Panel Key Function Regulatory Parameter Value Weight on Scale Tare in System Tare Zero Tare zero or negative Clear Tare NONE Zero Tare positive Clear Tare Table 6-7. Tare/Zero Key Functions for Regulatory Parameter Settings (Continued)
Page 91: Passwords
Select Colon (:) or Comma (,) as the time separator. Decimal Format Dot (.) Select Dot (.) or Comma (,) as the format for the decimal. Table 6-10. Locale Parameters Menu © Rice Lake Weighing Systems ● All Rights Reserved...
Page 92: Default Weigh Mode Languages
1280 Series Color Touchscreen Indicator Parameter Default Description Time/Date Change Returns current status, only works in setup mode Restriction ON/OFF Table 6-10. Locale Parameters Menu (Continued) 6.5.1 Default Weigh Mode Languages There are 16 languages available for the indicator weigh mode.
Page 93: Advanced Printing
4. Select the connection type to be used to connect to the printer, network or USB. 5. If using a network connection, enter the Network URl. The 1280 supports Direct Print and Internet Printing Protocol for printing directly to a printer. URI examples Note include: socket://<ip-address-of printer>:9100...
Page 94 The checksum is calculated when the weighment is stored in alibi storage. When the data is retrieved, the checksum is re- calibrated and compared to the initial value. If the values match, the data is transmitted. If they do not match, the 1280 will send an Invalid Record response.
Page 95: Formats
Print Formats the setpoint push-print or truck weigh-in/weigh-out operations are performed. See Section 7.1 The 1280 supports four configurable data streaming formats that can be set to outside data frames in Stream Formats one of nine pre-configured formats (see Table 7-2), or the data frame can be customized.
Page 96: Default Print Formats
1280 Series Color Touchscreen Indicator Use the Revolution configuration utility, serial commands or the indicator front panel to customize the print formats. 1. Press , then select Print Format 2. Press the selection field arrow (circled in Figure 7-2) to select the print format to be configured.
Page 97: Print Format Tokens
Number of weighments (<NOW> token) is incremented whenever the scale weight exceeds 10% of scale capacity. Scale must return to gross or net zero before the value can be incremented again. Table 7-4. Print Format Tokens © Rice Lake Weighing Systems ● All Rights Reserved...
Page 98 1280 Series Color Touchscreen Indicator Token Description Supported Ticket Formats Formatting and General-Purpose Tokens ASCII character (nnn = decimal value of ASCII character). <nnn> Used for inserting control characters (STX, for example) in the print stream. <TI> Time <DA> Date <TD>...
Page 99: Strteam Format Menu
To set up the stream formats using the indicator front panel: 1. Press , then select . See Figure 7-1. Stream Format 2. Press to select the format to be configured. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 100 1280 Series Color Touchscreen Indicator 3. Press Output Stream Type to set Industrial or Legal for Trade. 4. Press 5. Press Stream Source to set one of the eight scales for the format. 6. Press Stream Format to choose the format to be used and press 7.
Page 101: Stream Format Tokens
=01 if primary DSPDIV=1 Configuration =10 if primary DSPDIV=2 =11 if primary DSPDIV=5 =00 (not used) =01 if secondary DSPDIV=1 Configuration =10 if secondary DSPDIV=2 =11 if secondary DSPDIV=5 Table 7-6. Stream Format Tokens © Rice Lake Weighing Systems ● All Rights Reserved...
Page 102 1280 Series Color Touchscreen Indicator Format Identifier Defined By Description =00 (not used) =01 if tertiary DSPDIV=1 Configuration =10 if tertiary DSPDIV=2 =11 if tertiary DSPDIV=5 =000 if current DECPNT=8888800 =001 if current DECPNT=8888880 =010 if current DECPNT=8888888 =011 if current DECPNT=888888.8 Configuration =100 if current DECPNT=88888.88...
Page 103: Digital I/O
Assigns the bit as a digital output for setpoint or iRite program use. Input Assigns the bit as a digital input used for Digital Input setpoints. Table 8-1. Digital I/O Types © Rice Lake Weighing Systems ● All Rights Reserved...
Page 104 1280 Series Color Touchscreen Indicator Function Description Programmability Assigns the bit as a digital input used to generate a iRite program event. Zero Provides the same function as the front panel Zero key. Gross/Net Provides the same function as the front panel Gross/Net key.
