Introduction
This document describes the electronic specifications, RF specifications, interfaces, mechanical
characteristics and testing results of the SIMCom MODULE. With the help of this document and
other software application notes/user guides, users can understand and use MODULE to design and
develop applications quickly.
1.1

Product Outline

Aimed at the North American market, the MODULE support GSM, WCDMA, LTE-TDD and
LTE-FDD. Users can choose the MODULE according to the wireless network configuration. The
supported radio frequency bands are described in the following table.
Table 1: Module frequency bands
Standar
d
Category
With a small physical dimension of 30*30*2.9 mm and with the functions integrated, the
MODULE can meet almost any space requirement in users' applications, such as smart phone,
PDA, industrial handheld, machine-to-machine and vehicle application, etc.
1.2

Hardware Interface Overview

The interfaces are described in detail in the next chapters include:
Power Supply
●
USB2.0 Interface
●
UART Interface
●
MMC/SD Interface
●
SDIO Interface
●
USIM Interface
●
SPI Interface
●
SIM7600NA_user manual _V1.00
SIM7600NA
Frequency
FDD B2 √
FDD B4 √
FDD B5 √
FDD B12 √
FDD B13
√
FDD B14 √
FDD B25 √
FDD B26
√
FDD B71 √
FDD B66 √
TDD B41 √
CAT1
8
