Page 1: Quickstart Guide
STUDIOVISION STV-150-4KH / STV-230-4KH / STV-280-4KH 4K HDMI Monitor (15" / 23" / 28") STUDIOVISION 4K HDMI1 HDMI2 HDMI3 HDMI4 MENU EXIT QUICKSTART GUIDE... -
Page 2: Box Contents
BOX CONTENTS • Elvid StudioVision Monitor • Sun hood • AC adapter • DC power cord • Tally connector and hardware • Mounting feet (×2) and hardware PRECAUTIONS • Keep this product away from water and any flammable gases or liquids. - Page 3 OVERVIEW FRONT STUDIOVISION 4K HDMI1 HDMI2 HDMI3 HDMI4 MENU EXIT SDI input selector Speakers HDMI 1–4 input selectors DVI input selector VGA input selector Menu button Scroll left button Scroll right button Exit button F1–F4 function buttons Power indicator Headphone output...
- Page 4 BACK Release button V-mount battery plate Handle Connector protection GND 5 TALLY HDMI AUDIO DC 15V VESA 75/100 mounting threads Tally port VGA input DVI input HDMI input (×4)* RCA audio L/R input SDI input/output 4-pin XLR power input Power switch *Note: HDMI 1 supports 4K @ 60 Hz.
-
Page 5: Getting Started
GETTING STARTED ATTACHING A V-MOUNT BATTERY Attach a battery by sliding it into the V-mount plate until it clicks into place. Release the battery by pressing the release button and sliding the battery off the V-mount. CONNECTING TO AC POWER 1. -
Page 6: User Interface
USER INTERFACE MENUS FUNCTION BUTTONS 1. Press the Menu button to open the main menu. The function buttons default to the following menus: Main menu items are Picture, Function, Display Mode, Display Setting, Select Region, Input, Audio, VGA, System, and •... -
Page 7: User Options
USER OPTIONS REMOVING THE MONITOR FROM THE FLIGHT CASE STAND-ALONE USE 1. Remove the V-mount battery, or unplug the AC power adapter. Metal feet and attachment screws are included for stand-alone operation. 2. Set the monitor faceup on a flat surface. 1. -
Page 8: Supported Resolutions And Frame Rates
SUPPORTED RESOLUTIONS AND FRAME RATES HDMI2.0 HDMI1.4 3G-SDI 480i (59.94) 480i (59.94) 59.94i 480i (60) 480i (60) 576i (50) 576i (50) 480p (59.94) 480p (59.94) 59.94p 480p (60) 480p (60) 576p (50) 576p (50) 23.98p (1920×720) 720p (23.98) 720p (23.98) 720p (24) 720p (24) 720p (25) - Page 9 DVI-I Resolution Resolution 800x600 56/60/70/72/75 720x480 1024x768 50/60/66/70/75 800x600 56/60/72/75 1152x864 60/70/75 1024x768 50/60/66/70/75 1152x900 1152x864 60/70/75/76 1280x720 50/60/70/72/75 1280x720 50/60/70/72/75 1280x768 50/60/70/75 1280x768 50/60/70/75 1280x800 60/70/72/75 1280x800 60/70/72/75/85 1280x960 60/70/72/75 1280x960 60/72/75 1280x1024 60/70/72/75/76 1280x1024 60/70/72/75/76 1360x768 1360x768 1440x900 60/75 1400x1050 60/75/85...
-
Page 10: Specifications
SPECIFICATIONS DISPLAY POWER Panel Type IPS LCD DC Input Power 12 to 24 V DC Display Size STV-150-4KH: 15.6 in. (39.6 cm) Battery Type V-mount STV-230-4KH: 23.8 in. (60.5 cm) Power STV-150-4KH: ≤15 W STV-280-4KH: 28 in. (71.1 cm) Consumption STV-230-4KH: ≤36 W Screen Resolution 3840 ×... -
Page 11: Troubleshooting
TROUBLESHOOTING Problem Solution The StudioVision will not turn on. • Make sure that the AC adapter is fully plugged in, and that the AC power source is reliable. • Make sure the V-mount battery is fully charged and properly seated in the V-mount battery plate. The StudioVision is turned on, but •... -
Page 12: One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider’s discretion, of any product that fails during normal use of this product in its...
