Hakko Electronics FG-465 Instruction Manual

Hakko Electronics FG-465 Instruction Manual

Footwear tester
Hide thumbs

Advertisement

Quick Links

Download this manual
FOOTWEAR TESTER
Thank you for your purchase of the HAKKO FG-465 Footwear Tester.
1. Contents
HAKKO FG-465 .................................................. 1
Installation base.................................................. 1
AC adapter ......................................................... 1
Test plate ............................................................ 1
Knobs ................................................................. 2
HAKKO FG-465
Knobs
(Installed onto FG-465 body
when shipped)
USB cable
FG-465
Instruction Manual
This product is for testing anti-static footwear.
Before using this product, be sure to read this manual.
Keep this manual readily accessible for reference.
Please check to make sure that all items listed below are included in the package.
Wood screws
AC adapter
USB cable........................................................... 1
Pan head screws (M5 x 10) ................................ 2
Wood screws (DN 4.5 x 16) ................................ 2
Instruction Manual (this document) .................... 1
Pan head screws
Test plate
Instruction Manual
Installation base
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the FG-465 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hakko Electronics FG-465

Summary of Contents for Hakko Electronics FG-465

  • Page 1: Table Of Contents

    FOOTWEAR TESTER FG-465 Instruction Manual Thank you for your purchase of the HAKKO FG-465 Footwear Tester. This product is for testing anti-static footwear. Before using this product, be sure to read this manual. Keep this manual readily accessible for reference.

  • Page 2: Hakko Fg-465

    AC adapter Output voltage DC 24 V * For details on calibrating the FG-465, contact your nearest agent. * Please note that specifications and appearance are subject to change without notice in the interest of product improvement. ※ 各言語 （日本語、 英語、 中国語、 フランス語、 ドイツ語、 韓国語） の取扱説明書は以下のURL、 HAKKO Document Portalからダウンロード...
  • Page 3 3. Safety and Handling Precautions This document divides precautions into the following two categories, "WARNING" and "CAUTION." Fully understand the content of the precautions below before reading descriptions in this document. WARNING : This indicates that mishandling might lead to death or serious injury. CAUTION : This indicates that mishandling might lead to injury or damage to property.
  • Page 4 4. Names of Parts Connection port for FG-470 wrist strap tester (w/ dust cover) USB port Type B Pass/Fail indicator Terminal for external output (No.1, 2)* Level indicator Level indicator GND terminal (left foot) (right foot) (No.3) Jack (for test plate) Pass range indicator Jack...

  • Page 5: Knobs

    5. Installation Note This product can also be mounted on a wall or optional stand in addition to use on a desktop. When mounting on a wall (1) Mount the installation base on the wall using the wood screws or pan head screws (provided) as shown in the figure.
  • Page 6 • Users that are pregnant, please refer to the technical document "FG-465 Information Regarding Safety to the Human Body" which can be found on our homepage (https://doc.hakko.com) and consult with the proper medical specialist.
  • Page 7 When FAIL LED lights This indicates that the anti-static footwear including the human body is outside the preset range. Check the cause and take action such as replacing the anti-static footwear. Measurement value is lower than lower limit Measurement value is higher than upper limit Example: The soles of the footwear have worn down Example: You are wearing thick socks Metal fragments are stuck in the soles...
  • Page 8 DIP switch settings. As external output is photocoupler output, add a drive circuit when a large current is required for connection of a relay or other device. No.1, 2 FG-465 side Output time: ON for 1 second after evaluation For external output...

  • Page 9: Instruction Manual (This Document)

    • Remove the battery for the FG-470 before use. • There is no need to press the pad on the FG-470. • Both the FG-465 and FG-470 can be attached to the "stand" (optional) by using the optional "unit integration base." (See "8. Parts List.")
  • Page 10 7. Troubleshooting WARNING Before replacing parts, be sure to disconnect the AC adapter plug from the power outlet. Is the AC adapter No operation even if power switch is or connection cord Connect. turned ON. disconnected? Set ON or OFF while referring The pass range indicator LED does Is the DIP switch setting to the DIP switch setting...
  • Page 11 8. Parts List Parts for HAKKO FG-465 Dwg. Part Part Name Specifications B5116 Installation base w/ screws B5117 Test plate w/ connection cord B5118 AC adapter CH plug B5119 AC adapter BS plug B5220 AC adapter European plug CE B3528 AC adapter 2 Core &...
  • Page 12 HEAD OFFICE 4-5, Shiokusa 2-chome, Naniwa-ku, Osaka 556-0024 JAPAN TEL: +81-6-6561-3225 FAX: +81-6-6561-8466 https://www.hakko.com E-mail: sales@hakko.com OVERSEAS AFFILIATES U.S.A.: AMERICAN HAKKO PRODUCTS, INC. TEL: (661) 294-0090 FAX: (661) 294-0096 Toll Free (800) 88-HAKKO 4 2 5 5 6 https://www.HakkoUSA.com E-mail: Support@HakkoUSA.com HONG KONG: HAKKO DEVELOPMENT CO., LTD.