Page 105: Analog Output
Specifies the maximum weight value tracked by the analog output, range of -9999999 Maximum Value Tracked to 9999999. Alias — Enter an alias name for the analog output. Table 9-1. Analog Output Parameters © Rice Lake Weighing Systems ● All Rights Reserved...
Page 106: Analog Output Calibration
1280 Series Color Touchscreen Indicator Analog Output Calibration The following calibration procedure requires a multimeter to measure voltage or current output from the analog output module. Note The analog output must be calibrated after the indicator itself has been configured and calibrated.
Page 107: Setpoints
10.0 Setpoints The 1280 indicator provides 100 configurable setpoints for control of the indicator and external equipment functions. Setpoints can be configured to perform actions or functions based on specified parameter conditions. Parameters associated with various setpoint kinds can be configured to: •...
Page 108: Select Setpoint For Configuration
1280 Series Color Touchscreen Indicator 10.1 Select Setpoint for Configuration 1. Press to select the setpoint (1-100) for which the target value needs to be changed. Setpoint 1 2. Press the red number of the setpoint in the table (use the arrows to scroll through the setpoints).
Page 109 • Start and End parameters are used to specify the start and end setpoints. • If the End setpoint is not reached before the timer expires, the digital output associated with this setpoint is activated. Table 10-2. Setpoint Kinds (Continued) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 110 1280 Series Color Touchscreen Indicator Parameter Description Batch Continuous Allows a digital output to remain active over a specified portion of the batch sequence. • Type 1 (VALUE=0): The digital output associated with this setpoint becomes active when the Start setpoint becomes the current batch step and remains active until the End setpoint becomes the current batch step.
Page 111: Setpoint Configuration
Wait Standstill Quiet Digital I/O Sense Slot None Normal Slot 1-6 Invert Settings Prompt Batch Access Enable Alias Enter Enter Value Value Hide Branch Figure 10-3. Gross/Net/Negative Gross/Negative Net Setpoint Parameters © Rice Lake Weighing Systems ● All Rights Reserved...
Page 112 1280 Series Color Touchscreen Indicator Accumulate Target Value Source Trip Enter Scale Higher/Lower Inband/Outband Value Band Value Preact No parameters to be set. Actions Push Tare Alarm Clear Accum. Clear Tare Push Accum. Push Print Quiet Wait Standstill Digital I/O...
Page 113 Slot 1-6 Invert Settings Branch Access Alias Prompt Settings Enter Enter Enter Access Alias Prompt Value Value Value Enter Enter Hide Value Value Hide Figure 10-7. Wait Standstill and Counter Setpoint Parameters © Rice Lake Weighing Systems ● All Rights Reserved...
Page 114 1280 Series Color Touchscreen Indicator Auto-Jog Center Of Zero/In-Motion/In-Range Target Target Source Source Scale Scale 1-8 Preact Preact No parameters to be set. No parameters to be set. Actions Actions No parameters to be set. Push Accum. Push Print Push Tare Clear Accum.
Page 115 None Normal Slot 1-6 Invert No parameters to be set (Always only). Settings Batch Access Alias Prompt Enter Enter Value Value Hide Figure 10-11. Time of Day and Always/Never Setpoint Parameters © Rice Lake Weighing Systems ● All Rights Reserved...
Page 116 1280 Series Color Touchscreen Indicator Digital Input Count Target Digital Input Slot Mask Value Pre-Count Enter Enter Enter Enter Slot Value Value Value Preact No parameters to be set. Actions No parameters to be set. Digital I/O Sense Slot None...
Page 117: Targets
For setpoints with Preact Type set to Learn, Preact Adjust specifies a decimal number of the percentage Preact Adjust (%) of error correction applied (0.5 = 50%, 1.0 = 100%), each time an adjustment is made. The range is 0-100. Table 10-4. Preact Parameters © Rice Lake Weighing Systems ● All Rights Reserved...
Page 118: Actions
1280 Series Color Touchscreen Indicator Parameter Default Description For setpoints with Preact Type set to Learn, Preact Stability specifies the time (0.1 second), to wait for Preact Stability standstill before adjusting the Preact Value. Setting this parameter to a value greater than zero disables (seconds) the learn process if standstill is not achieved in the specified interval.
