1-8 Replaceable Parts and Assemblies
Table 1-7.
Replaceable Parts and Assemblies (3 of 5)
Part Number Description
GPS Receiver Module, Option 31
– Does not include GPS Antenna 2000-1528-R
– For MS2026C, MS2027C and MS2028C instruments equipped with Option 31 GPS Receiver
ND70320
–
Section 6-19 "Replacing GPS Receiver Module (Option 31) – ND70320" on page 6-37
– For MS2036C, MS2037C and MS2038C instruments equipped with Option 31 GPS Receiver
–
Section 7-19 "Replacing GPS Receiver Module (Option 31) – ND70320" on page 7-45
LCD Display
– For all MS202xC and MS203xC instruments
3-15-154
–
Section 6-23 "Replacing LCD Display – 3-15-154" on page 6-50
–
Section 7-23 "Replacing LCD Display – 3-15-154" on page 7-64
Clear Plastic LCD Protector
– For all MS202xC and MS203xC instruments
3-61368
–
Section 6-24 "Replacing Clear Plastic LCD Protector – 3-61368" on page 6-51
–
Section 7-24 "Replacing Clear Plastic LCD Protector – 3-61368" on page 7-66
Main Keypad Rubber Membrane
– For all MS202xC and MS203xC instruments
3-61362
–
Section 6-11 "Replacing Main Keypad Components – 3-61362, 3-71027-3" on page 6-12
–
Section 7-11 "Replacing Main Keypad Components – 3-61362, 3-71027-3" on page 7-13
Main Keypad PCB
– For all MS202xC and MS203xC instruments
3-71027-3
–
Section 6-11 "Replacing Main Keypad Components – 3-61362, 3-71027-3" on page 6-12
–
Section 7-11 "Replacing Main Keypad Components – 3-61362, 3-71027-3" on page 7-13
Main Keypad Plastic Bezel
– For all MS202xC and MS203xC instruments
3-61363-1
–
Section 6-11 "Replacing Main Keypad Components – 3-61362, 3-71027-3" on page 6-12
–
Section 7-11 "Replacing Main Keypad Components – 3-61362, 3-71027-3" on page 7-13
Main Menu Keypad Rubber Membrane
– For all MS202xC and MS203xC instruments
3-61361
–
Section 6-12 "Replacing Main Menu Keypad Rubber Membrane – 3-61361" on page 6-15
–
Section 7-13 "Replacing Main Menu Keypad Components" on page 7-19
Main Menu Keypad Flex PCB
– For all MS202xC and MS203xC instruments
3-71030-3
–
Section 6-13 "Replacing Main Menu Keypad Components" on page 6-17
–
Section 7-13 "Replacing Main Menu Keypad Components" on page 7-19
Main Menu Keypad Plastic Bezel
– For all MS202xC and MS203xC instruments
3-61378-1
–
Section 6-13 "Replacing Main Menu Keypad Components" on page 6-17
–
Section 7-13 "Replacing Main Menu Keypad Components" on page 7-19
Rotary Encoder
– For all MS202xC and MS203xC instruments
3-410-101
– Does not include the Rotary Knob 3-61360-2
–
Section 6-20 "Replacing Rotary Encoder – 3-410-101" on page 6-41
–
Section 7-20 "Replacing Rotary Encoder – 3-410-101" on page 7-49
Encoder Rotary Knob (excluding encoder)
– For all MS202xC and MS203xC instruments
3-61360-2
– Does not include the Rotary Encoder 3-410-101
–
Section 6-15 "Replacing Rotary Knob – 3-61360-2" on page 6-23
–
Section 7-15 "Replacing Rotary Knob – 3-61360-2" on page 7-25
1-10
PN: 10580-00307 Rev. D
General Information
MS20xxC MM
