*Note: These parameters are for digital interface pins, such as SPI, GPIOs (NETLIGHT,
FLIGHTMODE, STATUS, USIM_DET, SD_DET), SDIO, I2C, UART, PCM, COEXn, and
BOOT_CFG0.
The operating temperature of MODULE is listed in the following table.
Table 34: Operating temperature
Parameter
Normal operation temperature
Extended operation temperature*
Storage temperature
*Note: Module is able to make and receive voice calls, data calls, SMS and make GSM/
UMTX/LTE traffic in -40℃ ~ +85℃. The performance will be reduced slightly from the 3GPP
specifications if the temperature is outside the normal operating temperature range and still
within the extreme operating temperature range.
5.3
Operating Mode
5.3.1
Operating Mode Definition
The table below summarizes the various operating modes of MODULE product.
Table 35: Operating mode Definition
Mode
GSM /UMTS/LTE
Sleep
GSM/UMTS/LTE
Idle
GSM/UMTS/LTE
Talk
GPRS/EDGE/
UMTS/LTE Standby
GPRS/EDGE/
UMTS/LTE
Data transmission
Minimum functionality
mode
SIM7600NA_user manual _V1.00
Min.
-30
-40
-45
Function
In this case, the current consumption of MODULE will be reduced to
the minimal level and the MODULE can still receive paging message
and SMS.
Software is active. Module is registered to the network, and the
MODULE is ready to communicate.
Connection between two subscribers is in progress. In this case, the
power consumption depends on network settings such as DTX off/on,
FR/EFR/HR, hopping sequences, and antenna.
Module is ready for data transmission, but no data is currently sent or
received. In this case, power consumption depends on network
settings.
There is data transmission in progress. In this case, power
consumption is related to network settings (e.g. power control level);
uplink/downlink data rates, etc.
AT command "AT+CFUN=0" AT+CSCLK=1 can be used to set the
MODULE to a minimum functionality mode without removing the
power supply. In this mode, the RF part of the MODULE will not
work and the USIM card will not be accessible, but the serial port and
55
Smart Machine Smart Decision
Typ.
Max.
25
80
25
85
25
+90
2020-1-7
Unit
℃
℃
℃
