3
From the inside out, insert the bushings
holes
on the steering servo housing.
4
Holding the pull cable
onto the lower link of the mount, aligning the lower holes on
the housing with the holes on the link.
5
While lifting up on the steering servo housing, push the pivot
pin
through the housing and the link to hold it in place.
Do not hit the pin with a hammer or other object. Do not drill
or modify the holes. Although it is a snug fit, the pin slides in
completely when pushed by hand. Damage caused by
hammering the pin or modifying the holes is not covered
under warranty.
6
Route the pull cable upward through the top of the steering
servo housing
.
into the lower
up, place the steering servo housing
NOTICE
Securing the Upper Gas Spring
Label identifying the parts bag required for this procedure:
1
Push the safety rod
far as possible to lock the lower pivot pin in place.
2
If necessary, pivot the upper gas spring
link of the mount so the base of the gas spring aligns with the
safety rod and mounting holes.
NOTE: If you must rotate the gas spring so the base aligns
with the mount, rotate the spring in a clockwise direction only.
Rotating the gas spring in a counter-clockwise direction may
loosen the fittings.
3
Align the single hole on the base of the gas spring
safety rod, and press down.
The screw holes on the base
on the bottom of the mount.
4
Using a #2 Phillips screwdriver, secure the base of the gas
spring to the lower link of the mount using the included
screws
.
Keep the remaining screws in the parts bag. You must use them
when securing the other gas spring in a later procedure.
Connecting the Upper Link of the Mount to the
Steering Servo Housing
Label identifying the parts bag required for this procedure:
1
Remove the tape that secures the data cable
steering servo housing.
2
From the outside in, insert the bushings
on the steering servo housing.
toward the steering servo housing as
toward the lower
should align with the holes
to the
in the upper holes
with the
3
