SOLDERING TESTER
FG-101B
Instruction Manual
Thank you for purchasing the HAKKO FG-101B Soldering tester.
This product is a soldering iron tester capable of measuring soldering tip
temperature, leak voltage and ground resistance.
Please read the manual carefully
before operating the HAKKO FG-101B.
Please keep this manual readily accessible for reference.
Advertisement
Table of Contents
Related Manuals for Hakko Electronics FG-101B
Summary of Contents for Hakko Electronics FG-101B
- Page 1 SOLDERING TESTER FG-101B Instruction Manual Thank you for purchasing the HAKKO FG-101B Soldering tester. This product is a soldering iron tester capable of measuring soldering tip temperature, leak voltage and ground resistance. Please read the manual carefully before operating the HAKKO FG-101B.
-
Page 2: Table Of Contents
Table of Contents PACKING LIST AND PART NAMES ..................1 SPECIFICATIONS ........................2 WARNINGS, CAUTIONS AND NOTES ..................3 OPERATION ..........................4 Initial setup ............................4 Measurement of tip temperature ......................5 Measurement of leak voltage ......................6 4-4 Measurement of resistance difference between tip and ground wire ..........7 Explanation about various functions ....................7 MAINTENANCE .........................9 REPLACEMENT PARTS/OPTIONS ..................10... -
Page 3: Packing List And Part Names
1. PACKING LIST AND PART NAMES Please check that all items listed below are included in the package. HAKKO FG-101B ..........1 Ground clip ............1 Fuse..............1 Power cord ............1 Conductive wire ..........1 Instruction manual ...........1 Sensor (qty 10) ..........1 AUTO ZERO button... -
Page 4: Specifications
2. SPECIFICATIONS Model name HAKKO FG-101B Temperature Resolution 1˚C 1°F Measurement range 0 - 700˚C 32 - 1300°F Measurement ±3˚C (between 300 and 600˚C) ±6°F (between 572 and 1112°F) tolerance ±5˚C (other than above) ±10°F (other than above) Sensor K(CA) thermocouple... -
Page 5: Warnings, Cautions And Notes
3. WARNINGS, CAUTIONS AND NOTES In this manual, items requiring caution are classified into 2 categories, "WARNINGS" and "CAUTIONS", as defined below. Please make sure to understand these items before reading the main text. WARNING : Failure to comply with a WARNING may result in serious injury or death. CAUTION Failure to comply with a CAUTION may result in injury to the operator, or damage to the objects involved. -
Page 6: Operation
Be sure to connect the main body power cord to a two-pole grounded- type receptacle. The power receptacle of the HAKKO FG-101B main body supplies power only when the power switch is turned... -
Page 7: Measurement Of Tip Temperature
Do not measure the temperature by applying measurements. In order to measure hot air (HAKKO FR-811, etc.) directly to the HAKKO FG-101B. If hot air is applied directly, the temperature correctly, if the the HAKKO FG-101B will be damaged. measurement point is worn out, replace the sensor with a new one. -
Page 8: Measurement Of Leak Voltage
Plug the power plug of the soldering iron to be measured into the power receptacle the HAKKO FG-101B main body. Wait until the tip reaches the set temperature. If the soldering iron temperature is variable, set temperature to maximum. -
Page 9: Measurement Of Resistance Difference Between Tip And Ground Wire
Press the about various functions".} Perform the measurement in the same procedure as "4-3 Measurement of leak voltage". Explanation about various functions HAKKO FG-101B can use the following functions. ■ MAX HOLD function (Temperature measurement only) Quickly pressing the button will cause "MAX... - Page 10 In order to send fixed values, the AUTO HOLD function or MAX HOLD function can be used for temperature measurements and the AUTO HOLD function can be used for voltage or resistance measurements. Make sure the HAKKO FG-101B infrared output part is facing and within the reception range of the receiver. ■ Count function...
-
Page 11: Maintenance
Connecting an exclusive cable adaptor module (option) to the DATA I/O connector on the upper part of the HAKKO FG-101B enables communication to applicable stations such as the HAKKO FN-1010, etc. (See the figure below) Data communication by infrared will be disabled during communication by DATA I/O. -
Page 12: Replacement Parts/Options
6. REPLACEMENT PARTS/OPTIONS ● HAKKO FG-101B Item No. Part name Specifications B2419 Power cord/3 core & American plug 120V USA B2421 Power cord/3 cored wire with no plug B2422 Power cord/3 core & BS plug India B2424 Power cord/3 core & European plug...
