Infinite Peripherals Imperea Quick Start Manual

QUICK START GUIDE
Imperea
For iPhone® 6s / 7 / 8 / SE
Assemble Imperea with Your iPhone
1. Remove the Imperea from the box, and then carefully twist a penny or the
ply tool inside the bottom notch.
2. Twist the coin along the metal inside bottom notch to release the snap
fittings on the bottom of the cover.
3. After the cover is loose, pull the remaining snap fittings with the coin
along the top cover.
4. Place the unit on a flat surface, and then slide the iPhone downwards
towards the Lightning™ connector.
5. Once the iPhone is engaged with the Lightning connector, gently press the
iPhone onto the unit.
6. Ensure the iPhone is seated property and flush with the rubber seals.
7. Place the front cover onto the unit with the snaps fully engaged.
Disassemble Your iPhone from Imperea
1. Remove the Imperea from the box, and then insert a penny horizontally
into the bottom notch.
2. Press firmly and twist a penny along the metal inside the bottom notch to
release the snap fittings on the bottom of the cover.
3. Once the bottom part of the cover is loose, carefully pull on the remaining
snap fittings along the top cover.
4. With the top cover removed, take the Imperea and locate the camera
opening on the reverse side.
5. Through the camera opening, press gently on the iPhone to release it from
the rubber enclosure.
6. Once the top iPhone is released, slide the iPhone upwards, removing it
from the Lightning connector.
7. Gently snap the top cover into place for safekeeping.
Note
Your Imperea includes a single-station charger with power adapter, case,
and a battery inside the unit.
Charge with Single Charging Station
IMPORTANT
For the single charging station to function properly, you must use the
power adapter provided. The fast charger requires a minimum of 10 watts
capacity to function.
1. Plug the USB-A end of the charging cable into the provided adapter. The
top LED flashes green.
Note
To prevent damage to the unit, do not plug the cable into a USB port on a
computer or other adapter.
2. Place the unit on a single station charger, lining up the bump on the base of
the charger with the bottom notch on the Imperea.
3. Ensure the unit is centered on the charger, and then wait to hear the
charging beep, which signals the wireless charging is begun.
4. The LED light on the single charging station blinks green when the unit is
being charged.
Battery Status Indicators
On the back of the unit, four LEDs will illuminate based on the battery
status when the battery status button is pressed.
Status Description
4 100% charged
3 75% charged
2 50% charged
1 25% charged
Programmable Buttons
The three blue buttons can be configured in the application that uses our
SDK to perform specific functionality.
• Left programmable button for scanning.
• Right programmable button for scanning.
• Right emergency button for user-specific functionality.
