Garmin FORCE KRAKEN Installation Instructions Manual
  1. Manuals
  2. Brands
  3. Garmin Manuals
  4. Engine
  5. FORCE KRAKEN
  6. Installation instructions manual
Garmin FORCE KRAKEN Installation Instructions Manual

Garmin FORCE KRAKEN Installation Instructions Manual

Trolling motor
Hide thumbs Also See for FORCE KRAKEN:

Advertisement

Quick Links

Download this manual
FORCE
®
Installation Instructions .......................2
Instructions d'installation.....................6
Garmin
®
, the Garmin logo, ActiveCaptain
®
, and Force
express permission of Garmin.
You should reference United States Code of Federal Regulations: 33 CFR 183 - Boats and Associated Equipment and ABYC E-11: AC and DC Electrical Systems on Boats when installing this
trolling motor.
El número de registro COFETEL/IFETEL puede ser revisado en el manual a través de la siguiente página de internet.
KRAKEN TROLLING MOTOR
®
are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the
Printed in Taiwan
June 2023
190-03009-02_0A

Advertisement

loading
Need help?

Need help?

Do you have a question about the FORCE KRAKEN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garmin FORCE KRAKEN

Summary of Contents for Garmin FORCE KRAKEN

  • Page 1 , and Force ® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the express permission of Garmin. You should reference United States Code of Federal Regulations: 33 CFR 183 - Boats and Associated Equipment and ABYC E-11: AC and DC Electrical Systems on Boats when installing this trolling motor.

  • Page 2: Getting Started

    Force Kraken Trolling Motor ® Shaft cap Installation Instructions Power and transducer cables Depth-adjustment collar Getting Started Steering system WARNING See the Important Safety and Product Information guide in the product box for Mount product warnings and other important information. Shaft Do not run the motor when the propeller is out of the water.

  • Page 3: Installation Procedures

     in. (8 mm) drill bit, drill the mounting holes. NOTE: Most models come fully assembled. This procedure is only required for the 90-inch Force Kraken Trolling Motor. 5 Place the motor on the boat deck, aligning the holes on the mount with the mounting holes.

  • Page 4: Motor Information

    The stabilizer is an optional accessory that can help stabilize and provide additional support for the trolling motor when it is in the stowed position. NOTE: A stabilizer is only included with the Force Kraken Trolling Motor 90" model. Installation instructions for the stabilizer are provided in the stabilizer box.
  • Page 5 2 AA (not included) Contacting Garmin Support Battery life 240 hr., typical use • Go to support.garmin.com for help and information, such as product Radio frequency 2.4 GHz @ 3.4 dBm nominal manuals, frequently asked questions, videos, and customer support. Water rating IEC 60529 IPX7 •...

  • Page 6: Préparation De L'installation

    Force Kraken Trolling Motor Préparation de l'installation ® Instructions d'installation Device Overview Getting Started WARNING Consultez le guide Informations importantes sur le produit et la sécurité inclus dans l'emballage du produit pour prendre connaissance des avertissements et autres informations importantes sur le produit. N'enclenchez pas le moteur tant que l'hélice se trouve hors de l'eau.

  • Page 7: Procédure D'installation

    NOTE: Most models come fully assembled. This procedure is only required indiqué. Si vous utilisez des outils électriques pour assembler le moteur, for the 90-inch Force Kraken Trolling Motor. vous risquez d'endommager les composants et d'entraîner l'annulation de la Using a 4 mm hex bit or wrench, secure the nose cone to the front of the garantie.
  • Page 8 The stabilizer is an optional accessory that can help stabilize and provide additional support for the trolling motor when it is in the stowed position. NOTE: A stabilizer is only included with the Force Kraken Trolling Motor 90" model. Installation instructions for the stabilizer are provided in the stabilizer box.
