- Page 1 INSTALLATION INSTRUCTIONS PART#: 8D091016SS\8D091016A REAR BUMPER GUARD FOR TOYOTA HIGHLANDER W/O HITCH 08-09...
- Page 2 REAR BUMPER GUARD FOR TOYOTA HIGHLANDER W/O HITCH 08-09 PARTS LIST: 1 Rear Bumper Guard 4 10-1.25mm x 35mm Hex Head Bolts (fine thread) 1 Driver/Left Mounting Bracket 4 10mm Lock Washers 1 Passenger/Right Mounting Bracket 4 10.2mm ID x 26mm OD x 3.1mm Flat Washers 4 12-1.75mm x 35mm Hex Head Bolts 4 12mm Lock Washers 4 12mm Hex Nuts...
- Page 3 REAR BUMPER GUARD FOR TOYOTA HIGHLANDER W/O HITCH 08-09 PROCEDURE: 1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION. 2. IMPORTANT! Due to the passenger side mounting location of the Frame Bracket being so close to the muffler, before starting the installation allow muffler to cool.
- Page 4 REAR BUMPER GUARD FOR TOYOTA HIGHLANDER W/O HITCH 08-09 Fig 1 Fig 2 Fig 3 Fig 4 Page 3 of 3...
