Keysight Technologies N9000B CXA Signal Analyzer Option T03 and T06, Tracking Generator Upgrade Kit Installation Note...
Page 2
The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Page 3
Introduction This kit includes parts to upgrade any N9000B CXA signal analyzer to add Option T03 and T06 tracking generator. 1. Pre-upgrade Status Check 2.
Page 4
Option T03 and T06, Tracking Generator Upgrade Kit N9000BU-T03/T06, Tracking Generator Upgrade Kit Parts List Quantity Description Part Number Tracking Generator Assembly N9000-65402 RF Input Connector Assembly N9000-60032 EMI O-ring Shielding 8160-1637 Carton Box for Tracking Generator E4403-80035 N9000-20104 Cable Assembly, SMA TG-RF, 2 Cable Assembly, SMA TG-RF, Bridge N9000-20105 N9000-20106...
Instrument S/W Revision: ______________ 3. Refer to the data in step 2 above. If the Product Number is not N9000B, do not proceed with the installation of this kit. This kit is to be installed only on N9000B signal analyzers. Installation Note N9000-90039...
Option T03 and T06, Tracking Generator Upgrade Kit Analyzer Disassembly If the instrument is placed on its face during any of the following procedures, be sure to use a soft surface or soft cloth to avoid damage to the front panel, keys, or input connector. If the analyzer has Option PRC, Portable Configuration, refer to the “Portable Instrument (Option PRC)”...
Page 8
Option T03 and T06, Tracking Generator Upgrade Kit Standard Instrument (Benchtop Configuration) 1. Disconnect the instrument from ac power. 2. Refer to Figure 1. Using the T-20 driver, remove the four screws (two on each side) (1) that attach the handle strap (2) on each side of the instrument. 3.
Page 9
Option T03 and T06, Tracking Generator Upgrade Kit Portable Instrument (Option PRC) Make sure any adapters on the front panel are removed. 1. Disconnect the instrument from ac power. 2. Refer to Figure 2. Using the T-20 driver, remove the four screws (two on each side) (1) that hold the bail handle (2) to the front frame.
Page 10
Option T03 and T06, Tracking Generator Upgrade Kit 5. Refer to Figure 3. Using the T-20 driver, remove the four screws including washers (1) that hold the rear bumpers (2) in place. The rear bumpers will not be re-used. 6. Pull the instrument cover (3) off towards the rear of the instrument. The instrument cover will not be re-used.
Page 11
Option T03 and T06, Tracking Generator Upgrade Kit Top Brace and Reference Bracket Removal 1. Refer to Figure 4. To remove the top brace (1), use the T-10 driver, remove the eight screws (3) (0515-0372) attaching the top brace to the chassis, the six screws (4) (0515-1227) attaching the top brace to the boards, and the four screws (4) attaching the top brace to the reference bracket Figure 4...
Page 12
Option T03 and T06, Tracking Generator Upgrade Kit Front Frame Assembly Removal 1. Refer to Figure 5. Using the T-10 driver, remove the eight screws (1), four on each side, to detach the front frame from the chassis. Figure 5 Front Frame Removal Installation Note N9000-90039...
Page 13
Option T03 and T06, Tracking Generator Upgrade Kit 2. Refer to Figure 6. Pull the front frame carefully away from the chassis. Remove the ribbon cable W1 from the A8 Motherboard. W1 may have locking springs on each side. Depress the spring on each side of the connector to remove from the motherboard.
Page 14
Option T03 and T06, Tracking Generator Upgrade Kit Tracking Generator Installation Please follow the procedures below to install the tracking generator in N9000B unit. Install the Tracking Generator Assembly Op Locate the tracking generator assembly in the kit. 2. Refer to...
Page 15
Option T03 and T06, Tracking Generator Upgrade Kit Install the RF Input Connector Assembly 1. Locate the tracking generator assembly in the unit. 2. Refer to Figure 8 to install the RF input connector assembly (1) into the instrument chassis. 3.
Page 16
Option T03 and T06, Tracking Generator Upgrade Kit Figure 10 Install the RF Semi-rigid Cable 4. Locate the cable assemblies N9000-20104, N9000-20105, N9000-20106, and N9000-20107 in the retrofit kit. 5. Refer to Figure 10, install N9000-20105 (2), N9000-20106 (3), N9000-20104 (4), and N9000-20107 (5) onto the corresponding instrument assemblies.
Page 17
Option T03 and T06, Tracking Generator Upgrade Kit Final Installation for Standard Instruments (Benchtop Configuration, Figure 1 1. Refer to Figure 1. Locate the new instrument dress cover (N9020-00068) in the kit. Carefully slide the instrument cover onto the instrument from the rear of the analyzer, making sure not to damage any internal cables.
Option T03 and T06, Tracking Generator Upgrade Kit Updating the Instrument Software 1. Visit the following website to determine the latest instrument software version for the N9000B: http://www.keysight.com/find/xseries_software 2. Compare the latest software version with the software version noted in...
Page 19
TG Absolute Amplitude and Flatness TG Power Sweep TG Spurious Outputs For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL, or if in the United States, call the following telephone number: http://www.keysight.com/find/assist...
