Table 27: Conducted receive sensitivity
Frequency
LTE FDD/TDD
Table 28: Reference sensitivity (QPSK)
E-UTR 1.4 MHz
A band Standard
2 -102.7
4 -104.7
5 -103.2
12 -101.7
13
14
25 -101.2
26 -102.7
71
66 -104.7
41 -
4.2

GSM /UMTS/LTE Antenna Design Guide

Users should connect antennas to MODULE's antenna pads through micro-strip line or other types
of RF trace and the trace impedance must be controlled in 50Ω. SIMCom recommends that the
total insertion loss between the antenna pads and antennas should meet the following requirements:
Table 29: Trace loss
Frequency
700MHz-960MHz
1710MHz-2170MHz
2300MHz-2650MHz
To facilitate the antenna tuning and certification test, a RF connector and an antenna matching
circuit should be added. The following figure is the recommended circuit.
SIM7600NA_user manual _V1.00
Receive sensitivity(Typical)
See table 28.
3 MHz 5 MHz
Standard Standard
-99.7 -98
-101.7 -100
-100.2 -98
-98.7 -97
-97
-97
-98.2 -96.5
-99.7 -97.5
-97.2
-101.7 -100
- -99
Loss
<0.5dB
<0.9dB
<1.2dB
50
Smart Machine Smart Decision
Receive sensitivity(MAX)
3GPP
10 MHz 15 MHz
Standard Standard
-95 -93.2
-97 -95.2
-95
-94
-94
-94
-93.5 -91.7
-94.5 -92.7
-94.2 -92
-97 -95.2
-96 -94.2
2020-1-7
20 MHz Duplex
Standard Mode
-92 FDD
-94 FDD
FDD
FDD
FDD
FDD
-90.5 FDD
FDD
-87.5 FDD
-94 FDD
-93 TDD
