Recommended USIM Card Holder
It is recommended to use the 6-pin USIM socket such as C707 10M006 512 produced by
Amphenol. User can visit http://www.amphenol.com for more information about the holder.
Table 14: Amphenol USIM socket pin description
Pin Signal
C1 USIM_VDD
C2 USIM_RST
C3 USIM_CLK
C5 GND
C6 VPP
C7 USIM_DATA
SIM7600NA_user manual _V1.00
Figure 224: Amphenol SIM card socket
Description
USIM Card Power supply.
USIM Card Reset.
USIM Card Clock.
Connect to GND.
NC
USIM Card data I/O.
39
