1.5

General Electrical and Facility Requirements

Machine Model
1624R, 2525, 2550 Router with T-Slot
Table
With Engraving Head
With High Frequency Router Head
2550 Router with Vacuum Table
With Engraving Head
With High Frequency Router Head
Optional Equipment
Engraving Chip Removal System
Router Extraction System
Optional Equipment Requiring
Compressed Air Supply
UNIST Misting System
NSK 50,000 RPM Spindle
NOTE: In addition to the above requirements, a standard outlet is required for the computer.
© 2019 Vision Engraving Systems
Requirements
One 110 VAC 15 Amp
OR One 220 VAC 10 Amp Single Phase
One 110 VAC 15 Amp
OR One 220 VAC 10 Amp Single Phase (Vision controller)
AND One 220 VAC 30 Amp Single Phase (3 HP router)
One 110 VAC 15 Amp
OR One 220 VAC 10 Amp Single Phase (Vision controller)
AND One 220 VAC 20 Amp Single Phase (vacuum pump)
One 110 VAC 15 Amp
OR One 220 VAC 10 Amp Single Phase (Vision controller)
AND One 220 VAC 30 Amp Single Phase (3 HP router)
AND One 220 VAC 20 Amp Single Phase (vacuum pump)
Required in addition to the machine power above:
One 110 VAC 15 Amp OR One 220VAC 10 Amp
One 220 VAC 20 Amp Single Phase
Required in addition to the machine power above:
Clean Dry Compressed Air Supply 60 - 90 PSI
One 110 VAC 15 Amp OR One 220 VAC 10 Amp Single
Phase AND Clean Dry Compressed Air Supply 1 SCFM
@ 40 PSI
