INSTALLATION GUIDE
BNC-2142 D
BNC A
DAPTER
Introduction
What You Need to Get Started
natinst.com ™ and National Instruments ™ are trademarks of National Instruments Corporation. Product and company names mentioned herein
are trademarks or trade names of their respective companies.
322545A-01
ESKTOP AND
This installation guide describes how to install and configure your
BNC-2142 accessory.
The BNC-2142 is a desktop and DIN rail-mountable BNC adapter you
can connect directly to dynamic signal acquisition (DSA) devices. It
includes six BNC connectors for signal connections, and a 68-pin
I/O connector for connection to the PCI-445x and NI 455x DSA devices.
The BNC-2142 is ideal for simplifying connections between your
measurement apparatus and your DSA device in laboratory, test, and
production environments.
To set up and use your BNC-2142 accessory, you will need the following:
BNC-2142 BNC Adapter
BNC-2142 Desktop and DIN Rail-Mountable BNC Adapter
Installation Guide
PCI-445x or NI 455x device
SHC68-C68-A1 analog cable
Detailed specifications for the BNC-2142 are in the Specifications section
later in this guide.
© Copyright 1999 National Instruments Corp. All rights reserved.
DIN R
-M
AIL
OUNTABLE
September 1999
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for National Instruments BNC-2142
Summary of Contents for National Instruments BNC-2142
- Page 1 Detailed specifications for the BNC-2142 are in the Specifications section later in this guide. natinst.com ™ and National Instruments ™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies.
- Page 2 All BNC connectors on the BNC-2142 are single-ended only. The outer shells of the BNC connectors are in direct contact with the metal enclosure of the BNC-2142, which is grounded via the SHC68-C68 analog cable shield to the chassis ground of your computer.
- Page 3 Do not connect the BNC-2142 to any device other than the National Instruments PCI-445x and NI 455x DSA devices. Doing so can damage the BNC-2142, the DSA device, or host computer. National Instruments is not liable for damages resulting from these connections.
- Page 4 Consult your computer user manual or technical reference manual for specific instructions and warnings. Note You can either place the BNC-2142 on a workbench near the host computer or use the available DIN rail-mount kit. Connect the BNC-2142 to your DSA device.
- Page 5 Specifications This section lists the specifications of the BNC-2142. These specifications are typical at 25 °C unless otherwise specified. Electrical Max input voltage ........Each input should remain within ±42.4 V (30 V ) of ground Field connection........6 BNC connectors...