Page 119: Batch Operations
Setpoints 10.3 Batch Operations Softkeys can be configured to allow operator control of batch operations from the 1280 front panel, or they can be configured using MSI-8000HD, serial commands or the Features menu (see Section 6.1 on page 79). Display or change assigned setpoints.
Page 120 1280 Series Color Touchscreen Indicator ABORT/RUN/START SWITCH BLACK CPU BOARD DIGITAL I/O 7 8 9 10 BLACK WHITE EMERGENCY START/STOP SWITCH Figure 10-14. Batching Switch Wiring Diagram Example To begin a batch process, turn the 3-way switch to Start momentarily. If the...
Page 121: Diagnostics
Select On to enable the Automatic Backlight Control. If set to Off, a Manual Backlight Value parama- Automatic Backlight Control ter displays, allowing a light value to be manually set to Low, Medium or High. Table 11-1. Devices Menu © Rice Lake Weighing Systems ● All Rights Reserved...
Page 122: Touchscreen Calibration
9171 on the numeric keypad and press Clear. Cycle power the indicator and follow steps 5 above. There will be no response from the screen until the power has been cycled. Alternatively, the user can send a REMOVE.TSCAL serial command to the 1280 to prompt for a touch screen recalibration after the next power cycle.
Page 123: Option Cards
Option Cards The 1280 can host up to six option cards. The option cards can be installed in any of the six available option slots. The cards cannot be installed or removed when power is applied to the indicator (cards cannot be hot swapped).
Page 124: Option Card Firmware
1280 Series Color Touchscreen Indicator 99 = Single Channel Analog Output card 90 = Dual Channel Analog Output card B1 = Dual Channel Analog Input card AA = Fieldbus card (with any module) 12.2 Option Card Firmware The OPTVERSION#s serial command, where s is the slot number, can be used to return the version of the firmware installed on the option cards.
Page 125: Importing/Exporting
• Database – .db extension which are the actual data records that would populate a database schema. Definitions Export – pulling information from the 1280 to a file system to save as one of the two types of files. Import – sending information to the 1280 from a previously saved file system.
Page 126: Importing Configuration
• Save the .rev file to a micro SD card and importing it into the 1280 from the micro SD card Slot • Connect to the 1280 from a PC that has 1280 open and is connected to any COM port (USB, Ethernet or Serial). See Section 13.7 on page 124...
Page 127: Importing Irite™ Programs
• Import the program stored on a micro SD card. iRite • Connect to the 1280 from a PC that has Revolution open and is connected to any COM port (USB, Ethernet or Serial). Section 13.7 on page 124. 13.2.1 Importing Built-in iRite Programs 1.
Page 128: Importing Database Data
13.3.1 Importing Databases from a Flash Drive or Micro SD Card 1. Insert a flash drive or a micro SD Card into the 1280 with a saved .db file (a text file with a special extension, that was previously exported pipe-delimited file of records).
Page 129: Exporting Configuration
Download to Figure 13-4. Database Commands in Revolution The data shown in the Data Editor will be sent one at a time to the 1280. This data is appended to any existing data in the 1280. 13.4 Exporting Configuration It is important to save a copy of the file to create a backup version of the Configuration. There are three ways this can be done.
Page 130: Exporting Database To Flash Drive Or Micro Sd Card
124. 4. Navigate to the Database Editor in 1280 and click on the database name (in the middle) that is about to be populated. 5. A grid will display that is as many columns wide as there are fields, and as many rows down as there are records.
Page 131 Auto Detect Settings check box remains unchecked on the AutoDetect screen. Settings Set parameters as needed Figure 13-7. Set Communications Parameters 7. From Settings, set the communication parameters as needed. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 132: Loading New Firmware
8. An address is required for connection to RS-485 or TCP/IP . 13.8 Loading New Firmware For the latest version of the 1280 firmware go to www.ricelake.com. Prior to loading new firmware, save existing configuration and/or databases by using the instructions earlier in IMPORTANT this section.
Page 133: Check Current Firmware
