Erica Synths WOGGLEBUG Manual To Assembly page 2

GUIDE TO ASSEMBLY OF ERICA SYNTHS WOGGLEBUG
BOM
CAPACITORS
C2-C14 100n
C1 100n
C15 10n
C18 1n
C23 - C25 47n
C19, C20 1µ
C21 2.2µ
C22 3,3µ
C16, C17 47µ
RESISTORS
R01, R05 3k3
R1 820ohm
R02 150k
R2 2k2
R3, R4, R5, R04, R41 68k
R03, R6, R7, R9, R10 100k
R8, R40 300k
R11, R13-R16, 10k
R12 8k2
R17 10M
R18 120k
R19 15k
R21-R27 1k
R29-R31 1M
R31, R32 20k
R33 220k
R34 4k7
R35 470ohm
R36 49K99
R37-R39 33k
SEMICONDUCTORS
T1 2N3906
T2-T4 2N3904
U1, U2 CD4046
U3 LF398
U4 LM555N
U5, U6 TL072
U7 TL074
D1-D4 1N4148
D5, D6 1N4007
Vactrol VTL5C3
Vactrol VTL5C3/2
LED 3mm
POTENTIOMETERS
V2 - V4 B1M
V1, V5, V6 B100k
OTHER
L5, L6 Ferrite bead
Power connector 2x5 pin
Jacks
IC sockets 16 pin
IC sockets 14 pin
IC sockets 8 pin
Links are from Farnell.lv, but you can use the part number for local Farnell
13 SMD 1206
1 Ceramic, 2,5mm spacing
1 Film, 5mm spacing
1 Ceramic, 5mm spacing
3 Film, 5mm spacing
2 Electrolytic >25V, 2,5mm spacing
1 Electrolytic >25V, 2,5mm spacing
1 Non polarized Electrolytic >25V, 2,5mm spacing
Electrolytic >25V, 2,5mm spacing
2
1
1
1
5
5
2
5
1
1
1
1
8
3
2
1
1
1
1
3
1
3
2 DIL case
1 DIL case
1 DIL case
2 DIL case
1 DIL case
4
2
1 Farnell VTL5C3
1 Farnell VTL5C3/2
2 Color of your choice
3 Thonk
1 Thonk
2 Can be replaced by 20ohm resistor
9 Tnonkiconn
2
1
4
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
1%
5%
