- Page 1 FIELDVISION OCM-7P-HDR 7" Professional Field Monitor QUICKSTART GUIDE...
- Page 2 PRECAUTIONS • Exposure to high sound levels • Handle this product with care. can cause permanent hearing Avoid any impacts to this loss. Avoid listening at high product. volumes for extended periods • Do not block the vents in this of time.
- Page 3 CONTENTS • Monitor • NP-F battery plate • Sun hood • LP-E6 battery plate • Sun-hood frame • V-mount battery adapter • Mini HDMI to HDMI cable and mounting screws (C to A) • 1/4-20 screw and hex key • Shoe-mount ball head •...
- Page 4 OVERVIEW Heat vents FIELDVISION OCM-7P-HDR 1/4-20 threaded mounting sockets...
- Page 5 Input selector F1 and F2 buttons Exit button / Battery plate mute button mounting holes Scroll wheel Speaker MENU EXIT INPUT HDMI DC 12V SDI input USB port Power input connector Headphone HDMI input jack connector SDI output connector HDMI output connector...
- Page 6 Power switch 1/4-20 threaded mounting socket...
-
Page 7: Getting Started
GETTING STARTED ATTACHING A BATTERY PLATE 1. Align the battery adapter with the four mounting holes on the back of the monitor, and screw it in with the included screws. 2. Attach the power cord to the power input. 3. Place the NP-F or LP-E6 battery plate into the adapter, making sure to align the plate’s and... -
Page 8: Attaching The Sun Hood
2. Slide the battery toward the contacts until it’s firmly in place. ATTACHING THE SUN HOOD Attach the sun hood to the monitor by following these steps: 1. Attach the sun hood to the sun-hood frame by pressing the touch- connect strips together. - Page 9 MOUNTING THE MONITOR ONTO A CAMERA 1. Determine the monitor orientation you prefer, and screw the ballhead into the bottom or side 1/4-20 threaded socket until it’s tight. 2. Loosen the mounting foot by turning the locking wheel clockwise. Make sure the side tilt adjustment knob is tight, and the ballhead is locked in place.
-
Page 10: Connecting To A Camera
2. Screw the 1/4-20 screw into the socket, and tighten it with the hex key. 3. Screw the ballhead into a 1/4-20 socket until it’s snug. 4. Screw the monitor onto the ballhead, and secure it by tightening the locking wheel. CONNECTING TO A CAMERA HDMI: Connect the monitor’s HDMI input to a camera with an HDMI output. -
Page 11: Accessing The Menus
USER INTERFACE ACCESSING THE MENUS To get the most out of the monitor, make sure its settings are properly configured. All the setting configurations are located in the main menu, which has six submenus: Image Adjust, Marker, Function, Monitoring Tools, Audio, and System. MENU NAVIGATION 1. -
Page 12: Quick Adjustments
QUICK ADJUSTMENTS When the monitor is powered on, you can make quick adjustments to the volume, brightness, contrast, saturation, and sharpness settings at any time. • Turn the scroll wheel to activate the volume menu and change the volume. • While the volume menu is on-screen, press the scroll wheel repeatedly to cycle through the brightness, contrast, saturation, and sharpness menus, and to exit quick adjust mode. - Page 13 When activated, the function buttons default to the setting in the Scan and Waveform menus described below. Press the function button repeatedly to cycle through the options available in the menu's settings. • Press the function button to activate the menu. •...
- Page 14 RESETTING THE OCM-7P-HDR To erase all settings and return to the factory presets, follow these steps: 1. Press the scroll wheel to open the main menu. 2. Select System. 3. In the System menu, scroll down to Reset, and press the scroll wheel.
