- Page 1 DACHNAYA DVUSHKA Cellular polycarbonate greenhouse (EURO) height 2,2 m any length multipple to 2m min 4m wight 2,0 m Technical certificate page 2-6 Assembling manual page7-27...
- Page 2 Name Quantity Box 1 Description 12фл small window vertical Dachnaya Dvushka greenhouse is designed for creation microclimate favorable for growing 12фп small window vertical garden crops on cottage and household plots. 12дл door vertical Greenhouse might have variable length depending on customers’ desire. Required length 12дп...
- Page 3 In winter, coverage of greenhouse should not be removed provided that snow supports load is limited. In winter greenhouse Dachnaya Dvushka doesn’t need any control in the majority of the areas of Russia, including Moscow, Tver, St.Petersburg horizontal screed...
- Page 4 A simplified fastening of parts with only one or two screws is the violation of assembly rules and the ground to relieve the manufacturer of the warranty responsibility. Manufacturer: Volya LLC 8 Severnyi Pereulok, Dubna, Moscow Oblast 141983 Manufacturer is responsible for quality of products in accordance with RF Civil Code.
- Page 5 Assembling manual Assembling manual General view of the frame of the greenhouse, extendable inserts General view of the frame of Dachnaya-Dvushka Greenhouse 4вк 4в 2кк «Dachnaya-Dvushka», extended by any number of inserts. 2к 4н 9-2л 2к 2с А 2с 9-2п 4н...
- Page 6 Assembling manual Assembling manual The location of arcs and the longitudinal fittings greenhouses, Installation steps extendable inserts Perform the assembly next to the installation site of the greenhouse. Fig. 4 4н 4н 4н 4н 4н Perform the assembly in accordance with the pictures of assembly stages and the joints as shown in Fig.
- Page 7 Assembling manual Assembling manual Installation steps Installation steps 1 Step 3 Step Collect a power arc (or the required number of power arcs depending on the number of А inserts) of the elements 1, 3, 4в, 4н, 22, 23, 24, 25, 26 using screws М4х8, M4 nuts. If the В...
- Page 8 Assembling manual Assembling manual Installation steps Door and window assembly 6 Step А А 2кк 13м А 13м 4в 4н 13м 14м 2с 14м 12фл 12фл 12фп 12фп 12фл В 2кк 2с А 2кк 2кк 13м 12фп 14м To attach the second end of the arc. If the length of the greenhouse more than В...
- Page 9 Assembling manual Assembling manual Fastening of coverage allowence allowance threshold line for penetration into for penetration Into the ground the ground In Fig.15 is a diagram of cuttingt for installation of greenhouses on the Foundation. If the greenhouse is installed on the ground, the lower part of the sidewalls of the end, it is recommended to extend 200 mm for the Door corresponding deepening of the polycarbonate in the ground.
- Page 10 Assembling manual Assembling manual Fastening of coverage Fastening of coverage Match elements 9-3 and 9-4 (Fig.17) and install them according to Fig.19. Washers and clamps on the end are set in accordance with Fig.21. press the pieces of polycarbonate at the edges from the doors and Windows lining 9-3, 9-4 (Fig.19), leaving holes for А...
- Page 11 Assembling manual Assembling manual Fastening of coverage Fastening of coverage Rotator for locking doors and windows inserted into the holes of the uprights of the door opening direct end outside until it stops. Using the tube the bend of the inner rectilinear end of the arm up (Fig.
- Page 12 Assembling manual Assembling manual Крепление покрытия Do not fully tighten! х2 х2 х4 х4 х4 adhesive tape х1 х1 х1 х1 х2...
- Page 13 Assembling manual Assembling manual L=1,0м х1 х2 х2...
- Page 14 Assembling manual Assembling manual Install the bracket with the hooks to lock the doors and vents in accordance Installation of sealing profilles with Fig. 24. Sealing profile consists of door profile -8,5m; loop profile is 3.6 m; end profile - 12m. the sealing profiles are installed along the contour of the doors and vents in compliance with Fig.
- Page 15 Technical certificate Manufacturer: LLC Volia, city of Dubna, Moscow Region. tel/fax: (495) 598-5-999 www.teplicy.ru e-mail: info@perchina.ru This manual cannot be reproduced in any form, fully or partially, without written consent of Volia LLC...