Importing/Exporting 13.8.1 Check Current Firmware Enter the configuration mode, the current firmware version loaded on the 1280 will be displayed at the bottom of the screen.. V1.07.00 Figure 13-9. Check the Firmware Version Compare it to the latest version available Online at www.ricelake.com...
Page 134 1280 Series Color Touchscreen Indicator checking for the flash drive (this may take up to 12 seconds). Figure 13-11. Initializing – Firmware Update 4. Once the device is found the message ‘update’ directory found on USB storage device displays. Press the USB button.
Page 135: Errors
• Make sure the flash drive is formatted as a FAT32 file system. NTFS is not recognized. • Try another flash drive, the first one may be faulty. • If the issue continues, it may be a faulty USB port, please contact technical support for further assistance. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 136 1280 Series Color Touchscreen Indicator Update Directory Missing The update directory does not exist on the flash drive. Figure 13-14. Update Directory Not Found Solution • Verify that the update directory containing the firmware image update files exists at the root level of the flash drive.
Page 137 Download and extract the zip file again. Table 13-1. Digital Signature Failure Errors Do not tamper, modify or remove any of the firmware image files in the update directory. Doing so may render the IMPORTANT unit non-functional. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 138: Scale Card Version Update
4. Type erasecard#s (s=Scale Card Slot Number) and hit . Reenter command to verify card erase displays. Enter 5. Type erasecard#s and hit . OK displays. Enter 6. Power down 1280 and remove the scale card. Visit our website www.RiceLake.com...
Page 139 12. Drag and drop the .bin file into the folder. The folder closes and the scale card pipe lights will blink green. Figure 13-22. Green Lights 13. Disconnect USB from scale card and reinstall card in the 1280. 14. Power on the 1280 and reconfigure card.
Page 140: Visual Studio Code - Irite
1280 Series Color Touchscreen Indicator 13.10 Visual Studio Code – iRite This supports the iRite Language for Visual Studio Code. • Syntax Colorization • Snippets • Preprocessing • Compiling • Deployment to Indicator Installation 1. Press and enter iRite. 2. Press install and allow VScode to restart. The syntax highlighting and snippets are now available.
Page 141: Display Editor
The Display Editor, in Revolution, is the only way to add widgets. Widgets can be added on up to 99 different screens. The type and location of elements shown on the 1280 display are easily specified using the drag and drop features of the 1280 utility.
Page 142 1280 Series Color Touchscreen Indicator Some widget types require that the location or size of the widget be specified, in pixels. Figure 14-2 shows the pixel counts (133.33 pixels per inch) used to specify the pixel location on the display.
Page 143: Scale Widgets
(to resize the bitmap) or enter a number for either value. Left/Top– position away from the left/top edge in pixels. This can be dragged/dropped (to reposition the bitmap) or enter a number for either value. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 144: Bar Graph Widgets
1280 Series Color Touchscreen Indicator 14.2.3 Bar Graph Widgets Bar graph widgets allow display of vertical or horizontal graphs, either a normal bar graph style or a needle gauge, with or without graduations. The graph can be used to represent scale weight or progress toward a setpoint target value. To...
Page 145: Label Widgets
Left/Top – Set the distance from the left/top edges in pixels. This can be dragged/dropped (to position the label widget) or for more precise alignment a number can be entered for any of these values. © Rice Lake Weighing Systems ● All Rights Reserved...
Page 146: Symbol Widgets
SDimages folder. If using an image located at a URL Address, simply enter that address here. The 1280 has to be connected to a network that can access the specified URL Address.
Page 147 31.png Exit 12.png Green Bar 32.png Delete All 13.png Dark Red Bar 33.png Delete Entry 14.png Light Grey Bar 34.png Truck Database Search 15.png Yellow Bar 35.png 16.png 36.png 17.png 37.png © Rice Lake Weighing Systems ● All Rights Reserved...
Page 148: Chart Widgets
