- Page 1 INSTALLATION INSTRUCTION Rear Bumper Guard Single Tube with Step Pad 2015 2021 Chevrolet Suburban 2015 2019 Chevrolet Tahoe 2015 2018 GMC Yukon PART # 8GMTASS-1...
- Page 2 Attention: ⚫ Please read this installation menu before installing this part. Protect your car properly in case there is any scratch might have. ⚫ You may need to periodically to re-tighten all hardware for safety use after installation. ⚫ Installation pictures are only for your reference, there might be some differences between pictures and real parts but no affect for your fitting.
- Page 3 INSTALLATION PROCEDURES Step 1: Refer to Part List to check if all hard ware are included. Step 2: Refer to the following picture to install left and right brackets. Pic 1 Factory Hard Ware M12x35 Hexagon Bolt φ12x30x3.0 Large Washer φ12 Spring Washer M12 Hexagon Nut Step 3: Install the rear guard on the brackets and then adjust them to the proper positions.
