PRODUCT
MANA
Product code MANA MW
MANA MW
K-BAND MICROWAVE PERIMETER PROTECTION
BARRIER
INSTALLATION AND MOUNTING MANUAL VERSION 3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MANA MW and is the answer not in the manual?

Questions and answers

Summary of Contents for Politec MANA MW

  • Page 1 PRODUCT MANA Product code MANA MW MANA MW K-BAND MICROWAVE PERIMETER PROTECTION BARRIER INSTALLATION AND MOUNTING MANUAL VERSION 3.0...
  • Page 2: Table Of Contents

    14.1 Basic settings and programming - MANA RX board 15.Appendix A:DT3 sensor …………………………………………………………………………………..……….………………...18 15.1 Commissioning and adjustment 16.Appendix B:MW details ………………………………………………………………..…………………..……..…………..19 16.1 Walk Test function 16.2 Installation tips 17.Technical specifications ………………..…...………………………………………………………………….………….…….. 20 18.FAQ…………………………………………………….………………………………………………………………….……….….………21 19.Product disposal………………………………………………………………………………………….……….……....….22 MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 3: Introduction

    The system has been designed to detect intrusions and activate the alarm; it is not a device that prevents intrusion.Politec is not responsible for damage, injury or loss caused by accidents, theft, force majeure (including momentary lightning-induced overcurrent), abuse, improper or incorrect use, faulty installation or inadequate maintenance.
  • Page 4: General Warnings

    • Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. •...
  • Page 5: List Of Main Components

    MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 6: Preparation For Installation

    • Check that the surface chosen for the installation of the product is sturdy so as to ensure stable fixing and that it is adequately protected against possible impacts or the elements. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 7: Assembly And Positioning Of The Cable Pit

    Insert the third side in the same way and Widen the two opposite walls of the cable pit so you tighten the screws can insert the last side Insert and fully tighten the missing screws of the two sides MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 8: Cable Pit Positioning

    Mana base is raised to achieve the appropriate vertical alignment. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 9: Column Transformer Mounting

    N.B. it is advisable to position the transformer in the space intentionally left, so as to be able to easily screw the fixing screws to the column and have sufficient space for positioning the battery. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 10 If the column is set up with the kit for pole or wall fixing, use the cover under the base for the passage of the cables, following the instructions as above and finally fix it in the same way to the base. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 11: Column Power Supply Connection

    9.Column power supply connection Blue - Brown blue brown Red - Red black black Black - Black FUSE A: 5A-24Vac FUSE B: 0.8A-13.8Vac Make all the electrical connections as shown in the diagram. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 12: Evaluations Before Installation

    When a body approaches longitudinally until it crosses the lobe, the signal received by the receiving section is perturbed until an alarm is generated. Attenuation can be large or small depending on the mass and type of material that crosses the emission zone. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 13: Barrier Positioning

    2 TX or 2 RX at each intersection, with different frequencies out of the 4 available. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 14: Wiring

    N.B.The shielding of this cable must be connected to the negative of 13.8 Vdc of all the columns. 230Vac mains cable Alarm signal cable (power supply) MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 15 3 – 4 Infrared section power supply Power connectors (terminal board of 24 Vac input 5 – 6 Cable coming out of the transformer 24 Vac output 7 – 8 Heater power supply MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 16 High impedance output if the voltage supplied by the transformer on the "24Vin" terminals is <18Vac. 120Ω output if the voltage supplied by the transformer on the "24Vin" terminals is > 18Vac. Not connected MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 17: Barrier Alignment

    1.Activate the cavities by setting the DIP on the back of each dish to OFF.This DIP must always remain in this position. 2.Select the same synchronisation channel, on the 4 DIP unit on the MW TX board and on the MW RX board MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 18 160-250m 6.5-7.3 N.B.:To check the optimal orientation, press the dish with a finger pointing it towards a specific direction (right or left) checking if there is an increase in the signal level. MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 19: Basic Functions

    SENS:Turn clockwise to increase the alarm threshold.High: risk of false alarms Low: risk of non-detection • DLY:Turn clockwise to decrease system sensitivity.High: requires a large mass to generate alarm Low: requires a small mass to generate alarm MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 20: Appendix A:dt3 Sensor

    • Adjust the sensitivity of the 24GHz microwave with the trimmer carry crossing tests 12V POWER SUPPLY NC ALARM ALARM LED DIP LED ON MW SENSITIVITY TRIMMER MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 21: Appendix B:mw Details

    Active Walk Test (buzzer) It shows automatic gain value SENS It displays sensitivity value (SENS) It displays 5V power supply It displays 9V power supply It displays 13.8V power supply VOLT It enables DISPLAY MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 22: Technical Specifications

    250mm x 200mm x from 1000 to 4000 mm on a 300mm round base* PROFILE DIMENSIONS WxDxH *On request it is supplied with a special base and accessories for wall mounting WEIGHT Variable from 10 to 20 kg per barrier WARRANTY 2 years MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 23: Faq

    ON and the others OFF). After accurately aligning the sensor, Check operation by disconnecting the column earth the system remains in alarm Check that the CAG value (dip 5-10 in ON) is less than 7.5 MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
  • Page 24: Product Disposal

    Warning!- Local regulations can impose heavy penalties for incorrect disposal of these products. For technical support, contact your security systems distributor MANA MW POLITEC | INSTALLATION MANUAL - VER.3.1...
