Overview
Number Item
1 Through-hole
XBee sockets
2 Grove
connectors
3 Association
indicator
4 RSSI indicator
5 Reset button
6 Potentiometer 10 K potentiometer connected to the XBee AD3 line. One jumper is
7 Micro USB
8 Commissioning
button
9 Battery
connector
10 Loopback
jumper
11 User button
12 ON/SLEEP LED
13 User LED
14 RX and
TX indicator
15 I2C bus
XBee Grove Development Board User Guide
XBee through-hole (TH) Grove development board
Description
Two 10-pin, 2 mm pitch.
The board provides six vertical Grove connectors, connected to XBee
DIO lines.
LED connected to the XBee association pin.
LED connected to the XBee RSSI pin.
Button connected to the XBee reset pin.
available to save power when it is not used.
The XBee serial port is connected through a USB to RS-232 converter to
a micro USB connector provided on the board.
Button connected to the XBee commissioning pin.
Two-pin, 2 mm pitch, PH type connector from JST to power the board
from an external battery.
Three-pin jumper to connect the UART to the USB (normal mode) or to
make a loopback connection between the Rx and Tx signals of the UART.
Button connected to XBee DIO4 line. The button shares the same DIO
line with one user LED.
LED connected to the ON/SLEEP pin (DIO9).
On: XBee is awake
Off: XBee is asleep
A user LED that shares the DIO4 with the user button.
Yellow: UART Rx / RF Tx
Bus connected to XBee DIO1/DIO11 to be used with several Grove
sensors.
