ViewEra V150 User Manual

15"/17" tft-lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
15" /17" TFT-LCD MONITOR
V150/ V171
USER' S MANUAL
Rev. 1.1
www.viewera.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V150 and is the answer not in the manual?

Questions and answers

Related Manuals for ViewEra V150

Summary of Contents for ViewEra V150

  • Page 1 15” /17” TFT-LCD MONITOR V150/ V171 USER’ S MANUAL Rev. 1.1 www.viewera.com...

  • Page 2: Table Of Contents

    CONTENTS 1. Introduction Product Description ... Package Contents Product Features …... Screen Cleaning Techniques Additional 2. Control Functions ……………………………………………………...….. 3. Input Diagrams ... 4. Installation... 5. Product Specifications... 6. Dead Pixel Policy……... 7. Warranty and Customer Service ... 8. Windows Setup ... 9.

  • Page 3: Introduction

    This LCD monitor incorporates color active matrix thin-film-transistor (TFT) liquid crystal display to provide superior display performance. Its maximum resolution is 1024x768(SVGA) for V150, 1280 x 1024 (SXGA) for V171. The V150/V171 also includes built-in speakers, one touch image adjusting and OSD (On Screen Display) controls.

  • Page 4: Product Features

    Product Features  High brightness, high contrast ratio and quick response tiem.  Built-in speakers.  Power management system conforms to VESA DPMS standard.  Support Plug & Play, no need for driver installation.  Advanced OSD controls for picture quality adjustment. ...

  • Page 5: Additional

    Additional  Read all of these instructions and save them for later use.  Follow all warnings and instructions on the product.  Product ♦ Do not cover block the vent holes in the case. ♦ Do not insert sharp objects or spill liquid into the LCD monitor through cabinet slots. They may cause accident fire, electric shock or failure.
  • Page 6  Power and extension cords ♦ Do not allow anything to rest on the power cord. ♦ Do not locate this product where persons will walk on the cord. ♦ Use the proper power cord with correct attachment plug type. If the power source is 120V AC, use a power cord that has UL and C-UL approvals.

  • Page 7: Control Functions

    2. Control Functions a.【PC,Audio,DVI】 Control Button Front View (Model : V150、V171 series) ﹝2﹞ ﹝5﹞ ﹝1﹞ ﹝3﹞ ﹝4﹞ 1. Power switch Power switch & LED. 2. Auto adjust Press this button to obtain the best display quality. 3. Adjust (decrease －) This button is used to decrease the value of selected function.
  • Page 8 OSD Controls Monitor Function Selection Menu： Press this button to obtain the best display quality. AUTO ADJUST Adjust the brightness by using ＋ and － buttons. BRIGHTNESS Adjust the contrast by using ＋ and － buttons. CONTRAST Adjust the clock by using ＋ and － buttons. CLOCK Adjust the phase by using ＋...
  • Page 9 Tools Menu： Adjust the volume by using ＋ and － buttons. VOLUME MUTE Speakers are inactive. RESET Recall factory settings Page 7...
  • Page 10 Color Temperature and RGB Adjusting Menu： Adjust the color temperature of the display. COLOR TEMP. Adjust red pixel luminance. Adjust green pixel luminance. GREEN Adjust blue pixel luminance. BLUE Page 8...
  • Page 11 OSD Function Selection Menu： Exit the OSD menu. EXIT OSD Press ＋ to move the OSD menu to right. OSD– H– POSITION Press － to move the OSD menu to left. Press ＋ to move the OSD menu upward. OSD– V– POSITION Press －...

  • Page 12: Input Diagrams

    3. Input Diagrams Inputs 【PC】 This is for connecting the adapter DC 12V/3A (4A) cable. 【1】DC IN This can be connected to the audio-out jack of any sound card. 【2】LINE IN 【3】 VGA (Analog) IN This can be connected with the D-sub 15 pin signal connector. Page10...

  • Page 13: Installation

    4. Installation Electrical Connection Please follow the instruction below to properly connect the LCD monitor to external electrical source. 1. Connect the female-end of the power cable to the transformer. Connect the male-end of the power cable to the wall outlet or extension cable. 2.

  • Page 14: Product Specifications

    Front control OSD menu Brightness, Contrast, Auto Adjustment, Clock, Phase, Language and Reset Power adapter AC Input: 100-240V~1.8A, 50-60Hz; DC Output : 12V/ 3.0A Weight Net：3.55Kgs , Gross： 5.25Kgs 375(H) x 360(V) x 185(D) mm Set Size V150 Page 12...
  • Page 15 V150 Display Modes Mode Resolution 640 × 350 640 × 480 640 × 480 640 × 480 720 × 400 800 × 600 800 × 600 800 × 600 800 × 600 1024 × 768 1024 × 768 1024 × 768 H Freq (KHz) 31.469...
  • Page 16 b. 17〞LCD monitor. Model Spec LCD Display 17” Active matrix TFT LCD panel Pixel Pitch 0.264(H) x 0.264(V) mm Max. Resolution 1280(H) x 1024(V) SXGA Contrast Ratio 400 : 1 Brightness 250 cd/m Response Time 25 ms Display Color 16.777M Viewing Angle (H/V) 140°...
  • Page 17 V171 Display Modes Mode Resolution 640 × 350 640 × 480 640 × 480 640 × 480 720 × 400 800 × 600 800 × 600 800 × 600 800 × 600 1024 × 768 1024 × 768 1024 × 768 1280 ×...

  • Page 18: Dead Pixel Policy

    6. Dead Pixel Policy Dead pixels on the TFT LCD panel are sometimes inevitable. ViewEra guarantees that the monitor will be replaced if the number of dead pixels on our monitor exceeds 5 pixels within the first year from the date of purchase.

  • Page 19: Windows Setup

    8. Windows setup For the best display quality, please set the monitor type in Windows. Control Panel > Display > Settings > Advanced > List All Modes For V150, please set to “ XGA 1024 × 768 @ 75Hz.” Page 17...
  • Page 20 For V171, please set to “ SXGA 1280 × 1024@75Hz.” Page 18...

  • Page 21: Trouble Shooting

    9. Trouble Shooting 1) Power on but no picture → Make sure the VGA cable is tightly connected from the video output connector on the video card to the video input connector on the monitor. → Make sure you are using the standard power adapter coming with the monitor. →...
  • Page 22 4) Display position is incorrect → U s e “ Auto Tuning” function to adjust image position on the OSD menu or you can hold button 2 for 3 seconds to do auto tuning. 5) Speakers have no sound → Ma k e s u r e t h e a u d i o c a b l e i s t i g h t l y c o n n e c t e d f r o m t h e a u d i o o u t p u t j a c k o n t h e P C t o t h e a u d i o i n p u t j a c k on the monitor.
  • Page 23 Boot the computer into VGA Mode (F8) [repeatedly] at startup. Go to “ Control Panel” , double click on “ Display” , click on the SETTINGS TAB, and click on the ADVANCED button. Then Click on the Adapter TAB, click “ List All Modes” and change the screen resolution to 1280x1024. (You can select 16 bit or 32 bit color which depends on your video card capability.) Select “...
