XBee SMT Grove Development Board XBee connector
The XBee SMT Grove Development Board provides three spring sockets. A spring header is a custom Digi header that provides a reliable connection to
SMT XBee modules without soldering the module in place.
Left
Pin Signal
Comments
1
GND
2
3.3V
XBee supply
Bottom
Right
Pin Signal Comments
Pin Signal
1
DIO18 To GROVE_
1
DIO18
2
2
Comments
AD0/CB
To commissioning button and GROVE_
AD0
