Ottawa Bar Stool Assembly Instructions - 194803 Please keep for future reference 194806 600/0444 600/5645 600/0468 Dimensions Width - 47cm Depth - 45cm Height - 78-100 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 4 - 03/04/13...
Page 2
Safety and Care Advice Important - Please read these instructions fully before starting assembly • We suggest you spend a short • Assemble all parts loosely • We do not time reading through this leaflet before tightening any bolts. recommend the and follow the simple step by use of power •...
Page 3
Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below 1 Seat 2 Upper leg 3 Gaslift (Ø5.8 x 39.5 x 16cm) (Ø5 x 50-72cm) (41 x 47 x 23.5cm) 4 Decor ring 5 Base...
Page 4
Assembly Instructions Step 1 Attaching upper leg Place the seat upside down on a flat protected surface. Position the upper leg and make sure that the lever is at your left hand side as Lever shown in the diagram. Secure using washer and bolt .
Page 5
Assembly Instructions Step 3 Step 3 Attaching the seat Position the seat as shown and insert the gaslift into the upper . Secure by pressing down the seat firmly. Gaslift operation To adjust the seat higher, lift up the lever under the seat and release at desired height.