14.2.7 Chart Widgets Chart widgets are used to visually graph data on the 1280 display. Available chart types include line graphs, vertical bar charts, and horizontal bar charts. These features can only be used in conjunction with an iRite program to populate these charts. See...
Page 149: Line Widgets
Default Softkeys can be reincorporated automatically by entering the Features menu, under General and select Softkey Auto-Population This will conflict with softkey widgets added in Revolution. Figure 14-14. Softkey Widget Properties © Rice Lake Weighing Systems ● All Rights Reserved...
Page 150: Widget Colors
1280 Series Color Touchscreen Indicator 14.3 Widget Colors The 1280 display is capable of displaying 256 thousand colors. When defining the display widgets, the color of some of their elements can be specified. This ability varies by widget type. Scale Widgets – the color of both the foreground and background can be specified.
Page 151 Stop Sign Yield Sign Skull & Crossbones Unbalanced Runner Walker Printer Hourglass Gas Pump Conveyor Batch Auto/Manual Valve Motor Checkmark Faucet Padlock Pipe Conveyor Full Info Table 14-2. Widget Table (Continued) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 152 1280 Series Color Touchscreen Indicator Description Widget State 1 Widget State 2 Widget State 3 Widget State 4 Power Folder Recipe Report Manual Mode Table 14-2. Widget Table (Continued) Visit our website www.RiceLake.com...
Page 153: Edp Commands
EDP Commands The 1280 indicator can be controlled by a personal computer connected to one of the indicator communication ports. Control is provided by a set of commands that can simulate front panel key press functions, return and change setup parameters, and perform reporting functions.
Page 154: Reporting Commands
DUMPVERSIONS Returns the versions of all files, software and installed option cards. Table 15-2. Reporting Commands 15.3 Clear and Reset Commands The following commands can be used to clear and reset the 1280: Command Function PCLR Program Clear – erases the loaded user program (setup mode only).
Page 155: Parameter Setting Commands
SC.SMPRAT#n Scale A/D sample rate. 60HZ, 100HZ, 120HZ, 200HZ, 240HZ, 400HZ, 480HZ, 800HZ, 960HZ SC.PWRUPMD#n Power up mode GO, DELAY SC.TAREFN#n Tare function BOTH, NOTARE, PBTARE, KEYED Table 15-4. Scales Commands © Rice Lake Weighing Systems ● All Rights Reserved...
Page 156 1280 Series Color Touchscreen Indicator Command Description Values 8888100, 8888200, 8888500, 8888810, 8888820, 8888850, 8888881, 8888882, 8888885, 888888.1, Primary units format (decimal point and display 888888.2, 888888.5, 88888.81, 88888.82, 88888.85, SC.PRI.FMT#n divisions) 8888.881, 8888.882, 8888.885, 888.8881, 888.8882, 888.8885, 88.88881, 88.88882, 88.88885, 8.888881, 8.888882, 8.888885...
Page 157 Multi-Interval/Range range 2 format – decimal 888888.2, 888888.5, 88888.81, 88888.82, 88888.85, SC.RANGE2.FMT#n point and display divisions 8888.881, 8888.882, 8888.885, 888.8881, 888.8882, 888.8885, 88.88881, 88.88882, 88.88885, 8.888881, 8.888882, 8.888885 Table 15-4. Scales Commands (Continued) © Rice Lake Weighing Systems ● All Rights Reserved...
Page 158: 1280 Calibration Using Serial Commands
For commands ending with “#n”, n is the scale number (1-8). Table 15-4. Scales Commands (Continued) 15.5 1280 Calibration using Serial Commands Use the following instructions to calibrate the 1280 using serial commands. For information on how to calibrate the 1280 using the front panel, see Section 4.2 on page The indicator must respond with OK after each step.
Page 159 TKIP, AES WIFI.CRYPTO_KEY Wi-Fi encryption key Up to 15 Alpha-numeric characters DIRECT.ENABLED Enable Wi-Fi Direct ON, OFF TCPC1.ECHO TCP Client 1 Echo OFF, ON Table 15-6. Ethernet TCP/IP and Wi-Fi Commands © Rice Lake Weighing Systems ● All Rights Reserved...
Page 160 1280 Series Color Touchscreen Indicator Command Description Values TCPC1.EOLDLY TCP Client 1 End-of-line delay 0-255 (in 0.1 sec intervals) TCPC1.IPADDR TCP Client 1 remote server IP Valid IP xxx.xxx.xxx.xxx* TCPC1.LINETERM TCP Client 1 line termination CR/LF, CR, ETX, EOT, FF TCPC1.NAME...
Page 161 (no characters) in order to not have a password. CFGPWD Configuration password 999999 is the rescue password, it will reset all parameters to faculty defaults. Do not use it as a password. Table 15-8. Feature Commands © Rice Lake Weighing Systems ● All Rights Reserved...
