Elvid OCM-7B-D FieldVision User Manual

7" on-camera monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FIeLDVIsION
OCM-7B-D
7" ON-CAMerA MONITOr
user
MANuAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OCM-7B-D FieldVision and is the answer not in the manual?

Questions and answers

Related Manuals for Elvid OCM-7B-D FieldVision

Summary of Contents for Elvid OCM-7B-D FieldVision

  • Page 1 FIeLDVIsION OCM-7B-D 7" ON-CAMerA MONITOr user MANuAL...
  • Page 3 INTrODuCTION Thank you for choosing Elvid. The Elvid OCM-7B-D FieldVision is an on-camera monitor with HDMI and composite audio and video inputs, as well as composite video loop-through. The 7″ LED panel’s native resolution is 1024 × 600, with an aspect ratio of 16:9 (native) that you can set to 4:3.
  • Page 4 PreCAuTIONs • Exposure to high sound levels can power source before storage and cause permanent hearing loss. Avoid during electrical storms. listening at high volumes for extended • Do not use chemical solutions to clean periods of time. this product. Clean it with only a soft, •...

  • Page 5: Table Of Contents

    TABLe OF CONTeNTs Product Contents ..............6 Overview ................7-8 Powering Options ..............9-10 Using the OCM-7B-D ............11-12 The Sunshade .................13 The Menu ................14 Color Menu ................15 OSD Menu ................16 Function Menu ............... 17 Sound Menu................18 Using the Buttons ..............19 Specifications ..............20-21 Troubleshooting ..............22-24 Notes ..................

  • Page 6: Product Contents

    PrODuCT CONTeNTs · 7" On-Camera Monitor · Mini HDMI to HDMI cable · Shoe-mount ball head · User manual · Sunshade NOTE: Additional battery plates and/or battery adapters compatible with other popular brands can be purchased by visiting www.elvidcinema.com...

  • Page 7: Overview

    OVerVIeW Sunshade slots Power button Headphone jack Status LED Screen Mode button Camera button Up button Scale button Down button Left Nav Menu button Right Nav...
  • Page 8 Speaker Battery mounting plate 1/4″-20 Threaded socket DC Input terminal Composite video output HDMI input Power Switch Composite video input Audio input...

  • Page 9: Powering Options

    There are two ways to power the FieldVision: AC or a Canon LP-E6 battery. AC POWER To run the FieldVision via AC power, use the Elvid 12 V DC adapter to connect the FieldVision’s DC power input to your AC power source.
  • Page 10 To install a compatible battery, follow these steps: 1. Place a compatible battery in the battery plate. Make sure the battery’s bottom contacts are aligned with the contacts in the battery plate. 2. Slide the battery forward until it locks into place. To turn on the FieldVision, press the power switch to the On position.

  • Page 11: Using The Ocm-7B-D

    usING THe OCM-7B-D MOUNTING THE FIELDVISION Use the FieldVision’s 1/4″-20 threaded socket to attach the monitor to your mounting system. Make sure your bracket can support the monitor. CONNECTING THE VIDEO SOURCE HDMI Input: The FieldVision is equipped with an HDMI input for use as a wired high-definition video monitor.
  • Page 12 Composite Video Input: The FieldVision also has a composite video input for use as a wired standard-definition video monitor. Use a compatible cable (not included) to connect your composite video source to the FieldVision’s composite video and audio inputs, and then press the Mode button to cycle through the input modes until “video”...

  • Page 13: The Sunshade

    suNsHADe The sunshade prevents glare on the monitor’s screen by blocking out stray light, and is useful when shooting outdoors. 1. Insert the sunshade’s pegs into the monitor’s sunshade slots. 2. Slide the sunshade down until it locks into place. To deploy the sunshade, fully open its lid and wings.

  • Page 14: The Menu

    THe MeNu To get the most out of the FieldVision, make sure the monitor’s settings are properly configured. All of the setting configurations are located in the main menu, which has four submenus: Color, Onscreen Display (OSD), Function, and Sound. The submenus are located in the left column of the main menu window.

  • Page 15: Color Menu

    COLOr MeNu In the Color menu, you can adjust brightness, contrast, hue, and saturation of the monitor from 0 (least) to 100 (most). Check Field: In Check Field mode, only the selected color will appear onscreen. You can select red, green, blue, or mono. In mono, a grayscale image will appear onscreen.

  • Page 16: Osd Menu

    OsD MeNu Language: You can set the onscreen language to English (default), simplified Chinese, French, Italian, German, Spanish, Japanese, Korean, Russian, and Portuguese. H Position: Adjust the horizontal position of the onscreen menu. V Position: Adjust the vertical position of the onscreen menu. OSD Timeout: Use this setting to set the length of time the onscreen menu is displayed.

  • Page 17: Function Menu

    FuNCTION MeNu Reset: Restore the FieldVision’s menu to the factory default settings. System: Select the transmission display format. You can choose NTSC M (default), PAL M, NTSC BG, PAL N, NTSC DK, PAL DK, PAL I, or SECAM BG. Display Ratio: You can set the aspect ratio for the onscreen image.

  • Page 18: Sound Menu

    sOuND MeNu Volume: Adjust the monitoring volume of the FieldVision from 0 to 100. Focus: Use this setting to check the areas of the image that are in focus. Activating this setting increases the sharpness and contrast of the monitor and displays in-focus areas of the image with sharpening artifacts.

  • Page 19: Using The Buttons

    usING THe BuTTONs For greater efficiency while using the FieldVision, you can use the buttons on the front of the monitor as shortcuts to various functions instead of cycling through the onscreen menus. Camera Button: Press this button to enable or disable Camera mode.

  • Page 20: Specifications

    sPeCIFICATIONs MONITOr Panel Size 7" Panel Type Backlight Resolution 1024 × 600 Brightness 250 cd/m² Contrast ratio 700:1 Viewing angle L/R: 75°/75° U/D: 70°/75° Dot pitch (W × H) 0.05 × 0.15 mm Display ratio 16:9 Inputs HDMI, composite video, mono audio Outputs Composite video,...
  • Page 21 MONITOr (CONTINueD) Supported formats 480i, 480p, 576i, 576p, (50/60 Hz) 720p, 1080i Threaded socket 1/4″-20 Input voltage 6 to 24 V DC Power consumption ≤6 W Battery type Canon LP-E6 Dimensions 7.4″ × 5.3″ × 2.0″ (L × W × H) (18.9 ×...

  • Page 22: Troubleshooting

    PrOBLeM sOLuTION The FieldVision will not • If you are powering the turn on. FieldVision with a battery, make sure the battery is fully charged and properly seated in the battery plate. • Make sure that the 12 V DC adapter is fully plugged in, and that your AC power source is reliable.
  • Page 23 PrOBLeM sOLuTION (continued) • If you are powering the FieldVision via AC power, use only the Elvid 12 V DC adapter. • Check your cables to make sure they are reliable. The screen displays • Check the brightness, contrast, only a black and white hue, and saturation settings, and image.
  • Page 24 PrOBLeM sOLuTION The FieldVision is • Turn the monitor’s volume all the way down or plug headphones emitting a high- into the headphone jack. pitched whine (feedback). There is no sound. • Increase the monitoring volume. • If you are using the FieldVision as a wired standard-definition video monitor, make sure your composite audio cable is fully...

  • Page 25: Notes

    NOTes ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________...

  • Page 26: Fcc Statement

    FCC sTATeMeNT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and AUTION: (2) this device must accept any interference received, OT SURFACE including interference that may cause undesired operation.

  • Page 27: Warranty

    ONe-YeAr LIMITeD WArrANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be...
