2008-2016 Ford F-250, 350 and 450 Super Duty Pickup truck
1. The C-DMM-2000 series Dash Monitor Mount brackets are specifically designed to work with Havis,
2. The display mount bracket includes a VESA 75 hole pattern that can also be used for some light
weight tablet docking station applications under 5 lbs. . Acceptable positioning must be determined
3. The C-DMM-2007 will work with all Havis, Inc. consoles made for the Super Duty.
4. The C-DMM-2007 Does NOT work with the upgraded radio with touchscreen. Please review photos to
TOOLS
REQUIRED: (some tools are not needed for all vehicle installations)
• Socket set - metric & standard
• Phillips screwdriver
MOUNT BRACKET PARTS and HARDWARE:
Installation parts with * come loose in hardware kit bag. Other parts are preassembled
QTY:
DESCRIPTION:
1
Main dash mount bracket
1
Pivot / display mount bracket
1
PVC spacer washer
1
Tilt swivel adaptor
2
1/4" x 3/4" Carrage bolts
2
1/4" Nylock nut
2
1/4" Flat washer
2
Nylon 1/16" spacer washer
1
Tilt swivel hinge
1
F-250 Display mount support bracket
2
Standoff plate
1
F-250 Rear mount support bracket
1
M8 hex nut SS
1
M8 lock washer SS
4
Machine Screw 10-32 x 3/4"
4
#10 Flat washer
1
Vinyl cap (.50" high x .312 - .375 id)
1
Stop bracket
2
M5 x 10mm Thread forming screw
2
Pull through bumper (3mm head)
2
Push in bumper
1
8-32 x .312" Phillips truss head machine screw
1
M6 hex nut
1
1/4" Flat washer
2
1/4" Serrated nut
INSTALL INSTRUCTIONS
C-DMM-2007
Inc, model # TSD-101 Touch Screen Display.
confirm what OEM dash is required for this application.
• Drill & drill bits
• Trim removal tools
(10mm head)
Dash Monitor Mount
Notes:
by end user.
• 1.5" hole saw
• Pencil / Marker
PART #:
MT-0314-SA
MT-0320-SA
*
CM008582
CM008531
GSM32000
GSM30016
GSM31005
CM86600
GSM22005
MT-0316-SM
MT-0317-SM
MT-0315-SM
GSM30113
GSM31217
GSM33119
GSM31003
GSM41127
MT-0291-SM
GSM33774
GSM21109
GSM21108
GSM34077 *
GSM30201
GSM31005
GSM30023
• Tape measure
C-DMM-2007_INST_1-17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Havis C-DMM-2007
Summary of Contents for Havis C-DMM-2007
- Page 1 3. The C-DMM-2007 will work with all Havis, Inc. consoles made for the Super Duty. 4. The C-DMM-2007 Does NOT work with the upgraded radio with touchscreen. Please review photos to confirm what OEM dash is required for this application.
- Page 2 ALWAYS! • Read all instructions before installing any Havis, Inc products. • Use hardware provided with install kit C-DMM-2007 assembly GSM21108 MT-0314-SA GSM22005 GSM33119 MT-0320-SA * GSM32000 GSM33119 CM86600 GSM31005 GSM30016 GSM31005 GSM30201 GSM31217 CM008582 GSM30113 GSM41127 MT-0317-SM CM008531 GSM30023...
- Page 3 Remove panel containing OEM 12v socket. View of F-250 Super Duty prior to Remove fastener. installation. (7 mm socket) Remove panel containing aux input. Remove dash panel by gently prying along Remove fastener. edges with a panel removal tool. (7 mm socket) Following measurements above, drill four (4) 5/16”...
- Page 4 Install forward mount support bracket onto Use M6 nut and 1/4" washer to attach bracket OEM stud on brace. to existing threaded stud. Tighten hardware. Insert MT-0317-SM standoff plates into the (10mm socket) forward hole in upper radio frame. Attach display mount support bracket MT-0316-SM Repeat process for rear hole.
- Page 5 Display mount hardware is included with M8 hex nut and lock washer. Tighten nut and with TSD-101 hardware kit attach vinyl cap on M8 bolt threads. Refer to TSD-101 owner’s manual for Installation of C-DMM-2007 with TSD-101 power and computer connection details. complete. C-DMM-2007_INST_1-17...
