Functional Overview

Table 2: General features
Feature
Power supply
Power saving
Radio frequency bands
Transmitting power
Data Transmission
Throughput
Antenna
GNSS
SMS
USIM interface
USIM application toolkit
Phonebook management
Audio feature
UART interface
MMC/SD
SDIO
USB
Firmware upgrade
SIM7600NA_user manual _V1.00
Implementation
Single supply voltage 3.4~4.2V, Recommend supply voltage 3.8V
Current in sleep mode : <5mA
Please refer to the table 1
LTE power class: 3 (0.25W)
LTE CAT 1: 10 Mbps(DL)
5 Mbps(UL)
LTE CAT 4 :150 Mbps (DL)
50 Mbps (UL)
LTE main antenna.
LTE auxiliary antenna
GNSS antenna
GNSS engine (GPS,GLONASS and BD)
Protocol: NMEA 0183
MT, MO, CB, Text and PDU mode
SMS storage: USIM card or ME(default)
Transmission of SMS alternatively over CS or PS.
Support identity card: 1.8V/ 3V
Support SAT class 3, GSM 11.14 Release 98
Support USAT
Support phonebook types: DC,MC,RC,SM,ME,FD,ON,LD,EN
Support PCM interface
Only support PCM master mode and short frame sync, 16-bit linear data
formats
A full modem serial port by default
Baud rate: 300bps to 4Mbps(default:115200bps)
Auto baud rate: 9600,19200,38400,57600,115200bps
Can be used as the AT commands or data stream channel
Support RTS/CTS hardware handshake
Multiplex ability according to GSM 07.10 Multiplexer Protocol
Support MMC and SD cards with 2.85 V on SD port
Support SDIO with 1.8 V only on SDIO port
USB 2.0 high speed interface, Can used be send AT command, Software
update, GNSS NMEA,USB voice function etc.
Firmware upgrade over USB interface or FOTA
11
