• Examine the power cable for wear, and patch or repair as
necessary .
• Check the power terminals, and clean them if necessary
• Lubricate the hinges and bushings
• Clean and lubricate the stow and deploy latch mechanism
• Check the mount rails, and replace them if necessary
• Check the mount bumper, and replace it if necessary
• Clean or replace the anodes in the propeller drive motor

Motor Information

Stowed Dimensions
Item 50 in. Model
5
1.558 m (61 / in.) min.
16
5
1.811 m (71 / in.) max.
16
13
300 mm (11 / in.)
16
Deployed Dimensions
Item 50 in. Model
1
461 mm (18 / in.) min.
8
3
721 mm (28 / in.) max.
8
7
708 mm (27 / in.)
8
1
648 mm (25 / in.) min.
2
889 mm (35 in.) max.
1
839 mm (33 / in.) min.
16
5
1.1 m (43 / in.) max.
16
.
.
.
.
.
57 in. Model
3
1.712 m (67 / in.) min.
8
5
2.066 m (81 / in.) max.
16
3
340 mm (13 / in.)
8
57 in. Model
3
488 mm (19 / in.) min.
16
1
817 mm (32 / in.) max.
8
7
799 mm (31 / in.)
16
737 mm (29 in.) min.
1.07 m (42 in.) max.
3
920 mm (36 / in.) min.
16
1
1.18 m (46 / in.) max.
2
Item 50 in. Model
11
931 mm (36 /
16
13
402 mm (15 /
16
203 mm (8 in.)
Registering Your Device
Help us better support you by completing our online registration
today. Keep the original sales receipt, or a photocopy, in a safe
.
place.
1
Go to my.garmin.com/registration.
2
Sign in to your Garmin account.
Contacting Garmin Support
• Go to support.garmin.com
product manuals, frequently asked questions, videos, and
customer support.
• In the USA, call 913-397-8200 or 1-800-800-1020.
• In the UK, call 0808 238 0000.
• In Europe, call +44 (0) 870 850 1241.

Specifications

Trolling Motor
Weight (motor, 50 in. model: 30 kg (66 lb.)
mount, and cables)
57 in. model: 31.75 kg (70 lb.)
Weight (stabilizer) 0.54 kg (1.2 lb.)
Operating From -5° to 40°C (from 32° to 104°F)
temperature
Storage temperature From -40° to 85°C (-40° to 185°F)
Material Mount and motor housing: aluminum
Shaft cap, display panel, and side panels: plastic
Motor shaft: fiberglass
Water rating Shaft cap: IEC 60529 IPX5
Steering motor housing: IEC 60529 IPX7
Display panel housing: IEC 60529 IPX7
Propeller drive motor housing: IEC 60529 IPX8
Compass safe 91 cm (3 ft.)
distance
Power cable length 50 in. model: 1.2 m (4 ft.)
57 in. model: 1.1 m (3.5 ft.)
Input voltage From 20 to 45 Vdc
Input amperage 60 A continuous
Breaker (not 42 VDC or greater, suitable for 60 A continuous
included)
NOTE: You can protect the system by using a
larger circuit breaker, not to exceed 90 A, if you
are operating under high temperatures or if you
are sharing the circuit with other devices. You
should verify that your boat wiring meets marine
wiring standards using a larger breaker before
changing it.
1
The part withstands projected water exposure from any direction (such as rain).
2
The part withstands incidental immersion in water up to 1 m deep for up to 30 min.
3
The part withstands continuous immersion in water up to 3 m deep.
57 in. Model
1
in.) 1.022 m (40 /
4
13
in.) 402 mm (15 /
203 mm (8 in.)
