Installing the Shelves
DD system Memory
required
(GB)
DD6800 w/ 192
Expanded Capacity
5, 6
and w/ HA
DD6800 w/ 192
Expanded Capacity
5, 6
and w/ ER
DD6800 w/ 192
Expanded Capacity
and w/ DD Cloud
6, 7
Tier
DD6800 w/ 192
Expanded Capacity
and w/ DD Cloud
6, 7
Tier and HA
DD7200 128
DD7200 256
2
DD7200 ER 256
5, 6, 13 14
DD9300 192
DD9300 w/ 384
Expanded Capacity
5, 6, 12
DD9300 w/ 384
Expanded Capacity
5, 6
and w/ HA
DD9300 w/ 384
Expanded Capacity
5, 6, 10
and w/ ER
DD9300 w/ 384
Expanded Capacity
and w/ DD Cloud
6, 7
Tier
DD9300 w/ 384
Expanded Capacity
and w/ HA and DD
6, 7
Cloud Tier
DD9500 256
DD9500 Expanded 512
2
DD9500 ER 512
Data Domain DS60 Expansion Shelf Hardware Guide
22
Table 11 Shelf configuration supported per Data Domain system for the DS60 shelf (continued)
SAS DS60 support
cards/ (TB)
port per
card
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45
2x4 SAS 45, 60
4x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
2x4 SAS 45, 60
3x4 SAS 45, 60
3x4 SAS 45, 60
4x4 SAS 45, 60
Max Max
shelves number
per set of sets
1 2
2 4
2 4
2 4
2 4
2 4
2 8
3 4
3 4
3 4
3 4
3 4
3 4
4 6
4 6
4 8
Max Max RAW
external external
capacity capacity
available (TB)
1
(TB)
288 360
576 720
288 + 96 for 360 + 120 for
DD Cloud Tier DD Cloud Tier
288 + 96 for 360 + 120 for
DD Cloud Tier DD Cloud Tier
288 360
432 540
864 1080
384 480
720 900
720 900
1440 1800
720 + 192 for 900 + 240 for
DD Cloud Tier DD Cloud Tier
720 + 192 for 900 + 240 for
DD Cloud Tier DD Cloud Tier
432 540
864 1080
1728 2160
