GDS3710 Connection & Wiring Diagrams ---- "Fail Safe" Electric Strike, 3
Outdoors
GDS3710
12V
GND
GND
IN1+
IN1-
IN2-
IN2+
Op onal
COM2
NC2
NO2
COM1
"Fail Safe " Model
NO1
Op onal
rd
Party Power Supply
Indoors
Power Supply for GDS
V+
Power Supply for GDS
V-
DC 12V 1A minimum
Door Lock Switch
V-
V+
Electric Strike
to protect people:
The lock is released if power cuts off
Power Supply for
Electric Strike
DC 6-24V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDS3710 and is the answer not in the manual?

Questions and answers

Related Manuals for Grandstream Networks GDS3710

Summary of Contents for Grandstream Networks GDS3710

  • Page 1 GDS3710 Connection & Wiring Diagrams ---- “Fail Safe” Electric Strike, 3 Party Power Supply Outdoors Indoors Power Supply for GDS Power Supply for GDS DC 12V 1A minimum Door Lock Switch IN1+ IN1- Power Supply for IN2- Electric Strike IN2+...
  • Page 2 GDS3710 Connection & Wiring Diagrams ---- “Fail Secure” Electric Strike, 3 Party Power Supply Indoors Outdoors 1A at least for GDS3710 Power Supply for Both GDS3710 and Electric Strike: Note DC 12V 2A minimum. IN1+ Door Lock Switch IN1- NOTE: IN2- •...
  • Page 3 GDS3710 Connection & Wiring Diagrams ---- “Fail Safe” Electric Strike, 3 Party Power Supply + POE Indoors Outdoors POE Switch Cat 5e/6 Ethernet Cable Door lock Switch IN1+ IN1- Power Supply for IN2- Electric Strike IN2+ Op onal DC 6-24V...
  • Page 4 GDS3710 Connection & Wiring Diagrams ---- “Fail Secure” Electric Strike, 3 Party Power Supply + POE Indoors Outdoors POE Switch Cat 5e/6 Ethernet Cable Door lock Switch IN1+ IN1- Power Supply for IN2- Electric Strike IN2+ Op onal DC 6-24V...
  • Page 5 GDS3710 Connection & Wiring Diagrams ---- Inappropriate Electric Strike Connection Indoors Outdoors Power Supply for Both GDS3710 and Electric Strike: Note DC 12V 2A minimum. COM2 COM1 Relay limit 125VAC/0.5A, 30VDC/2A Lamp 110VAC 220VAC GDS3710...
  • Page 6 GDS3710 Connection & Wiring Diagrams ---- Good Electric Strike &High Power DeviceConnection Indoors Outdoors Power Supply for Both GDS3710 and Electric Strike: Note DC 12V 2A minimum. COM2 COM1 Low voltage DC power Add relay for Isola on proten on...
  • Page 7 GDS3710 Connection & Wiring Diagrams ---- Wiegand RFID Reader Indoors Outdoors Power Supply for Both GDS3710 and Electric Strike: Note DC 12V 2A minimum. IN1+ IN1- COM2 DC V 12 RFID devices GDS only powers DC5V RFID devices DC-/GND WG_D0_IN...
