Display-It Desk
IMPORTANT SAFETY INSTRUCTIONS:
Please read all instructions carefully before assembling.
For your safety, assembly by two adults is recommended.
PARTS INCLUDED:
(A) Desk Top – 1pc
(B) Drawer Pedestal – 1pc
(C) Door Pedestal – 1pc
(D) Shelf – 1pc
(E) Keyboard Tray – 1pc
ASSEMBLY INSTRUCTIONS:
1. Insert the Shelf Support (S) into the pre-drilled holes inside the Door Pedestal (C). Place the Shelf (D) on
the Shelf Supports (S).
2. Pull out the bottom drawer by pressing the clips on both of the metal glides on the sides of the drawers to
release it from the Drawer Pedestal (B), as shown below. Place the File Grids (K) on the cut-outs of the
drawer. There are two positions. One is for legal size and the other is for letter size.
One Door Pedestal
Hardware Included with
Two Drawer Pedestal:
(F) Allen Key
– 1pc
(G) Bolt ¼" x 25mm
(H) Spring Washer
– 4pcs
(I) Flat Washer
– 4pcs
(J) Wooden Dowel
(K) File Grid
(L) Cable Clip
- 1pc
(M) Wood screw
3.5x15mm -1pc
www.pbteen.com
Hardware Included with
Desk Door Pedestal:
(N) Allen Key
– 4pcs
(O) Bolt ¼" x 25mm
(P) Spring Washer
(Q) Flat Washer
– 4pcs
(R) Wooden Dowel
2pcs
(S) Shelf Support
Two Drawer Pedestal
– 1pc
– 4pcs
– 4pcs
– 4pcs
– 4pcs
– 4pcs

Advertisement

loading
Need help?

Need help?

Do you have a question about the Display-It Desk and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PB TEEN Display-It Desk

  • Page 1 Display-It Desk IMPORTANT SAFETY INSTRUCTIONS: • Please read all instructions carefully before assembling. • For your safety, assembly by two adults is recommended. Hardware Included with Hardware Included with Two Drawer Pedestal: Desk Door Pedestal: (F) Allen Key – 1pc (N) Allen Key –...
  • Page 2 3. Open the top drawer of the Drawer Pedestal (B). Press the clips on both sides of the drawer-mounted metal glides to release the drawer box from the Drawer Pedestal (B). 4. Place the Drawer Pedestal (B) on the left and the Door Pedestal (C) on the right. Insert the Wooden Dowels (J&R) into the pre-drilled holes on the tops of the two pedestals.
  • Page 3 Display-It Desk Hutch MPORTANT SAFETY INSTRUCTIONS: Please read all instructions carefully before assembling. For your safety, assembly by two adults is recommended. Parts Included: Hardware Included: A - Desk Hutch – 1pc C - Shelf Support Pegs - 4pcs D - Bracket - 4pcs B - Shelf –...
  • Page 4 Display-It Desk Hutch FURNITURE TIPPING RESTRAINT Young children may be injured by tipping furniture. The use of a tipping restraint is highly recommended. When properly installed, this restraint could provide protection against the unexpected tipping of furniture due to small tremors, bumping or climbing. We recommend mounting this restraint to a wall stud.
