Evaluation Software; Time.net Connector - ALGE-Timing Mobile Timing MT1 Manual

High-precision timing device

Hide thumbs Also See for Mobile Timing MT1:

Table of Contents

5.3.1

Evaluation software

If your evaluation software can work with serial data and supports the communication protocol,

(Timy series or TDC 800x series, daytime format) it can be used to read the timestamps direct-

ly via USB interface.

5.3.2

The Time.NET Connector is a software to connect the MT1 system with an evaluation soft-

ware. There are many connection possibilities:

Note:

If the time.NET Connector an the evaluation software runs on the same PC you will need a

Null modem cable (from one COM port to the other) or a driver software which simulates and

connects two COM ports. This

website.

If you use the Time.NET software we suggest to use the network connection to the Time.NET

connector which will be automatically established. An IDCam device will be simulated in this

case.

Note:

Timing impulses of non-MT1 devices are not reflected to the online platform alge-results.com

Manual

Mobile Timing MT1

COM port simulator

- 14 -

(Com0Com) can be downloaded on our
