Section 2 General Information and Setup
12
9
10
Generator Components
1
Key Switch Ignition
2
120 Volt AC, 20 Amp GFCI Duplex
Receptacle
3
120/240 Volt AC, 30 Amp Locking
Receptacle
4
Circuit Breakers (AC)
5
Battery Charger Input
6
Hour Meter
7
EFI Fault Indicator Light
8
Fuse
9
Grounding Lug
10
Spark Arrestor
11
Muffler
12
Fuel Cap
13
Recovery Hose
14
Carbon Canister
15
Air Filter
16
Recoil Starter
17
Handle
18
Fuel Gauge
19
Roll Over Valve
20
Fuel Tank
Owner's Manual for Portable Generator
13
010208
14
11
Figure 2-1. Features and Controls
19
24
15
17
16
21
21
Oil Drain
22
Oil Fill/Dipstick
23
Battery
24
Fuel Pump
25
Ignition Keys
26
Battery Charger
27
COsense® Shut-Off (RED)
28
COsense® Fault (YELLOW)
29
Oil Filter
27
1
28
8
Figure 2-2. Control Panel
18
20
23
22
29
6
2
3
7
5
4
25
26
010034
4
010035
5
