DEMO MANUAL DC1385A
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 2 CIN1, CIN7
2 4 CIN3, CIN4, CIN5, CIN6
3 2 CO3, CO8
4 2 CO1, CO9
5 1 RSET1
6 1 RSET2
7 2 R2, R1
8 1 U1
Additional Demo Board Circuit Components
1 0 CPP1, CFF1, CPP2, CFF2
2 0 CIN2, CIN8, CO11, CO12
3 0 CO2, CO4, CO5, CO6, CO7, CO10
4 0 C1, C2, C3, C4
5 1 R9
6 1 R7
7 2 R8, R6
8 1 R10
Hardware-For Demo Board Only
1 3 JP1, JP2, JP3
2 3 JPX1, JPX2, JPX3
3 13 TP1, TP3, TP7-9, TP12,
TP14, TP16-20, TP23
4 8 TP2, TP6, TP10, TP11, TP13,
TP15, TP21, TP22
5 4 (STAND-OFF)
6
PART DESCRIPTION
CAP ., OSCON 120uF , 10V, E7
CAP ., X5R, 10μF , 6.3V, 20%, 1206
CAP ., X5R, 22μF , 6.3V, 20%, 1206
CAP ., X5R, 100μF , 6.3V, 20%, 1210
RES., CHIP , 4.02k, 1/16W, 1%, 0402
RES., CHIP , 10.0k, 1/16W, 1%, 0402
RES., CHIP , 100k, 1/16W, 1%, 0402
I.C. LTM4614EV 144 PIN LGA
CAP ., 0402, OPT
CAP ., 1206, OPT
CAP ., 7343, OPT
CAP ., 0402, OPT
RES., CHIP , 4.02k, 1/16W, 1%, 0402
RES., CHIP , 10.0k, 1/16W, 1%, 0402
RES., CHIP , 4.99k, 1/16W, 1%, 0402
RES., CHIP , 1mΩ, 1W, 5%, 2512
HEADER 3 PIN 0.079 SINGLE ROW
SHUNT, 0.079" CENTER
TESTPOINT, TURRET, 0.094" PBF
JACK BANANA
STAND-OFF , NYLON 0.50"
MANUFACTURER/PART NUMBER
SANYO, 10SVP120M
AVX, 12066D106MAT2A
AVX, 12066D226MAT2A
AVX, 12106D107MAT2A
VISHAY, CRCW04024K02FKED
VISHAY, CRCW040210K0FKED
VISHAY, CRCW0402100KFKED
LINEAR TECH., LTM4614EV
CAP7343
VISHAY, CRCW04024K02FKED
VISHAY, CRCW040210K0FKED
VISHAY, CRCW04024K99FKED
PANASONIC, ERJM1WTJ1M0V
SAMTEC, TMM103-02-L-S
SAMTEC, 2SN-BK-G
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8833(SNAP ON)
