Important Safety Instructions Thank you for selecting ViewEra's high performance, multi-function LCD monitor . To ensure your safety and extend product life, please read and follow the instructions before using it, and comply with the following safety cautions: 1 To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor case.
Page 5
surface .Don't place the machine near or over heat source or place in built-in installation. 141 Unplug your monitor from the electric outlet before any service is performed. . 15 Don't use solvents, like ethyl alcohol, acetone, ethanol and hexane to clean the surface of LCD screen. 16 Don't place the machine near water source such as bathtub, washbowl, sink, laundry tub, swimming pool, etc.
1. INTRODUCTION General information HDMI supports 1080 p/i, 720 p, 576 p/i, 480 p/i video signal. Support HDCP (High-bandwith Digital Content Protection) Featured built-in speakers, they will give you audio enjoyment and save your space. With multiple connectors, you may directly connect it to your DVD player, VCR or game console, etc. The Components Video input connectors let you enjoy beautiful image quality.
2. Package Contents Unpack the package and check if you have the following items. TFT-LCD monitor (19 inch for V193 series; 22 inch for V220 series) VGA signal cable Audio cable Power cord Remote control ...
3. Installation Note: Disconnect the power plug while installing the monitor. Plug the power plug after cable connections are done. You can find more connectors when you take off the cover board on the left of the rear cover [Fig.2] Component connection [Fig.1] Connect Y, Pb/Cb, Pr/Cr Video Out on a video player to the monitor Y, Pb/Cb,...
Page 9
Power Cord Connection Plug one end of the power cord into the monitor power jack and then plug the other end into the outlet. Earphone connection [Fig.2] When you enjoy music with earphone, you can insert the plug of earphone into earphone jack on the monitor. Then the monitor will automatically mute the speakers.
4. Front Panel Control Keys 1) Power Indicator 2) IR Sensor: It is to receive signals from remote contorl. 3) Signal Source: press this key to enter the menu of signal source and choose signal source. 4) Menu: press this key to enter main menu 5) CH+/CH-: Press these two keys to adjust the options you need under OSD operation.
5. Remote Control POWER MUTE Power Numerical key SMART S SMART P Smart sound MENU SOURCE Menu Volume INFO 16:9 Info Time DCDi COLOR AUDIO DCDi(optional) Color(optional) Remote Control Mute Power Turn on or standby Info System information display switch Mute sound;...
6. Basic Operations Power On Plug power cord into the outlet and press '' control to turn on the monitor. Signal Source Selection Press ''SOURCE'' key either on the remote control or on the front panel. will be displayed on the screen. Then press ''Up/Down'' key on remote control or "CH+/CH-" key on the front panel to choose the signal source such as TV(optional) AV, S-VIDEO, YPBPR, PC, HDMI.
OSD Menu Press ''MENU'' key on the remote control or on the front panel. The monitor will display the main menu. 1. Press ''Left/Right'' key on the remote control or ''VOL+/VOL-''key on the front panel to select the submenu, which includes PICTURE SOUND ADVANCE SYSTEM TV-CHANNEL (optional).
Picture Adjustment Select to enter the Picture Adjustment submenu. Press "Up/Down" key on the remote control or the key " CH+/CH-" on the front panel to choose what you need. Press the "Left /Right "key on the remote control or the" VOL+/VOL-" key on the front panel to adjust analog value or state (see below table).
Page 15
Option Function PICTURE MODE Select picture mode Adjust the contrast of whole CONTRAST picture Adjust brightness and blackness BRIGHTNESS of whole picture Adjust the hue of whole picture Adjust the saturation of whole SATURATION picture Adjust the sharpness of whole SHARPNESS picture Adjust the black light of whole...
Page 16
Sound Adjustment Select to enter the SOUND submenu. Press "Up/Down" key on the remote control or the key "CH+/CH-" on the front panel to choose what you need. Press the "Left / Right" key on the remote control or the "VOL+/VOL-" key on the front panel to adjust analog value or state (see below table).
Page 17
Advance Settings Select to enter the ADVANCE submenu. Press "Up/Down"key on the remote control or the key "CH+/CH-" on the front panel to choose what you need. Press the "Left / Right"key on the remote control or the " VOL+/VOL-" key on the front panel to adjust analog value or state (see below table).
System Settings Select to enter the SYSTEM submenu. Press "Up/Down" key on the remote control or the key "CH+/CH-" on the front panel to choose what you need. Press the "Left / Right"key on the remote control or the " VOL+/VOL-" key on the front panel to adjust analog value or state (see below table).
