- Page 1 FIELDVISION OCM-7B-4KV2 7˝ 4K IPS Monitor USER MANUAL...
- Page 3 THANK YOU FOR CHOOSING ELVID. The Elvid FieldVision 4KV2 is a lightweight 7-inch on-camera monitor that’s capable of displaying signals up to UHD 4K (3840 × 2160) and DCI 4K (4069 × 2160). The LCD panel’s native resolution of 1920 × 1200 provides a sharp image and facilitates precise color rendering.
- Page 4 PRECAUTIONS • Exposure to high sound levels • Handle this product with care. can cause permanent hearing Avoid any impacts to this product. loss. Avoid listening at high volumes for extended periods of • Do not block the vents in this time.
-
Page 5: Table Of Contents
TABLE OF CONTENTS Overview ....................6-7 Product Contents .................. 8 Powering Options ................9-10 Using the OCM-7B-4KV2 ...............11-12 The HDMI Lock ..................13 The Sunshade ..................14 Front Panel Buttons ................15 Function Buttons .................16 The Menu ....................17 Color Menu ..................18-19 On-screen Display (OSD) Menu ..........20-21 Function Menu ................22-24... -
Page 6: Overview
OVERVIEW FIELDVISION MODE MENU Screen Status LED Mode button Power button F4 button Left Nav/Vol - F3 button Right Nav/Vol + Menu button Up Nav/F2 button Down Nav/F1 button... - Page 7 Headphone jack OSD controller port USB port Sunshade slots Speaker HDMI lock mount DC power input Battery plate HDMI input 1/4″-20 threaded socket AV input...
-
Page 8: Product Contents
PRODUCT CONTENTS · 7 in. On-Camera Monitor · Mini HDMI to HDMI cable · Shoe-mount ball head · HDMI lock collar · Sunshade mounting frame · Sony L-Series battery mount · Sunshade Note: For additional battery plates and adapters compatible with other popular brands, visit elvidcinema.com. -
Page 9: Powering Options
POWERING OPTIONS There are two ways to power the FieldVision 4KV2: AC power or battery (not included). CAMERA BATTERY The FieldVision’s built-in battery mounting plate accommodates a Sony L-Series–type battery. To install a compatible battery, follow these steps: 1. Place a compatible battery in the battery plate. - Page 10 To turn on the FieldVision 4KV2, press the power button on the front panel of the monitor. The FieldVision 4KV2 will turn on and enter standby mode (yellow indicator LED). A battery monitor appears at the top of the screen and displays the remaining battery charge.
-
Page 11: Using The Ocm-7B-4Kv2
USING THE OCM-7B-4KV2 MOUNTING THE FIELDVISION Use the FieldVision 4KV2’s 1/4″-20 threaded socket to attach the monitor to your mounting system or the included ball head. Make sure your bracket can support the monitor. CONNECTING THE VIDEO SOURCE HDMI Input: The FieldVision 4KV2 is equipped with an HDMI input for use as a wired high-definition video monitor. - Page 12 Composite Video Input: To use your FieldVision 4KV2 as a wired standard-definition video monitor, you’ll need an A/V breakout cable (available separately). 1. Insert the 1/8″ (3.5 mm) plug into the A/V input on the side of the monitor. 2. Connect your composite video source to the yellow RCA jack.
-
Page 13: The Hdmi Lock
HDMI LOCK An HDMI lock is included with the FieldVision 4KV2 to reduce stress on the HDMI plug and ensure that the plug isn’t pulled out of the input while you’re shooting. To install the HDMI lock, follow these steps: 1. -
Page 14: The Sunshade
SUNSHADE The sunshade prevents glare on the monitor’s screen by blocking out stray light, and it is useful when shooting outdoors. To attach the sunshade to the monitor, follow these steps: 1. Match the pegs of the mounting frame with the slots on the back of the monitor. -
Page 15: Front Panel Buttons
FRONT PANEL BUTTONS For greater efficiency while using the FieldVision 4KV2, you can use the buttons on the front of the monitor as shortcuts to various functions, instead of cycling through the on-screen menus. Mode Button: Selects between HDMI and A/V input signals. Left Navigation/Vol –... -
Page 16: Function Buttons
FUNCTION BUTTONS The four function buttons (F1–4) have preset shortcuts assigned to them, but can be changed to accommodate your specific needs. See Function Button Shortcut Menu below for information on changing the function assignment for each button. F1 Button: Preset to Check Field. In Check Field mode, only the one selected color will appear on-screen. -
Page 17: The Menu
THE MENU To get the most out of the FieldVision 4KV2, make sure the monitor’s settings are properly configured. All of the setting configurations are located in the main menu, which has four submenus: Color, On-screen Display (OSD), Function, and Function Button Shortcut. -
Page 18: Color Menu
COLOR MENU The color menu offers three preset picture modes (standard, mild, and dynamic) as well as a user mode with adjustable brightness, contrast, saturation, and sharpness settings. In all picture modes, the values of color temperature and tint can be adjusted to your specific needs. Other parameters that can be adjusted appear black, and when selected with the Up/Down buttons, a horizontal submenu icon appears next to it. - Page 19 Saturation: Adjusts the value of screen color saturation from 0–100. Sharpness: Adjusts the value of fine detail of the picture from 1–100. Color Temp.: Presets are 6500 (default) and 9300. When User mode is selected, the values of red, green, and blue can be set manually from 0–255.
