Kraus KBU10 Installation Manual
Stainless steel undermount kitchen sink
Hide thumbs
Also See for KBU10:
- Installation manual (31 pages) ,
- Installation manual (16 pages) ,
- Installation manual (33 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Kraus KBU10
Summary of Contents for Kraus KBU10
- Page 1 KBU10 / KBU11 / KBU12 / KBU14 / KBU15/ KBU16 / KBU17 / KBU21 / KBU22 / KBU23 / KBU24 / KBU25 / KBU26 / KBU27 / KBU28 / KBU29 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. January 11, 2018...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep teh box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Toll-Free: 800-775-0703 or Customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. -
Page 4: Tools You Will Need
Silicone Adhesive Jig Saw Scissors Phillips Screwdriver Putty Knife Tape Measure Pencil Screwdriver NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Undermount sinks with countertop materials other than wood, marble, or granite Dimensions × × × × 21”... - Page 5 Dimensions × × × × 29 1/2” 750mm 13” 17 3/4” 31 1/2” 330mm 450mm 800mm 15” 19 3/4” 381mm 500mm KBU14 KBU15 KBU16 31 1/2” x 18 3/8” x 10” 19 3/4” x 20 1/2” x 9” 15” x 18 1/2” x 7” Min Cabinet Size: 36”...
- Page 6 KBU23 KBU23 Dimensions KBU24 KBU24 11 3/8” 17 3/4” 15 3/4” 13” 290mm 450mm 17 3/4” 10 1/2” 400mm 330mm 15 3/4” 11 3/8” 17 3/4” 266mm 13” 450mm 17 3/4” 10 1/2” 32 3/8” 311/2” 32” 266mm 450mm 400mm 330mm 290mm 450mm...
- Page 7 (Negative, Positive, or Flushed Reveal) 3/8“ Positive Reveal 3/8“ Positive Reveal 3/8“ Positive Reveal Zero Reveal Flushed/Zero Reveal Flushed/Zero Reveal Flushed/Zero Reveal 1/8“ Negative Reveal ative Reveal KRAUS Recommended Installation Type 1/8“ Negative Reveal 3/8”POSITIV 3/8”POSITIVE 1/8“ Negative Reveal 3/8”POSITIV 1/8”NEGATI 3/8”POSITIV 1/8”NEGATIVE 1/8”NEGATI FLUSHED/ZERO 1/8”NEGATI...
- Page 8 Step1 2. Position Template • Check the cut-out template against the actual sink to ensure a proper sized cut-out • Place the cut-out template in the desired location on the countertop NOTE: Make sure clearance is suitable for backsplash, faucet, and plumbing for the sink Step2 3.
- Page 9 4. Cut Countertop • Cut the opening in the countertop by carefully following the traced line Step3 Please use the appropriate saw that best fits your countertop NOTE: material...
- Page 10 Determine location for mounting brackets; space 5. Set up Mounting Brackets 3/8”POSITIVE 1/8”NEGATIVE • Turn countertop over and align sink with countertop. Decide location for mounting brackets Centerline • Mounting holes should be ½” from edge of sink Step5 Step6 1/2"...
- Page 11 Step6 7. Install Anchors • Insert anchors into drilled holes and lightly tap with a hammer until flush Step7 8. Secure Sink to Countertop • Use a bead of silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the cutout in the countertop. Place sink over cutout hole and press firmly...
-
Page 12: Attach Mounting Hardware
9. Attach Mounting Hardware Step8 • Attach mounting hardware to secure bowl. Remove excess sealant from inside lip • Allow sealant to set for 30 – 60 minutes Use acetone or rubbing alcohol to remove any excess sealant NOTE:... - Page 13 10. Install Plumbing Fixtures • Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer’s instructions Step9 • Run water into sink and check for leaks...