-
Page 15: Image Adjust Menu
IMAGE ADJUST MENU BRIGHTNESS Adjusts the monitor’s brightness value from 0 to 100. The default setting is 50. CONTRAST Adjusts the contrast value of the on-screen image from 0 to 100. The default setting is 50. SATURATION Adjusts the value of screen color saturation from 0 to 100. The default setting is 50. -
Page 16: Hdmi Rgb Range
HDMI RGB RANGE Select limited range 16–235 (default) or full range 0–255. COLOR SPACE Selects one of the color-space presets: Rec709 (default), EBU, Native, and SMPTE-C. CAMERA LUT Activates either the Default LUT menu or the user LUT menu. The default setting is off. Applied LUTs will be sent downstream on active outputs. -
Page 17: Back Light Mode
GAMMA Select one of the preset gamma points. Choose Off, 1.8, 2.0, 2.2 (default), 2.35, 2.4, 2.6, or 2.8. Select one of the HDR presets. Choose Off (default), ST 2084 300, ST 2084 1000, ST 2084 10000, or HIg. BACK LIGHT MODE Adjusts the intensity of the backlight. -
Page 18: Marker Menu
MARKER MENU CENTER MARKER Turning the center marker option on places a crosshair at the center of the screen. The preset is set to off. ASPECT MARKER Sets the aspect marker on-screen display. Select from 16:9, 1.85:1, 2.35:1, 4:3, 3:2, 1.3X, 2.0X, 2.0X MAG, and off (default). SAFETY MARKER Displays an on-screen safety frame marker. -
Page 19: Marker Mat
MARKER MAT Available only when an aspect ratio is selected from the Aspect Marker menu. Adjust the darkness of the area of the screen that’s outside the aspect marker. Choose from 1 (lightest) to 7 (darkest) and off (default). THICKNESS Adjusts the thickness of the on-screen markers from 1 to 7. -
Page 20: Function Menu
FUNCTION MENU SCAN Determines how the image is displayed based on the settings in the Aspect and Zoom menus below. Selecting Aspect or Zoom activates the Aspect or Zoom menus. Selecting Pixel-to- Pixel turns off scaling and displays the incoming video signal in its native resolution and aspect ratio with 1:1 pixel mapping. -
Page 21: Check Field
H/V DELAY H/V delay mode highlights the horizontal and vertical blanking portions of the incoming signal. Select from three delay modes. H mode delays the horizontal sync. V mode delays the vertical sync. H/V mode delays both horizontal and vertical sync. The default setting is off. - Page 22 MONITORING TOOLS MENU WAVEFORM Select from Multi, Y, YCbCr, RGB (default), RGB Full, and off. WAVEFORM TRANS. Adjusts the level of transparency of the waveform window. Select 25%, 50% (default), or off (opaque). PEAKING Turning the peaking feature on adds a color outline to high- contrast areas of the image, highlighting areas that are in focus.
-
Page 23: False Color
FALSE COLOR Replaces the true colors of the image with a standard set of colors, displayed in an on-screen chart, that represent exposure levels. The higher—or hotter—the exposure, the higher the color will be in the chart. The default value is off. EXPOSURE ZEBRAS Turning on displays animated black and white stripes through areas of the image that are overexposed, along with an on-... -
Page 24: Audio Menu
AUDIO MENU VOLUME Adjusts the level of the audio output from 0 to 100. The default volume is set to 0. LEVEL METER Activating the level meter puts a meter on-screen that can monitor the level of up to 16 audio channels. The default setting is off. -
Page 25: System Menu
SYSTEM MENU LANGUAGE Sets the language on the on-screen display to English (default) or Chinese. HDMI/SDI CONVERT Activating this feature cross-converts signals so an HDMI signal can be output from the SDI port, and an SDI signal can be output from the HDMI port. The default value is off. Additionally, applied LUTs will be sent downstream from the active outputs. -
Page 26: Image Flip
IMAGE FLIP Controls the orientation of the on-screen image. Flip the screen horizontally (H), vertically (H), or both (H/V). The default is set to off. Sets the level of the internal cooling fan. Options are low (default) and high. COLOR CALIBRATION Recommended for advanced users only. -
Page 27: Specifications
SPECIFICATIONS Panel size 7 in. Panel type IPS LCD Backlight Resolution 1920 × 1200 Brightness 500 cd/m² Contrast ratio 1000:1 Viewing angle L/R: 170° U/D: 170° Aspect ratio 16:10 Input HDMI, SDI Output HDMI, SDI, headphone (3.5 mm stereo), mono speaker Threaded socket 1/4-20 (×3) Input voltage... -
Page 28: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