-
Page 20: On-Screen Display (Osd) Menu
ON-SCREEN DISPLAY (OSD) Language: You can set the on-screen language to English (default), Simplified Chinese, Spanish, Portuguese, French, Dutch, German, and Japanese. Aspect Ratio: Adjusts the aspect ratio of the incoming video signal and how it is displayed on-screen. Available settings are Panorama, Auto, 4:3, 16:9, Zoom 1, Zoom 2, and Just Scan. - Page 21 In manual mode (default), press the power button to turn the monitor on. USB Upgrade: Contact Elvid customer support to see if there is a firmware update for your monitor. Reset: Pressing the Right Nav button resets the FieldVision...
-
Page 22: Function Menu
FUNCTION MENU Center Marker: Selecting On puts a center marker on-screen. Off is the default setting. The center marker does not appear while the menu is displayed. Close the menu to make the center marker visible. Safe Frame: Safe frame displays and adjusts the size of the on-screen safety frame markers. - Page 23 P2P: Pixel-to-Pixel mode turns off scaling and displays the incoming video signal in its native resolution and aspect ratio with 1:1 pixel mapping. If the picture is larger than the monitor’s 1280 × 800 resolution, the center of the image will appear on-screen.
- Page 24 Exposure Level: Adjusts the sensitivity of the overexposure animation. Select from 1 to 100 IRE. Embedded Audio: Displays an on-screen audio meter. Nine Grid: Turning on this feature divides the screen into a 3 × 3 grid of nine panels, any of which you can select to display at full screen.
-
Page 25: Function Button Shortcut Menu
FUNCTION SHORTCUT MENU This menu allows you to select or change the settings of the four function buttons on the front of the monitor. The available functions are Center Marker, Safe Frames, Check Field, Focus Assist, Aspect Ratio, Camera Mode, Image Flip, P2P, Image Freeze, Histogram, False Colors, Over Exposure, Embedded Audio, Nine Grid, Zoom, and Anamorphic. -
Page 26: Specifications
SPECIFICATIONS MONITOR Panel size 7 in. Panel type Backlight Resolution 1920 × 1200 Brightness 400 cd/m² Contrast ratio 1200:1 Viewing angle L/R: 80°/80° U/D: 80°/80° Dot pitch (W × H) 0.07875 × 0.07875 mm Aspect ratio 16:10 Inputs HDMI, AV Outputs Composite video, headphone (3.5 mm... - Page 27 (CONTINUED) Supported formats 480i/p, 576i/p: 60/59.94/ (50/60 Hz) 50/30/29/25/24/23.98 720p: 60/59.94/50/30/ 29/25/24/23.98 1080i: 60/59.94/50 1080p: 60/59.94/50/ 30/29.97/25/24/24 PSF/ 23.98/23.98 PSF UHD 4K: 3840 × 2160 24/25/30 DCI 4K: 4096 × 2160 Threaded socket 1/4″-20 Input voltage DC: 7 to 24 V Power consumption ≤8 W Battery type...
-
Page 28: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION The FieldVision 4KV2 • If you are powering the FieldVision 4KV2 with a battery, will not turn on. make sure the battery is fully charged and properly seated in the battery plate. • Make sure that the 12 V DC adapter is fully plugged in, and that your AC power source is reliable. - Page 29 PROBLEM SOLUTION The screen displays only • Check the brightness, contrast, hue, and saturation settings, and a black and white image. adjust as necessary. • Make sure the Check Field mode is turned off. The on-screen image size • Make sure the Camera mode is is incorrect.
-
Page 30: Fcc Statement
FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 31: Warranty
ONE-YEAR LIMITED WARRANTY This Elvid product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider’s responsibility with respect to this limited warranty shall be... - Page 32 ELVID ® A Gradus Group Brand...
