ViewEra V200T User Manual

Tft-lcd tv monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TFT-LCD TV MONITOR
V200T
USER' S MANUAL
www.viewera.com
Rev 1.1
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V200T and is the answer not in the manual?

Questions and answers

Related Manuals for ViewEra V200T

Summary of Contents for ViewEra V200T

  • Page 1 TFT-LCD TV MONITOR V200T USER’ S MANUAL www.viewera.com Rev 1.1 Page 1...

  • Page 2: Table Of Contents

    Content 1. Introduction Product Description ………...………...…... Package Contents……………...…...………... Product Features………………….………..………………….. Screen Cleaning Techniques ……….………..……………..… Additional ……………………….………………………….. 2. Control Functions Front Panel Controls .………………………………………... OSD Controls ……………….…….…….…………………..… 3. Input Diagrams……………………………………………….. 4. Setup ……………………………..………………………….… 5. Viewing Angles………………….…….…….…………………. 6. Product Specifications 7. Display Modes……………….….……………………………… 8.

  • Page 3: Introduction Product Description

    1. Introduction 1.1 Product Description Congratulations on your purchasing ViewEra LCD monitor. It incorporates high quality display into a small light weighted module. It has power-saving capabilities and emits no radiation. You will certainly benefit from this monitor in lots of ways;...

  • Page 4: Product Features

    1.3 Product Features 1. High contrast color TFT LCD display support resolution up to 20.1" SVGA 800 ×600@75Hz 2. Compatible with IBM VGA, IBM SVGA, and Macintosh standards. 3. Imbedded audio system provides sound performance. 4. AV-In and S-video, Component (Option) 5.

  • Page 5: Additional

    1.5 Additional Read all of these instructions and save them for later use. Follow all warnings and instructions on the product. 1. Product  Do not cover block the vent holes in the case.  Do not insert sharp objects or spill liquid into the LCD monitor through cabinet slots.

  • Page 6: Front Panel Controls

    4. Power and extension cords  Do not allow anything to rest on the power cord.  Do not locate this product where persons will walk on the cord.  Use the proper power cord with correct attachment plug type. If the power source is 120V AC, use a power cord that has UL and C-UL approvals, If the power source is a 240V AC supply, use the tandem (T blade) type attachment plug with ground conductor power cord that meets the respective European...

  • Page 7: Control Functions

    2. Control Functions 2.1 Control Button Front View 【PC Mode】 1. Source Select : 2. NO Function 3. Auto Adjust : 4. OSD menu / select : 5. Adjust (decrease －) : 6. Adjust (increase ＋) : 7. Mute : 8.
  • Page 8 Monitor Function Selection Menu： Auto Select this function to obtain the best display efficiency. Brightness： Adjust the brightness using ＋ and － button. Contrast： Adjust the contrast using ＋ and － buttons. Adjust the clock using ＋ and － buttons. Clock：...
  • Page 9 Color Temperature and RGB Adjusting Menu ： Color Temperature Red： Green： Blue： Color Temperature Select. Red range adjustment Green range adjustment Blue range adjustment Page 9...
  • Page 10 Tools Menu： Volume： Adjust the volume using ＋ and － buttons. Mute： Mute function. Reset： Reset function. P C →A V →S -V i d e o → Y , Cb, Cr selection Input： Page 10...
  • Page 11 OSD Function Selection Menu： Exit OSD： Exit the OSD function selection menu. OSD-H- Position： Pressing ＋ moves the OSD to right ; Pressing － moves the OSD menu to left. OSD-V-Position： Pressing ＋ moves the OSD menu upward; Pressing － moves the OSD menu downward.
  • Page 12 2.2 Control Button Front View 【AV、Mode】 1. Source Select : Direct select the input signal PC / AV / S-Video / YCbCr . 2. NO Function: 3. NO Function: 4. OSD menu / select : 5. Adjust (decrease －) : 6.
  • Page 13 Monitor Function Selection Menu： Brightness： Adjust the brightness using ＋ and － button. Contrast： Adjust the contrast using ＋ and － buttons. Saturation： Adjust the Saturation using ＋ and － buttons. Adjust the Tint using ＋ and － buttons. TINT： Sharpness：...
  • Page 14 Tools Menu： Volume： Adjust the volume using ＋ and － Mute： Mute function. Reset： Reset function. P C →A V →S -V i d e o →Y C b C r s e l e c t . Input： buttons. Page 14...
  • Page 15 OSD Function Selection Menu： Exit OSD： OSD -H- Position： Pressing ＋ moves the OSD to right ; OSD-V-Position： Pressing ＋ moves the OSD menu OSD DURATION： Set the OSD display time. LANGUAGE： Exit the OSD function selection menu. Pressing － moves the OSD menu to left.

  • Page 16: Input Diagrams

    3. Inputs Diagram Inputs 【AV】 (1) (2) (3) (4) 【1】DC IN： 【2】AV IN： 【3】S-VIDEO IN： 【4】LINE OUT： 【5】RCA JACK： AUDIO IN 【6】VGA IN (PC IN)：Connect to PC VGA D-Sub signal. 【7】Component IN： Component in Y, Cb, Cr. DC power input from adaptor. RCA jack AV signal input.

  • Page 17: Setup

    4. Setup Electrical Connection Please follow the instruction below to properly connect the LCD monitor to external electrical source. 1. Connect the female-end of the power cable to the transformer. Connect the male-end of the power cable to the wall outlet or extension cable. 2.

  • Page 18: Viewing Angles

    5. Viewing Angles Tilting For better viewing angle, you may tilt the LCD monitor forwards(up to 10 degrees) or backwards (up to 25 degrees). Down：10 Up：25 Page 18...

  • Page 19: Product Specifications

    6. Product Specifications 20.1” Product Specification Type Spec LCD Display 20.1" Active matrix TFT LCD panel Pixel Pitch 0.51(H) × 0.51(V) mm Max. 800(H) × 600 (V) SVGA Resolution Set Size 595(H) × 430(W) × 190(D) mm Pack Size 695(H) × 675(W) × 275(D) mm Contrast Ratio 500:1 Brightness...

  • Page 20: Display Modes

    9. Warranty and Service Information Warranty ViewEra warrants the V200T TFT-LCD TV monitor for three years for parts and labor, one year for LCD panel and back light from the date of purchase. For detail warranty information, please refer to our website.

  • Page 21: Windows Setup

    10. Windows setup For the best view, please set up the monitor type in Windows as follows: Control Panel > Display > Settings > Advanced > List All Modes For 800 × 600, please set to “ SVGA 800×600 @60 Hz” Page 21...

  • Page 22: Wall Mount Installation

    11. Wall Mount Installation 11.1 Remove the Base by un-installing the 4 screws and pull the Base from the Monitor. 11.2 Install the Wall-mount kit by securing the 4 screws with the bracket pointing in downward direction as shown in the picture. 11.3 Face the Wall mount metal bracket in accordance with the direction shown for proper mounting with the monitor.