Page 162 1280 Series Color Touchscreen Indicator Command Description Values Up to 12 alphanumeric characters. Set as nothing SPPWD Setpoint password (no characters) in order to not have a password. Up to 12 alphanumeric characters. Set as nothing CALPWD Calibration password (no characters) in order to not have a password.
Page 163 Allow the manual clearing of the tare REG.MANUALCLEARTARE NO, YES value REG.MONORAIL Monorail mode NO, YES REG.TAREINMOTION Allow Tare in Motion NO, YES The Underload weight value in display REG.UNDERLOAD 1-9999999 divisions Table 15-9. Regulatory Commands © Rice Lake Weighing Systems ● All Rights Reserved...
Page 164 1280 Series Color Touchscreen Indicator Command Description Values Allow scale to be zeroed while in REG.ZEROINMOTION NO, YES motion SCRN.SAVE Enable screen saver ON, OFF SCRN.THRESH Screen saver weight threshold 0-1000 Screen saver activation time SCRN.TIME 10-120 (in seconds) Table 15-9. Regulatory Commands (Continued)
Page 165 Ticket header format strings See Section 7.0 on page 89 for information about demand HDRFMT2 print format strings. AUXFMT.FMT#nn Auxiliary ticket format AUXFMT.PORT#nn AUXFMT.PORT2#nn AUD.PORT Audit trail port AUD.PORT2 Table 15-11. Print Format Commands © Rice Lake Weighing Systems ● All Rights Reserved...
Page 166 1280 Series Color Touchscreen Indicator Command Description Values Example Scale Widget Command: WDGT#A=1,B,C,D,E,F,G,H<CR>  where – A: widget number; B: left; C: top; D: size 1-7;;  E: displayed 1-4; F: which screen 1-99; G: foreground color; H: background color.
Page 167: Weigh Mode Commands
Returns the tare weight in tertiary units XP#n Return probe temperature XPP#n Return probe primary temperature nnnnnnnnn UU Return probe secondary temperature XPS#n XPT#n Return probe tertiary temperature Table 15-16. Weigh Mode Commands © Rice Lake Weighing Systems ● All Rights Reserved...
Page 168: Batching Control Commands
The commands listed in Table 15-18 can be used to create and maintain databases in the 1280. Except for the DB.DELALL command, all of the database commands require an extension to identify the number of the database within the memory.
Page 169 Sending the DB.DATA command alone, without assigned data, returns the database contents: DB.DATA#n<CR> The 1280 responds with the entire contents of the database. Returned data is cell-delimited with the pipe character (ASCII 124) and row-delimited with carriage returns (ASCII 13).
Page 170 1280 Series Color Touchscreen Indicator , and elements repeat for each column in the database. <Column Name> <Data Type> <Data Size> follows the rules for alias names: 8 character maximum; must begin with an alpha character or an <Column Name>...
Page 171: Iqube2 Configuration Commands
EDP command, but in a specialized format. For a complete list of iQube2 commands, reference the iQube2 Manual (PN 67888). This is only valid for iQube2 configuration commands stored in the 1280 and is not direct a real-time pass through Note connection to the iQube2.
Page 172: Specifications
1280 Series Color Touchscreen Indicator 16.0 Specifications Power AC Line Voltages 100-240 VAC (Range 85-265 VCA) Frequency 50 or 60 Hz Power Consumption 60 Watts Power DC Line Voltages 11-30 VDC (Range 9-36 VDC) Power Consumption 60 Watts Scale Card Specifications Excitation Voltage 10 ±...
Page 173 500 NIT – Standard 1000 NIT – Viewable Outdoors 12 inch 1280 x 800 Resolution White LED Backlight 1500 NIT – Standard Keyboard 22-key membrane panel, tactile feel Touchscreen 5-wire resistive © Rice Lake Weighing Systems ● All Rights Reserved...
Page 174 1280 Series Color Touchscreen Indicator Memory Onboard 8GB eMMC (system use),1GB DDR3 460 MB onboard database storage Micro SD Card Up to 32 GB Environmental Operating Temperature Legal 14 to 104°F (–10 to +40°C) Industrial -4 to 131°F (–20 to +55°C)
Page 176 Speciﬁcations subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319 www.ricelake.com...

Rice Lake 1280 Technical Manual

1 Introduction

2 Installation

3 Configuration Menu

4 Scale Configuration

5 Communications

6 Features

7 Formats

8 Digital I/O

9 Analog Output

10 Setpoints

11 Diagnostics

12 Option Cards

13 Importing/Exporting

14 Display Editor

15 EDP Commands

16 Specifications

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rice Lake 1280

Summary of Contents for Rice Lake 1280

Table of Contents
