Grandstream Networks GDS3705 Quick Installation Manual

Grandstream Networks GDS3705 Quick Installation Manual

Ip door phones in-wall mounting kit
Hide thumbs Also See for GDS3705:

Advertisement

Quick Links

Download this manual See also: User Manual
U S E R G U I D E | C L O U D C O M M U N I C A T I O N S
GDS IP Door Phones
In-Wall Mounting Kit
Quick Installation Guide
March 2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the GDS3705 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandstream Networks GDS3705

Summary of Contents for Grandstream Networks GDS3705

  • Page 1 U S E R G U I D E | C L O U D C O M M U N I C A T I O N S GDS IP Door Phones In-Wall Mounting Kit Quick Installation Guide March 2019...
  • Page 2 OVERVIEW The In-Wall Mounting Kit is available for use with the GDS3705 and GDS3710. This mounting kit allows the GDS door phones to be flush mounted within a wall rather than on the surface of the wall. It supports solid wall, stud and drywall (hollow wall) installation.

  • Page 3: Package Contents

    I N -WAL L M OU NTI N G KI T PACKAGE CONTENTS 1 x Plastic Box 1 x Cover Plate 1 x Drill Template 1 x Metal Frame 1 x Quick Reference 1 x Anti-Tamper (For Stud Mount) Guide Hex Key PA3.5*35mm PA3*10mm...

  • Page 4: Solid Wall Installation

    I N -WAL L M OU NTI N G KI T Solid Wall Installation Please follow below steps to install the device into solid wall. Step 1: Use provided Drill Template to mark boundary then dig a rectangle hole into the wall (drilling or dig tools not provided).
  • Page 5 I N -WAL L M OU NTI N G KI T Step 3: Use provided Anchor/Screws to mount the Plastic Box inside the hole in the wall. Step 4: Follow GDS Door Phone and User Manual to connect wires to the PoE switch or PoE Injector. Connect the Electrical Lock according to its document.
  • Page 6 I N -WAL L M OU NTI N G KI T Step 5: Align the bracket clips, press and push down the GDS Door Phone (i.e. shows GDS3710) into place. Step 6: Install the Cover Plate and fix it using the Hex Key with the Anti-Tamper Screws provided.
  • Page 7 I N -WAL L M OU NTI N G KI T Stud Installation Please follow below steps to install the device at the stud of a new building open wall, or a finished wall. Step 1: For finished wall, use provided Drill Template to mark boundary and dig a rectangle hole into the wall. For open wall, skip and go to next step.
  • Page 8 I N -WAL L M OU NTI N G KI T Step 3: Mount the Installation Bracket into the Plastic Box using supplied Screws Step 4: Use provided Screws and Nuts to install the Plastic Box on the long edge of the Metal Frame. (3) (4) Choose either set of Nuts with convenience.
  • Page 9 I N -WAL L M OU NTI N G KI T Step 5: Follow GDS Door Phone and User Manual to connect wires to the PoE switch or PoE Injector. Connect the Electrical Lock according to its document. Step 6: Align the bracket clips, press and push down the GDS Door Phone (i.e. shows GDS3710) into place.
  • Page 10 I N -WAL L M OU NTI N G KI T Step 7: Install the Cover Plate and fix it using the Hex Key with the Anti-Tamper Screws provided. Drywall (Hollow Wall) Installation Please follow below steps to install the device on a drywall or hollow wall. The thickness of the wall where the clamps can handle is among 6.2 ~ 24 mm (or 0.24 ~ 0.94 inch) Step 1: Use provided Drill Template to mark boundary then cut opening on the dry wall.
  • Page 11 I N -WAL L M OU NTI N G KI T Step 2: Mount the Installation Bracket into the Plastic Box using supplied Screws Step 3: Insert the Plastic Box into the cut hole properly.
  • Page 12 I N -WAL L M OU NTI N G KI T Step 4: Tighten the four clamps alternately in diagonal to mount the Plastic Box on the wall. Please do NOT over tighten to avoid damaging the wall or clamp. Step 5: Follow GDS Door Phone QIG and User Manual to connect wires to the PoE switch or PoE Injector.
  • Page 13 I N -WAL L M OU NTI N G KI T Step 6: Align the bracket clips, press and push down the GDS Door Phone (i.e. shows GDS3710) into place. Step 7: Install the Cover Plate and fix it using the Hex Key with the Anti-Tamper Screws provided.
