RF Specifications
4.1

GSM/UMTS/LTE RF Specifications

Table 24: Conducted transmission power
Frequency
LTE-FDD B2
LTE-FDD B4
LTE-FDD B5
LTE-FDD B12
LTE-FDD B13
LTE-FDD B14
LTE-FDD B25
LTE-FDD B26
LTE-FDD B71
LTE-FDD B66
LTE-TDD B41
Table 25: Operating frequencies
Frequency
The LTE Operating frequencies are shown in the following table 26.
Note: Operating frequencies of LTE TDD B41 for the MODULE is 200MHz BW, 2496～2690 MHz
GPS
GLONASS
BD
Table 26: E-UTRA operating bands
E-UTRA Uplink (UL) operating
Operating Band band
2 1850~1910 MHz
4 1710~1755MHz
5 824～849 MHz
12 699~716MHz
13 777~787MHz
14 788~798MHz
25 1850~1915MHz
26 814~849MHz
71 663~698MHz
66 1710~1780MHz
41 2496~2690 MHz
SIM7600NA_user manual _V1.00
Power
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
23dBm +/-2.7dB
Receiving
1574.4 ～1576.44 MHz
1598 ～1606 MHz
1559 ～1563 MHz
Downlink (DL) operating
band
1930~1990 MHz
2110~2155MHz
869～894MHz
728~746MHz
746~757MHz
758~768MHz
1930~1995MHz
859~894MHz
617~652MHz
2110~2200MHz
2496~2690 MHz
49
Smart Machine Smart Decision
Min.
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
<-40dBm
Transmission
-
-
Duplex
Mode
FDD
FDD
FDD
FDD
FDD
FDD
FDD
FDD
FDD
FDD
TDD
