C‐DMM‐3003 Flip Up Dash Monitor Mount
2015‐2019 Chevy Tahoe PPV and Retail models
(Works with OEM "My Touch" display‐storage pocket)
TOOLS REQUIRED: (some tools are not needed for all vehicle installations)
• Socket set ‐ metric & standard
• Phillips screwdriver
PARTS and HARDWARE:
QTY: DESCRIPTION:
1
Main dash mount bracket
1
Driver side mounting bracket
1
Passenger side mounting bracket
1
PVC spacer washer
2
Nylon 1/16" spacer washer
2
1/4" Nylock nut
2
1/4" Flat washer
4
10‐32 x 1/2" Machine screw
4
10‐32 Keps nut
1
VESA swivel adaptor
The C‐DMM‐3000 swivel plate accepts C‐MM‐301 offset bracket used with C‐MM‐2XX adaptors.
C‐MM‐2XX series adaptor brackets are not needed for most VESA 75 and other Havis Docking Station
CM009068 VESA rotator plate gives additional positioning options, but is not required depending on
• Read all instructions before installing any Havis, Inc products.
INSTALLATION INSTRUCTIONS
• Drill & drill bits • Tape measure • Plastic notching tool
• Trim removal tools
mounting applications.
mounting preference.
• Use hardware provided with install kit
• Pencil / Marker
PART #:
CM009349
CM009402
CM009403
CM008582
CM86600
GSM30016
GSM31005
GSM33118
GSM30028
CM009068
Notes:
ALWAYS!
C‐DMM‐3003_INST_7‐18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Havis C-DMM-3003
Summary of Contents for Havis C-DMM-3003
- Page 1 1/4" Flat washer GSM31005 4 10‐32 x 1/2" Machine screw GSM33118 4 10‐32 Keps nut GSM30028 1 VESA swivel adaptor CM009068 Notes: The C‐DMM‐3000 swivel plate accepts C‐MM‐301 offset bracket used with C‐MM‐2XX adaptors. C‐MM‐2XX series adaptor brackets are not needed for most VESA 75 and other Havis Docking Station mounting applications. CM009068 VESA rotator plate gives additional positioning options, but is not required depending on mounting preference. ALWAYS! • Read all instructions before installing any Havis, Inc products. • Use hardware provided with install kit C‐DMM‐3003_INST_7‐18...
- Page 2 C‐DMM‐3003 assembly CM009402 Driver side mounting bracket CM009403 Passenger side mounting bracket 10‐32 Keps nut GSM30028 GSM30016 Nylock nut GSM31005 Flat washer CM86600 Nylon washer GSM33118 10‐32 x 1/2" Machine screw CM009068 VESA swivel adaptor CM008582 PVC spacer washer C‐DMM‐3003_INST_7‐18...
- Page 3 OEM Dash Prior to installation Pull back the driver side lower dash panel to gain access and remove side trim screw (7mm socket) Remove rubber cover in lower accessory pocket to Pull lower dash panel towards you to remove. gain access and remove two (2) lower dash panel screws. (7mm socket) Remove driver side upper dash panel. Insert a flat blade panel removal tool and remove the panel above the glove box. C‐DMM‐3003_INST_7‐18...
- Page 4 Remove three (3) screws from the vent housing and remove Carefully remove (unsnap) center trim bezel around touch the housing. Repeat for passenger side. (7mm socket) screen and climate controls Remove two (2) screws on each side next to the OEM screen. On the 2017 and older Tahoe, (2) plastic tabs will need to be Install side support brackets using OEM hardware. trimmed. This can be done with a simple snip from a pair of diagonal cut pliers OEM Trim Bezel P/N: 22883557 Carefully notch trim bezel accordingly and reinstall back Loosely place the center trim bezel up to the into dash. Re‐install all vents and dash trim. dash and mark the plastic area around the upper File or Dremel tool works well for notching plastic. side brackets to be notched. C‐DMM‐3003_INST_7‐18...
- Page 5 Re‐install all trim and dash panels. It helps to raise Attach the C‐DMM‐3003 using (4) 10‐32 x 1/2" screws and #10 Keps nuts. the screen to snap in the trim around the dash. Determine desired position for your specific computer Attach VESA swivel plate to the back of the mounting and attach to DMM swivel plate using nylon washers, bracket. The gray nylon washer will go between this steel washers, and nylock nuts. Tighten so that the dock bracket and the DMM swivel plate. rotates smoothly. (Firm, but not too tight) Run wiring as desired and test equipment. Installation is now complete C‐DMM‐3003_INST_7‐18...
